Purpose

This manual addendum applies to the Solar Boost 3024i family of charge controllers which have received the DUO-Option upgrade part number
Upgrade/3024DUO. This addendum should be used in conjunction with the standard product manuals.
The DUO-Option
The 3024 includes a 20 amp auxiliary output. The basic DUO-Option is a software only upgrade which converts the auxiliary output into a separate
20 amp Diversion type charge controller. The DUO-Option upgrade allows a 3024 to provide Diversion type charge control for hydroelectric, wind
or similar unregulated DC generator type power sources while at the same time providing MPPT type PV charge control.
What is Diversion type charge control?
The core purpose of any charge controller is to prevent battery voltage from exceeding a certain charge voltage setting during charging by reducing
charge current delivered to the battery. A battery will charge if PV modules or a wind generator was connected directly to a battery without a
charge controller, but as battery state of charge rises so does battery voltage. Without a charge controller voltage can rise so high once the battery
is charged that the battery or attached systems may be damaged. The Series Pass type charge control in the 3024's MPPT system reduces current
delivered to the battery when necessary to control battery voltage by reducing the current it draws in from the PV and "passes through" to the
battery. By contrast Diversion type charge control has the power source connected directly to the battery. When charge current needs to be
reduced to control battery voltage the Diversion controller "diverts or redirects" a portion of the power source charge current away from the
battery as the means it uses to limit net battery charge current and control battery voltage. The diverted current is typically dissipated as heat in a
resistive dump load.
Diversion charge control operation
When multiple 3024's are networked together without the Diversion control upgrade they essentially operate as separate PV power controllers
under the direction of a single charge control system. Charge voltage setpoints and all charge control "smarts" reside within the charge control
system. If one or more PV power controllers receives PV input power the charge control system starts and directs the activities of the one or more
PV power controllers to deliver the 3024's sophisticated multi-stage battery charge control. The Diversion control upgrade creates a completely
separate 100Hz Pulse Width Modulation (PWM) Diversion type power controller within the 3024 using the 3024's existing 20 amp auxiliary output.
The Diversion power controller has it's own turn on criteria which is when battery voltage reaches the present charge voltage setpoint (typically
14.4/28.8V). When this battery voltage threshold is reached Diversion turns on (whether PV power is present or not) and the Diversion power
controller as directed by the charge control system begins to divert current to a resistive dump load as necessary to reduce net charge current and
control battery voltage. The charge control system then progresses through it's normal multi-stage charge process to precisely control battery
charge.
Min-Power / Max-Power modes
A key aspect of the Diversion control upgrade is it's coordinated interaction with PV charge control. This interaction allows the user to select
whether minimum or maximum possible power is delivered to the dump load. Note that this coordinated interaction occurs within a 3024 only and
not among multiple 3024's on the IPN network. Min-Power / Max-Power mode is selected with 3024 Dip #4.
Diversion
DIP Switch
Operating
#4
Mode
OFF
Min-Power
(formerly
Mode
Aux
Bat Chg)
ON
Max-
(formerly
Power
Load
Mode
Control)
1
Blue Sky Energy | USA | www.blueskyenergyinc.com
When battery voltage climbs to the present charge voltage setpoint in the Min-Power mode the PV power
controller reduces current delivered to the battery to control battery voltage in the same manner as a standard
3024. The Diversion power controller remains off until the PV power controller is unable to reduce current
enough to control battery voltage. Once PV output is at a minimum, the Diversion power controller begins to
divert current to the dump load to further reduce net charge current and control battery voltage. Min-Power
mode is typically selected when dump load power is not directed towards a useful purpose and minimum dump
load heating is desired. If no generator is present in Min-Power mode a dump load is unnecessary as the PV
power controller alone controls all charge current.
When battery voltage climbs to the present charge voltage setpoint in the Max-Power mode the PV power
controller continues deliver maximum PV power. While maximum PV power production continues, the Diversion
power controller diverts current to the dump load to reduce net charge current and control battery voltage. If the
Diversion power controller is unable to divert enough current to control battery voltage, the PV power controller
will reduce current to assist in controlling battery voltage while the system as a whole delivers as much power as
possible to the dump load. Max-Power mode is typically selected when dump load power is directed towards a
useful purposes such as heating water. The Max-Power mode may be used with PV power alone if the user wishes
to divert PV power not required for battery charging to a useful purpose. Note that a dump load must be present
in Max-Power mode to ensure stable battery voltage control.
