Summary of Contents for Apposite Linktropy Mini-G
- Page 2 Los Angeles, CA 91316 USA 1.310.477.9955 info@apposite-tech.com www.apposite-tech.com Copyright ©2005-2017 Apposite Technologies LLC. All rights reserved. Apposite, Linktropy, and Netropy are registered trademarks of Apposite Technologies LLC. The Apposite logo and “WAN Emulation Made Easy” are trademarks of Apposite Technologies LLC. Part No. DOC-HG-LMG-P13...
-
Page 3: Table Of Contents
3 Front and Rear Panels ............................. 6 3.1 Front Panel ............................6 3.2 Rear Panel ............................7 4 Console Interface ............................8 5 Apposite Support ............................9 Appendix A: Specifications ..........................10 Appendix B: Regulatory ............................ 11 Federal Communications Commission Notice ..................11 Canadian Notice / Avis Canadien ...................... -
Page 4: Overview
VERVIEW This Linktropy Mini-G Hardware Guide describes the physical hardware of the Linktropy Mini-G WAN Emulator. The companion User’s Guide describes the installation, configuration, and operation of the Linktropy Mini-G WAN emulation functionality. A separate Quick Start Guide provides a walk-through for first time configuration. -
Page 5: Included Items
NCLUDED TEMS The Linktropy Mini-G shipping carton contains the following items: Linktropy Mini-G hardware unit Linktropy Mini-G Quick Start Guide AC power adaptor RS-232 DB-9 serial cable NCLUDED TEMS... -
Page 6: Front And Rear Panels
RONT AND ANELS 3.1 Front Panel The front panel of the Linktropy Mini-G contains: Power LED: Lit green when the unit is powered on. Unlit when power is off. RONT AND ANELS... -
Page 7: Rear Panel
3.2 Rear Panel The rear panel of the Linktropy Mini-G contains: CONSOLE: Console interface using RS-232 with a DB-9 connector. MGMT: 10/100/1000baseT Ethernet interface with a standard RJ-45 plug for browser-based management of the unit over the network. LAN A: 10/100/1000baseT Ethernet interface with a standard RJ-45 plug. Connects to the network segment functioning as LAN A in network emulations. -
Page 8: Console Interface
ONSOLE NTERFACE Console access to the Linktropy Mini-G is through the RS-232 interface on the rear panel labeled “ .” A DB-9 cable is included with the unit to connect the device to a standard PC serial CONSOLE port. The pin-out for the DB-9 connector is shown below:... -
Page 9: Apposite Support
PPOSITE UPPORT Purchase of the Linktropy Mini-G includes a 1 year warranty on the hardware, 1 year maintenance, and 90 days of customer support. If you believe your unit is not functioning properly and is under warranty, please upgrade to the latest firmware release. -
Page 10: Appendix A: Specifications
A: S PPENDIX PECIFICATIONS Capacity Max. Emulation Rate 1 Gbps full duplex Max. Packet Rate 350,000 packets per second with 64 byte packets Interfaces Network 2 x 10/100/1000baseT Ethernet Management 1 x 10/100/1000baseT Ethernet Console 1 x RS-232 Environmental and Physical DC Input 12V DC power AC Input... -
Page 11: Appendix B: Regulatory
B: R PPENDIX EGULATORY Federal Communications Commission Notice This equipment has been tested and verified to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 12: Appendix C: Linktropy End User License Agreement
Limited Warranty Apposite warrants that for a period of one (1) year from the date of shipment of the Hardware to you (“Warranty Period”), the Hardware will be free of any defects in materials and workmanship under normal use and the Software will perform substantially in accordance with the Documentation. - Page 13 Agreement. Apposite and its suppliers’ entire liability and your sole and exclusive remedy shall be, at Apposite’s sole discretion, to (i) repair the Software or Hardware; (ii) provide replacement Hardware or Software; or (iii) refund the purchase price and terminate this Agreement.
- Page 14 No amendment to or modification of this agreement are binding unless in writing and signed by Apposite. Third Party Acknowledgements Portions of the Software utilize or include third party software and other copyrighted material.
- Page 15 Apposite ® Technologies LLC 17835 Ventura Blvd., Suite 211 Los Angeles, CA 91316 USA 1.310.477.9955 info@apposite-tech.com www.apposite-tech.com...
