Related Manuals for GAI-Tronics 370-901
Summary of Contents for GAI-Tronics 370-901
-
Page 1: Table Of Contents
Maintenance ..........................13 GUDA Device Administrator Options ....................14 Save Configuration Locally ........................14 Import Saved Configuration ........................ 15 GAI-TRONICS 3030 KUTZTOWN RD. READING, PA 19605 USA 610-777-1374 800-492-1212 Fax: 610-796-5954 ISIT WWW TRONICS COM FOR PRODUCT LITERATURE AND MANUALS... - Page 2 Specifications ..........................16 Electrical ..............................16 Ethernet ..............................16 Mechanical ............................. 16 Environmental ............................16 Audio ..............................16 GAI-TRONICS 3030 KUTZTOWN RD. READING, PA 19605 USA 610-777-1374 800-492-1212 Fax: 610-796-5954 ISIT WWW TRONICS COM FOR PRODUCT LITERATURE AND MANUALS...
-
Page 3: Confidentiality Notice
TRONICS retains all intellectual property and other rights in or to the information contained herein, and such information may only be used in connection with the operation of your GAI-TRONICS product or system. This manual may not be disclosed in any form, in whole or in part, directly or indirectly, to any third party. -
Page 4: Installation
Open the Enclosure ® Figure 2. Model 370-901 SP2 to Page/Party Bridge 1. Remove and retain the four screws on the front cover. 2. Open the hinged front cover of the enclosure and turn it to the left. -
Page 5: Mount The Enclosure
Pub. 42004-525A ® Model 370-901 SP2 to Page/Party Bridge Page 3 of 16 Mount the Enclosure 1. Determine the conduit or cable gland location(s) on the rear enclosure (see Figure 3). : The drill spots provided on the outside of the enclosure do not line up with the center of the holes that must be drilled in the enclosure to accept the conduit. -
Page 6: Ethernet-Tb1
Pub. 42004-525A ® Model 370-901 SP2 to Page/Party Bridge Page 4 of 16 Figure 4. Main PCBA Ethernet—TB1 Table 1. Ethernet Connector Wiring—TB1 1000Base- 100Base- Terminate the Ethernet connection Wire Wire Color T Signal TX Signal at terminal block TB1. -
Page 7: Page/Party ® 33-Ohm Audio Connections-P2
PLn := Party Line 1..5 60029 Series Page/Party System Cable ® ® Page/Party stations should be connected using GAI-TRONICS 60029 Series system cable. Refer to ® Table 3 for the Page/Party system cable color codes: ® Table 3. Page/Party 60029 Series System Cable... -
Page 8: Channel Isolation Inputs-P3
Pub. 42004-525A ® Model 370-901 SP2 to Page/Party Bridge Page 6 of 16 Channel Isolation Inputs—P3 Table 4. Channel Isolation Channel isolation inputs independently isolate SP2 Input Connections—P3 multicast channel audio from each of the six ® Channel Page/Party audio lines. Activation of an input... -
Page 9: Mute Connection-P5
Application) software. Install the GUDA software and run it to configure Page/Party bridges as follows: 1. Launch the GUDA application by double clicking the GAI-TRONICS Universal Device Application shortcut from the start menu. 2. Choose the network interface to perform the discovery. - Page 10 Pub. 42004-525A ® Model 370-901 SP2 to Page/Party Bridge Page 8 of 16 3. Click the F button to perform a device discovery from the GUDA screen: EVICES 4. Double click the SP2 ® B to configure, from the list of devices displayed:...
-
Page 11: Interface Configuration
Pub. 42004-525A ® Model 370-901 SP2 to Page/Party Bridge Page 9 of 16 Interface Configuration The C screen appears with the I properties shown: ONFIGURATION NTERFACE Configure the following properties for the bridge’s NIC: Interface Name—name for the SP2 to Primary DNS—primary DNS server,... -
Page 12: Channel Configuration
Pub. 42004-525A ® Model 370-901 SP2 to Page/Party Bridge Page 10 of 16 Channel Configuration Click on each channel and configure the properties below. Click the U button in the lower right PDATE corner to confirm and commit the changes. -
Page 13: Guda Status
Pub. 42004-525A ® Model 370-901 SP2 to Page/Party Bridge Page 11 of 16 GUDA Status Click on the STATUS tab on the main GUDA screen to obtain status for the bridge or redundant bridge configuration. Interface Status The I screen provides the following information:... -
Page 14: Channel And Redundant Channel Status
Pub. 42004-525A ® Model 370-901 SP2 to Page/Party Bridge Page 12 of 16 Channel and Redundant Channel Status The C and R screens provide the following information HANNEL TATUS EDUNDANT HANNEL TATUS for each channel: Active—Y or N ... -
Page 15: System Reset
Pub. 42004-525A ® Model 370-901 SP2 to Page/Party Bridge Page 13 of 16 System Reset Hold the GLOBAL DIS press-button switch (S1) on the main PCBA for 8 seconds to reset the SP2 to ® Page/Party Bridge to factory default settings. -
Page 16: Guda Device Administrator Options
Pub. 42004-525A ® Model 370-901 SP2 to Page/Party Bridge Page 14 of 16 GUDA Device Administrator Options The following options are available after clicking the ADMIN button located in the lower right corner of the GUDA configuration screen area: ... -
Page 17: Import Saved Configuration
Pub. 42004-525A ® Model 370-901 SP2 to Page/Party Bridge Page 15 of 16 Import Saved Configuration Click the I button to load a saved configuration to the bridge. MPORT AVED ONFIGURATION : Only designated values that are not device specific are imported. - Page 18 (RA#) will be issued. Equipment should be shipped prepaid to GAI-TRONICS with a return authorization number and a purchase order number. If the equipment is under warranty, repairs or a replacement will be made in accordance with GAI-TRONICS’...
- Page 19 Warranty Equipment. GAI-Tronics warrants for a period of one (1) year from the date of shipment, that any GAI-Tronics equipment supplied hereunder shall be free of defects in material and workmanship, shall comply with the then-current product specifications and product literature, and if applicable, shall be fit for the purpose specified in the agreed-upon quotation or proposal document.
