- Page 1 TEP-1560-BSW MODULAR HMI PRODUCT MANUAL (TEP-1560-BSW) VER. 1.00 March 25, 2019...
- Page 2 TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 REVISION HISTORY Revision Date Originator Notes 1.00 March 25, 2019 TechNexion First public release Page 2 of 39...
-
Page 3: Table Of Contents
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 TABLE OF CONTENTS 1. Introduction ............................... 5 1.1. General Care and Maintenance ......................5 2. TEP-1560-BSW Product Overview ......................6 2.1. Functional Block Diagram ........................6 2.2. Dimensions ............................7 2.3. Device Cut-out Dimensions For Mounting Though a Panel ............... 8 2.4. - Page 4 TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 4.4. M.2 KEY-E Slot ..........................22 4.5. CMOS Jumper ..........................22 4.6. SO-DIMM DDR3L Slot........................22 4.7. Internal Stereo Speaker Connectors ....................23 5. BIOS Setup ............................. 24 5.1. Entering and Exiting BIOS ........................ 24 5.2.
-
Page 5: Introduction
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 1. Introduction 1.1. General Care and Maintenance Your device is a product of superior design and craftsmanship and should be treated with care. The following suggestions will help you. • Keep the device dry. Precipitation, humidity, and all types of liquids or moisture can contain minerals that will corrode electronic circuits. -
Page 6: Tep-1560-Bsw Product Overview
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 2. TEP-1560-BSW Product Overview 2.1. Functional Block Diagram Page 6 of 39... -
Page 7: Dimensions
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 2.2. Dimensions The following figure shows the TEP-1560-BSW dimensions (unit: mm): Page 7 of 39... -
Page 8: Device Cut-Out Dimensions For Mounting Though A Panel
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 2.3. Device Cut-out Dimensions For Mounting Though a Panel The TEP-1560-BSW can be mounted on the front or the back of the panel. In order to mount it from the front, a nominal rectangular cutout must be made in the panel. The following drawing shows the dimensions of the cut-out area (unit: mm): Page 8 of 39... -
Page 9: External Connectors
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 2.4. External Connectors The TEP-1560-BSW has a number of external connectors. Bottom view: 1 2 4 5 6 8 10 11 12 14 15 16 17 18 19 20 21 External Connectors: Description Description LED Light indicator... -
Page 10: Internal Board Connectors
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 2.5. Internal Board Connectors The TEP-1560-BSW has several connectors, switches and internal expansion options. 2.5.1. Galvanic Isolated (TEP1560-xxxxx-Rxx-Lxxx-XG21- xxxx-xxx-xxxx-xxxx) Rear view (opened device) with the galvanic isolated I/0 Expansion module: Power I/O Expansion Module Module... -
Page 11: Non-Galvanic Isolated (Tep1010-Xxxxx-Rxx-Lxxx-Xs21-Xxxx-Xxx-Xxxx-Xxxx)
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 2.5.2. Non-Galvanic Isolated (TEP1010-xxxxx-Rxx-Lxxx-XS21-xxxx-xxx-xxxx-xxxx) Rear view (opened device) with the non-galvanic isolated I/0 Expansion module: Power I/O Expansion Module Module E F G Internal Connectors and Switches: Description Description M.2 KEY-B slot (SATA + USB 2.0) RTC Battery connector M.2 KEY-B slot (USB 2.0) M.2 KEY-E slot (PCIe + USB 2.0) -
Page 12: External Connectors
Expansion Options of this manual. No M.2 KEY-B 3G/LTE module is included in this device (must be purchased separately, not sold by TechNexion). 3.3. MicroSD Connector The TEP-1560-BSW features a standard microSD cardslot which is connected to the Intel processor’s (Atom x5-E8000 / Pentium N3710) integrated “Ultra Secured Digital Host Controller”... -
Page 13: Usb Otg (Type-C) Connector
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 3.4. USB OTG (Type-C) Connector The TEP-1560-BSW has one USB OTG Type-C connector (USB 2.0 and USB 3.0 signals) that can be used to connect a host computer to the unit for programming and update purposes. Signal Description Signal... -
Page 14: Usb 3.0 Host Connectors
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 3.7. USB 3.0 Host Connectors The TEP-1560-BSW has two USB 3.0 Host connectors (USB 2.0 and USB 3.0 signals) to connect to a USB peripheral such as a keyboard, mouse, USB storage device or USB hub. 3.8. -
Page 15: Power Input Connector
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 3.13. Power Input Connector The TEP-1560-BSW can be powered either over the DC INPUT connector or PoE (optional) over the RJ45 LAN1 port. NOTE: Do not power the unit by DC input when you apply power over the Power over Ethernet (RJ45)! Pin # Signal Description... -
