Technical data

General operating conditions of the control components
Ambient temperature
Ambient humidity
Supply voltage
Supply voltage
Power rating
Power rating
Running time for 90°
Setpoint value signal input
Actual value signal output
IEC protection class
Protection level
EC conformity
Supply voltage
Supply voltage
Power rating
Power rating
Running time for 90°
Setpoint value signal input
Actual value signal output
IEC protection class
Protection level
EC conformity
10–50 °C
5–90% rF
Easy controller LMV-D3AL-F
Easy controller 227V-024T-05-013
Control component Easy for VAV terminal units
Technical data
24 V AC ± 20%, 50/60 Hz
24 V DC -10/+20%
3.5 VA max.
Max. 2 W
120–150 s
0 – 10 V DC, Ra > 100 kΩ
0–10 V DC, max. 0.5 mA
III (protective extra-low voltage)
IP 20
EMC to 2014/30/EU
24 V AC ± 20%, 50/60 Hz
24 V DC ± 20%
5 VA max.
Max. 3 W
100 s
0 – 10 V DC, Ra > 100 kΩ
0 – 10 V DC, max. 0,5 mA
III (protective extra-low voltage)
IP 20
EMC to 2014/30/EU