SB3024(D)iL-DUO Manual Addendum
For Models: SB3024iL and SB3024DiL – rev. 430-0027 C
Diversion Control Operation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Solar Boost 3024i Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Blue Sky Energy Solar Boost 3024i Series

  • Page 1 SB3024(D)iL-DUO Manual Addendum For Models: SB3024iL and SB3024DiL – rev. 430-0027 C Purpose This manual addendum applies to the Solar Boost 3024i family of charge controllers which have received the DUO-Option upgrade part number Upgrade/3024DUO. This addendum should be used in conjunction with the standard product manuals. The DUO-Option The 3024 includes a 20 amp auxiliary output. The basic DUO-Option is a software only upgrade which converts the auxiliary output into a separate 20 amp Diversion type charge controller. The DUO-Option upgrade allows a 3024 to provide Diversion type charge control for hydroelectric, wind or similar unregulated DC generator type power sources while at the same time providing MPPT type PV charge control. What is Diversion type charge control? The core purpose of any charge controller is to prevent battery voltage from exceeding a certain charge voltage setting during charging by reducing charge current delivered to the battery. A battery will charge if PV modules or a wind generator was connected directly to a battery without a charge controller, but as battery state of charge rises so does battery voltage. Without a charge controller voltage can rise so high once the battery is charged that the battery or attached systems may be damaged. The Series Pass type charge control in the 3024’s MPPT system reduces current delivered to the battery when necessary to control battery voltage by reducing the current it draws in from the PV and “passes through” to the battery. By contrast Diversion type charge control has the power source connected directly to the battery. When charge current needs to be reduced to control battery voltage the Diversion controller “diverts or redirects” a portion of the power source charge current away from the battery as the means it uses to limit net battery charge current and control battery voltage. The diverted current is typically dissipated as heat in a resistive dump load.
  • Page 2 Microprocessor installation (required for field upgrade only) Ø WARNING: The microprocessor or 3024 may be damaged by static electricity. Observe industry standard electrostatic handling precautions. At a minimum discharge yourself by touching grounded metal prior to handling the microprocessor or touching circuits in the 3024. Touch the “BAT-” terminal in the 3024 just prior to removing the old microprocessor or inserting the new microprocessor. The risk of electrostatic damage increases greatly if relative humidity is below 40%. The Microprocessor must be inserted in the proper Pin-1 orientation and all pins must be properly seated into the socket. 1. Remove all sources of power, battery and PV. 2. Carefully remove the old microprocessor with a suitable tool. Take care not to damage the microprocessor socket or other components. 3. Carefully place the new microprocessor p/n 590-0009-01 onto the socket, but do not press into place. Confirm that the Pin-1 end of the microprocessor is in the proper orientation closest to the case wall and that all pins are...
  • Page 3 Minimum Dump Load Resistor Minimum Dump Load Resistor Nominal Battery Voltage 3024’s Auxiliary Output CBM4070 20 Amp Maximum 40 Amp Maximum 12V 0.750 W 0.375 W = 15V BAT-MAX 24V 1.500 W 0.750 W = 30V BAT-MAX Dump Load and optional Current Booster Module wiring The 3024 can directly drive dump loads up to 20 amps. For dump loads of up to 40 amps the optional the Current Booster Module (CBM) part number CBM4070 may be used. The CBM consists of a large optically isolated MOSFET output stage which turns on when a 3 to 32VDC drive signal is present on it’s input. The 3024’s 2A-CHG output is used as the PWM drive signal for the CBM. For dump load needs in excess of 40 amps multiple CBM’s may be driven from a single 3024. For these applications multiple CBM inputs are connected in parallel. CBM outputs must connect to...
  • Page 4 Clamp on ferrite suppressor noise The 3024iL is shipped with two clamp on ferrite suppressors to minimize EMI radiation and susceptibility. One is placed around both battery wires, and the second is placed around the battery temperature sensor and remote display wires. If the 20A Load output drives the dump load directly it is possible that the battery wire suppressor may emit a 100Hz buzzing noise resulting from the 100Hz PWM diversion current. This noise can be eliminated by also routing the dump load wire from the 20A Load output through the battery wire suppressor in the same direction as the battery wires. If wire size is such that all three wires cannot fit through the existing battery wire suppressor an additional suppressor may be used. One suppressor should be placed around the BAT- wire alone. The other should be placed around both the BAT+ wire and the dump load wire. Routing both the BAT+ wire and the dump load wire through the same suppressor in the same direction cancels 100Hz magnetic field in the suppressor which eliminates the noise. Additional suppressors may be ordered as BSE part number 523-0005-01.
  • Page 5 DO NOT INCLUDE THIS PAGE WITH BOUND MANUAL Revision control --- 430-0027 DATE DESCRIPTION 9/17/09 INITIAL RELEASE 9/29/09 Swap min/max Dip #4, add ferrite discussion 6/22/17 General Updating 1/26/19 Updated Logo Blue Sky Energy | USA | www.blueskyenergyinc.com...