Page 16: Galvanic Isolated Digital I/O Connectors (Gpio1/Gpio2) (Optional)
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 3.15.1. Galvanic Isolated Digital I/O Connectors (GPIO1/GPIO2) (optional) The galvanic isolated GPIO Expansion headers have the following pinout: GPIO1: Signal Description Voltage Curr Interfa Control Pin # Min. Typ. Max. Max. Source GPIO1A DIG_IN1... -
Page 17: Galvanic Isolated Serial Port (Rs-Xxx) (Optional)
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 3.15.2. Galvanic Isolated Serial Port (RS-XXX) (optional) The dual 4-wire galvanic isolated serial port can be configured as follows: the primary serial port can only be used as a standard RS-232. The secondary port can be configured either as RS-232, or RS-422 or RS-485. -
Page 18: Non-Galvanic Isolated Connectors (Tep1560-Xxxxx-Rxx-Lxxx-Xs21- Xxxx-Xxx-Xxxx-Xxxx) (Optional)
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 RS-232 + RS-422: Pin # Signal Description Device SERIAL1A Identical as above COM1 Ground SERIAL1B_TXD+ RS-422 Transmit positive data signal (output) COM2 SERIAL1B_RXD- RS-422 Receive negative data signal (input) COM2 SERIAL1B_RXD+ RS-422 Receive positive data signal (input) COM2 SERIAL1B_TXD-... -
Page 19: Non-Galvanic Isolated Digital I/O Connectors (Gpio1/Gpio2) (Optional)
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 3.16.1. Non-Galvanic Isolated Digital I/O Connectors (GPIO1/GPIO2) (optional) The non-galvanic isolated GPIO Expansion headers have the following pinout: GPIO1: Signal Description Voltage Curr Interfa Control Pin # Min. Typ. Max. Max. Source GPIO1A DIG_IN1/OUT1... -
Page 20: Non-Galvanic Isolated Serial Port (Rs-Xxx) (Optional)
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 3.16.2. Non-Galvanic Isolated Serial Port (RS-XXX) (optional) The dual 4-wire non-galvanic isolated serial port are configured as follows: the primary and the secondary serial port can only be used as a standard RS-232. RS-232 + RS-232: Pin # Signal... -
Page 21: Internal Connectors And Expansion Options
NOTE: M.2 3G/LTE connector can be only used by a M.2 KEY-B 3G/LTE module installed into the M.2 connector (Marked B). No M.2 KEY-B 3G/LTE module is included in this device (must be purchased separately, not sold by TechNexion). 4.2. SATA 3.0 and SATA Power Connectors The TEP-1560-BSW has one internal SATA 3.0 connector (Marked C) for connecting to a SATA storage... -
Page 22: Rtc Battery Connector
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 4.3. RTC Battery Connector The TEP-1560-BSW features an internal RTC backup battery connector (Marked F). Pin # Signal Description RTC_VCC 3V (connect to standard CR2032 battery) Ground Header on TEP-1560-BSW: Molex 53047-0210 (1.25mm Pitch PicoBlade Wire-to-Board Header). Cable receptacle: Molex 051021-8602 (1.25mm Pitch PicoBlade Wire-to-Wire and Wire-to-Board Housing) plug with crimp contact Molex 50058-8000. -
Page 23: Internal Stereo Speaker Connectors
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 4.7. Internal Stereo Speaker Connectors The TEP-1560-BSW has two internal stereo speaker connectors to connect to two optional LEFT and RIGHT speakers (Marked J and I respectively). The signal is pre-amplified with a 2W Texas Instruments TPA2025D Class-D stereo audio amplifier. -
Page 24: Bios Setup
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 5. BIOS Setup The BIOS (Basic Input / Output System) firmware comes pre-installed on the TEP-1560-BSW. The AMI UEFI BIOS is a non-volatile firmware used to perform hardware initialization during the booting process and provides a basic level of communication between the processor and peripherals. -
Page 25: Main
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 5.2.1. Main By default, the Main screen appears when you enter the BIOS setup program. Main screen contains basic system information, including BIOS type, processor, memory, and time/date. Page 25 of 39... -
Page 26: Chipset
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 5.2.2. Chipset The Chipset screens contain North Bridge and South Bridge configuration options. Page 26 of 39... -
Page 27: Advanced
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 5.2.3. Advanced The BIOS Advanced screens provide detailed configuration information for the OS, POST Watchdog Timer, SATA, SDIO, Super IO, GPIO PORT and other system information. NOTE: Setting incorrect or conflicting values in Advanced BIOS setup may cause system malfunction or inability to boot. - Page 28 TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 Super IO Configuration Screen Name Options Description Serial Port X Enable Enable or Disable Serial Port (COM) Disable Change Settings Auto Select an optimal setting for Super IO Device IO=3F8h; IRQ=4; IO=3F8h;...
