132 LC100 Instruction manual
1/8 Adresiranje
As long as LC100-D is in any one of the addressing modes, all of the connected dot-matrix signalization modules
will display their assigned address via two interchanging screen images. One of them displays stop number and the
other one displays two characters, left one representing elevator assignment (A, B, C or D), and the right one
representing landing door assignment (A or B).
2/8 ADL200
3/3 DUPLEX
Third way of addressing is for DUPLEX elevators with one button
connected to both displays.
Choosing the wanted address is done with up, down, left and right
button. When pressing the pushbutton one display will be for the „A"
elevator, other one will be for „B" elevator. When pressing pushbutton again
they will change elevator address.
6.4

ADL 200/300 parameters

ADL parameters
In ADL 200 menu it is possible to change parameters in frequency
inverter. Inverter must be connected to CAN comunication.
Parameter description are given in ADL200/300 user manual.
