  • Page 1 V-SENSE V7003 T10 USER MANUAL SENSE SENSE SENSE...

  • Page 2: Table Of Contents

    CONTENTS 1. Importantsafety Instructions ……………………………..............……………………. 3 1.1 Safety precautions 1.2 Care and maintenance 2. Introduction ……………………………………………………………………................10 3. Each description …………………………………………………................…………..11 3.1 Front View 3.2 Rear View 4. Remote control ………………………………………………………………................13 5. OSD menu description .……………………………………………………................. 14 6. Product specification …..………………………………………………………..............23 6.1 Specification 6.2 OPS Specifications(Optional) 7.

  • Page 3: Safety Precautions

    » Otherwise, it may result in electric shock or fire. 1.1.1.8 If the pins of the power plug or the wall outlet are covered in dust, clean it using a dry cloth. » Otherwise, it may result in fire. i3TOUCH V- SENSE 7003T10 - operations manual...
  • Page 4 Caution 1.1.1.9 Avoid unplugging the power plug while the product is operating. » Otherwise, it may damage the product due to electric shock. 1.1.1.10 Make sure to use only the power cord supplied by our company. In addition, do not use the power cord of another electric appliance.
  • Page 5 » Avoid using chemicals such as wax, benzene, alcohol, thinner, mosquitorepellent, fragrance, lubrication or cleansing agent when cleaning the product, This may result in the exterior being deformed or the print being removed. i3TOUCH V- SENSE 7003T10 - operations manual...
  • Page 6 1.1.3.5 If you can’t get the product clean with just the supplied cloth, use a soft, damp cloth with a “monitor- exclusive cleansing agent” and wipe the product with it. » If no moitor-exclusive cleansing agent is available, dilute a cleansing agent with water at a ratio of 1:10 before cleaning the product.
  • Page 7 1.1.4.23 Watching the product from too close a distance continuously may damage your eyesight. 1.1.4.24 Avoid using a humidifier or cooker near the product. » Otherwise, it may result in electric shock or fire. i3TOUCH V- SENSE 7003T10 - operations manual...
  • Page 8 1.1.4.25 It is important to give your eyes some rest(5 minutes every hour) when viewing the product screen for long periods of time. » This will alleviate any eye strain. 1.1.4.26 Since the display panel is hot after using it for a long time, do not touch the product. 1.1.4.27 Keep the small accessories in a location out of the reach of children.

  • Page 9: Care And Maintenance

    The number of Sub-Pixels = Max. Horizontal Resolution x Max. Vertical Resolution x 3 Example) If the maximum resolution is 1920 x 1080, the number of sub-pixels is 1920 x 1080 x 3 = 6,220,800. i3TOUCH V- SENSE 7003T10 - operations manual...
  • Page 10 2. Introduction 2.1 Package Contents - Unpack the product and check if all of the following contents have been included. - Store the packaging box in case you need to move the product later. - If any items are missing, contact your dealer. - Contact a local dealer to purchase optional items.

