K-Drill Ice Auger Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Please read this manual and follow its instructions carefully. The words
WARNING, CAUTION, and IMPORTANT carry special meanings and should be
carefully reviewed.
WARNING
-
warnings and instructions listed could result in serious injury or death to
self or others.
CAUTION
-
procedures or precautions that must be followed to avoid damaging the
augers, injuries to self and others.
IMPORTANT - This provides special information to make usage of the K-Drill
easier and important instructions more clear.

Table of Contents

Introducing the K-Drill Ice Auger
Efficiency and light weight performance best describes the K-Drill Ice Auger. Both
the 6" and 8" K-Drill Ice Augers are designed to be driven with rechargeable elec-
tric drills or gas power heads.
The unique center tip and high carbon steel chipper blades allow for quick and
clean holes under all ice conditions. K-Drill will also work exceptionally well when
re-opening existing holes.
The K-Drill has its own flotation system to prevent it from sinking down the hole if
it should come detached from the drill. The 6-inch K-Drill Ice Auger cuts a 6" hole.
However, the 8-inch K-Drill cuts a 7-1/2" hole.
Failure
to
These
instructions
read,
understand
point
1
3
3
4
Limited Warranty
5
6
K-Drill Patent #7,946,355
8
Owner's Manual
and
follow
out
special
all
safety
9
10
11
11
13
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ice Auger and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for K-Drill Ice Auger

Summary of Contents for K-Drill Ice Auger

  • Page 1: Table Of Contents

    K-Drill will also work exceptionally well when re-opening existing holes. The K-Drill has its own flotation system to prevent it from sinking down the hole if it should come detached from the drill. The 6-inch K-Drill Ice Auger cuts a 6” hole. However, the 8-inch K-Drill cuts a 7-1/2” hole.
  • Page 2 Drill Drive Adapter (#IDRL28) Safety Float (#IDRLFLT) Thermal Wrap (#LBLA02) Locking Collar (#IDRL19) Modular Flighting (Patent Pending) 6” - #IDRL17 8” - #IDRL48 Head Replaceable Blade Set Each set uses two chipper blades and one center tip blade. 6” Blade Set (#IDRLBL6) 8”...

  • Page 3: Drill Setup

    IMPORTANT - At the end of the ice fishing season, before storing for summer, please spray WD-40 on the blades. This simple maintenance prevents rusting during storage. Also, K-Drill offers free blade sharpening. See page 9 for details. CAUTION - Always place protective cover over blades when not drilling.

  • Page 4: Drilling Ice Holes

    IMPORTANT: At no time is it safe to insert the K-drill into the chuck and pow- er-up the drill to tighten it onto the shaft. The same also holds true of removing the K-drill from the chuck. Do it manually for your own safety and the safety of others.

  • Page 5: Redrilling Holes

    Owner’s Manual Redrilling of Holes in the Ice Before explaining how to re-drill an old hole you must first understand how an existing hole refreezes. 1) It will begin refreezing from the top and outside edges 2) As it continues to freeze, the ice will continue thickening in from the sides with more ice at the top of the hole than the bottom 3) Given enough time and the right freezing con- ditions the hole would become a solid water...

  • Page 6: Safety & Usage Tips

    • KEEP the drill battery in a warm location prior to use in colder conditions. Keep spare batteries warm as well. • INSPECT your K-Drill auger periodically. If damaged, have it repaired or re- placed by an authorized service facility.
  • Page 7 New Stem Stripped Stem Storage & Maintenance Make sure to store the K-Drill auger in a safe location, and out of reach of children and animals. MAKE SURE THE SAFETY COVER IS IN PLACE DURING STORAGE! At the end of the ice fishing season before storing for summer, spray WD-40 on...

  • Page 8: Replacing The Blades

    6) Torque bolt of center tip to 115 in/lbs. K-Drill Extension Installation The standard K-Drill can drill through up to 36” of ice. The K-Drill extension can be added for thicker ice conditions. Extensions can be “stacked” if needed to create a very long ice auger.

  • Page 9: Free Lifetime Sharpening

    Owner’s Manual Free Lifetime Blade Sharpening* *Blade sharpening for the K-Drill is FREE unless the blades have been abused drilling into rock, gravel, sand, etc., or until the blades can no longer be sharpened. Refer to the warranty policy at the back of this manual.

  • Page 10: Parts & Accessories

    Parts and Accessories To purchase other parts and accessories for the K-Drill Ice Auger Systems please contact K-Drill customer service at 952-224-3649 or visit kdrillauger.com to place an order online. Replacement Parts IDRLBL6: 6” Replacement Blades (Set of 3 blades) IDRLBL8: 8”...

  • Page 11: Cordless Drill Requirements

    5) 500-750 RPM with a minimum of 6) 725 in/lbs of torque (or higher) Most of the Milwaukee M18 fuel series and most DeWalt MX XR series can be used with the K-Drill. Before you buy, please visit kdrillauger.com to see...
  • Page 12 Wear Truckers Cap 2-tone grey and black with Hoody Sweatshirt K-Drill embroidered logo, mesh top with snap back. Our charcoal K-drill hoodies #KAP002 are definitely one of the • Grey / Black heaviest and warmest • Mesh top hoodies around. • Snap back • Screen printed logo •...
