Installation instructions

System requirements/connections

The following system requirements and connections must be
available and enabled in advance in order to use the Smart
Friends system:
Router
- DHCP server with a free LAN connection (RJ-45 socket).
Another free LAN connection must be available to connect
the ABUS Smartvest wireless alarm system.
- Wi-Fi (home network) enabled for local control
- Internet enabled for the Remote Home function*
Connections on the Smart Home Box
1 2
1
Power supply socket for connecting the power
supply unit
2
RJ-45 socket for connection to a suitable router
via LAN cable
3 Reset button
Press and hold for one second: a) Box restarts
b) Reset password: To reset the password, the user
must log in with the following user data:
User: Admin
Password: Admin

Scope of delivery

Smart Friends Box
14 x 14 cm
6
3 4
LAN cable
200 cm
Smartphone/tablet
- Apple iOS device, iOS8 or higher
- Android device, Version 4.4 or higher
- Connection with home network (Wi-Fi see "Router") enabled
- Mobile internet enabled for the Remote Home function*
- Smart Friends app installed
* Note: To be able to control your Smart Friends system
outside your local Wi-Fi network, you need the Remote Home
function. You can find information about how to buy this on
page 21.
For the Remote Home function, the internet connection to
your router and to your smartphone and tablet must be ena-
bled. When using the internet, you may incur additional costs
from your internet provider/service provider.
within 10 minutes of pressing the reset button. After that, the
user is asked to set a new password. For security reasons, the
function is not available via the "Outdoor Control" function.
The user must be physically in front for the box to press the
reset button, and must be on their home Wi-Fi. After chang-
ing the password, it is only possible to log in again with the
above-mentioned user data after pressing the reset button.
Press and hold for ten seconds: Reset the box to the factory
settings
4
USB socket
* Note: Only use the Smart Friends Box with the original
power supply unit. The power supply unit is designed solely
for connection to the Smart Friends Box.
Power supply unit
AC / 230V