  • Page 11: Front View

    4. IR Receive Remote Control: Aim the remote control towards this spot on the LED Display. 5. Ambient light sensor(Optional) 6. USB 1 Terminal (Direct connect to PC) 7. USB 2 Terminal (Direct connect to PC) i3TOUCH V- SENSE 7003T10 - operations manual...
  • Page 12 12 11 1. SPEAKER Out L. ( 10W , 8 Ohm ) 2. SPEAKER Out R. ( 10W , 8 Ohm ) 3. AUDIO LINE Out¬¬¬ 4. PC AUDIO Input 5. PC RGB Input 6. DISPLAY PORT Input 7. HDMI 3 Input 8.
  • Page 13 4. Remote Control 4.1 How to insert battery. Insert the battery into proper polarities. Battery model:(CR-2025 3V) i3TOUCH V- SENSE 7003T10 - operations manual...
  • Page 14 5. OSD Menu Description Picture Menus • Press the [MENU] Button. The OSD Main MENU will be shown. • Enter the PICTURE MENU Press the buttons to move through options in the PICTURE Menu. When you have moved to the option you would like to adjust, press the ENTER button and you will enter its settings.
  • Page 15 Brightness, and press the ENTER button to change either of their settings. Press the buttons to adjust both the Contrast and Brightness levels. After finishing, press the [Exit] Button to exit the OSD MENU. i3TOUCH V- SENSE 7003T10 - operations manual...
  • Page 16 Sound Menus • Press [MENU] Button. The OSD Main MENU will be shown. • Entering the Sound MENU Press the buttons to move up to the SOUND Menu. Press the ENTER button to enter the menu. • Select Sound Status Mode Press the buttons to move up to the SSM (Sound Status Mode) Menu, and press the ENTER...
  • Page 17 Auto mode is not available. Press the buttons to highlight Manual, and press the ENTER button to select it. Press the buttons to adjust the time, and press the ENTER button to confirm it. i3TOUCH V- SENSE 7003T10 - operations manual...
  • Page 18 • Setup System OFF Time Press or the Menu Button to move or go back to the previous menu options. Press the buttons to highlight Off Time, and press the ENTER button to select it. Press the buttons to highlight Off, and press buttons to turn this feature on or off.
  • Page 19 Press the buttons to highlight either PC/ HDMI1/ HDMI2/HDMI3/DP. Once the desired input is highlighted, press the ENTER button to select it. Only sources that are connected to the display can be selected. i3TOUCH V- SENSE 7003T10 - operations manual...
  • Page 20 • Selecting the screen ratio Press or the Menu Button to move or go back to the previous menu options. Press the buttons to highlight ARC (Auto Ratio Control), and press the ENTER button to view the available settings. Press the buttons to select either AUTO/16:9/ 4:3.
  • Page 21 On Off, and press the ENTER button to confirm. Selecting Reset On will return all OSD menu settings to their factory defaults. Selecting Reset Off will cancel and exit the menu. i3TOUCH V- SENSE 7003T10 - operations manual...
  • Page 22 • Setup Fan ON Time Press or the Menu Button to move or go back to the previous menu options. Press the buttons to highlight Fan ON Time. Press the ENTER Button. Press the buttons to select ON/20 Min/30 Min and press the ENTER button to confirm.

  • Page 23: Specification

    1600(W) x 922(H) x 11.7(D) 6.3 Ratings of Environment Item / Model 70 inch Storage Temperature -20°C ~ +60°C Operating Temperature 0°C ~ +40°C Power Supply Voltage AC100 - 240V, 50/60Hz Power Consumption 285W i3TOUCH V- SENSE 7003T10 - operations manual...
  • Page 24 6.4 Input/Output Description Items Specifications Display Format Auto/16:9/4:3 Video Picture Status Memory 5 Modes Color Status Memory 4 Modes Output(RMS) EQ Max. 10W X 2 Channels Sound System Stereo Sound Equalizer 5 Bands Sound Status Memory 5 Modes Balance PC-RGB 1 ( D-SUB 15P) PC-Audio 1 ( Ø3.5 JACK )

  • Page 25: Led Dimensions

    WSXGA 1600*1200(60Hz), 1920*1080(60Hz) WUXGA 1920*1080(60Hz) • Design and Specifications are subject to change without notice. • Table stand (optional) 7. Product Dimensions 7.1 LED Dimensions i3TOUCH V- SENSE 7003T10 - operations manual...

  • Page 26: Product Self-Diagnosis

    8. Troubleshooting 8.1 Product Self-Diagnosis - You can check if the product is working properly using the Self-Diagnosis function. - If a blank screen is displayed and the Power LED blinks even if the product and the PC are properly connected, perform the self-diagnosis function according to the procedures below.

  • Page 27: Before Request As

    A/S is the cost incurred to our bylaws, item rated A/S price is determined according to the criteria, accurate repair cost, please contacts a customer support counseling over the phone. 9.2.3 Even within the warranty period if you use a shipping and negligence A/S will be charged. i3TOUCH V- SENSE 7003T10 - operations manual...

  • Page 28: Www.i3-Learning.com