- Page 29 TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 BIT5 = GPIO15 BIT6 = GPIO16 BIT7 = GPIO17 Write IO port 0x2E -> 0xE1 Write IO port 0x2F -> // 0 : Output 0, 1 : Output 1 when in Output mode BIT2 = GPIO12 BIT5 = GPIO15 BIT6 = GPIO16...
-
Page 30: Boot
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 5.2.4. Boot The Boot screens contain device priority boot options. Restore AC Power Loss Screen Name Options Description Restore AC Power Loss Power Off Select AC power state when power is re- applied after a power failure Power On Last State... -
Page 31: Security
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 5.2.5. Security The Security screens contain the administrator and user passwords settings. Page 31 of 39... -
Page 32: Save & Exit
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 5.2.6. Save & Exit The Save & Exit screens contain save and exit options. Save & Exit Screen Name Options Description Save & Exit Save Changes and Reset Save changes and exit, discard changes and exit, or discard changes Discard Changes and Reset... -
Page 33: Mounting
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 6. Mounting This section describes the mounting procedures for the TEP-1560-BSW. The material in area of the mounting must provide sufficient strength for safe mounting of this device. 6.1. VESA Mounting The TEP-1560-BSW is compatible with the VESA MIS-D Standard 100*100mm hole pattern. -
Page 34: Rear Mounting And Mounting Clips Installation
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 6.2. Rear Mounting and Mounting Clips Installation There are 14 mounting clips required for rear mounting. Please follow the steps below to secure the clips. Prepare mounting hook, post and screw (M3) (Step 1). Locate all removable tabs on the rear side of your device and use pincers or pliers to remove the tabs (Step 2-3). -
Page 35: Surface Mounting
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 6.3. Surface Mounting There are 16 mounting holes (M4) on the rear side of the device required for surface mounting. M4 screws with at least 6mm head-to-tip length are required to secure this device. Page 35 of 39... -
Page 36: Ordering Information
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 7. Ordering Information The TEP-1560-BSW is available in several configurations. Please contact your TechNexion sales contact window or distributor for options and availability details. 7.1. Custom Part Number Rule The TEP-1560-BSW can be ordered in custom tailored configuration to meet special application requirements and conditions according to the following custom part number creation rules. -
Page 37: Standard Package Contents
TEP-1560-BSW HARDWARE MANUAL – VER 1.00 MAR 25 2019 7.2. Standard Package Contents Item Partnumber Description TEP-1560-BSW 15.6 inch PoE HMI PCAP touch system with Intel Braswell Accessoires 14x mounting hooks 14x short screws (M3) 14x mounting posts 2x Wi-Fi/LTE module screw 2x screw (M3) for M.2 card 2x plastic washer 1x DC power latch cable (2-pin Micro-Fit 3.0) -
Page 38: Important Notice
Information published by TechNexion regarding third-party products or services does not constitute a license from TechNexion to use such products or services or a warranty or endorsement thereof. Use of such information may require a license from a third party under the patents or other intellectual property of the third party, or a license from TechNexion under the patents or other intellectual property of TechNexion. -
Page 39: Disclaimer
To the extent permitted by law no liability (including liability to any person by reason of negligence) will be accepted by TechNexion Ltd., its subsidiaries or employees for any direct or indirect loss or damage caused by omissions from or inaccuracies in this document.
