Installation instructions
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Box and is the answer not in the manual?

Questions and answers

Summary of Contents for Smart Friends Box

  • Page 1 Installation instructions...

  • Page 2: Table Of Contents

    Pairing Schellenberg wireless awning drive Plus SC8: System requirements/connections Pairing Schellenberg wireless awning drives/ wireless awning motors Connections on the Smart Friends Box SC9: Pairing Schellenberg garage door drive Scope of delivery Smart Drive Premium SC10: Pairing Schellenberg wireless socket...

  • Page 3: Security And Information

    - The Smart Friends Box may only be used with the original power supply unit delivered. - Use the product at an easily accessible socket.

  • Page 4: Intended Use

    ABUS, from the warranty: Paulmann, Schellenberg and Steinel. These are labelled as being ‘Ready for Smart Friends’. - incorrect installation of the product - Only use the product in dry environments (protection class - failure to observe the operating and installation instructions IP20).

  • Page 5: Eu Declaration Of Conformity

    ABUS August Bremicker Söhne KG hereby declares that this Do not dispose of the product with household type of wireless system, Smart Friends Box, complies with waste. The product is recyclable and can be Directive 2014/53/EU. The full EU Declaration of Conformity taken to a recycling centre or a collection point text can be found at: http://www.abus.com...

  • Page 6: System Requirements/Connections

    For security reasons, the function is not available via the “Outdoor Control” function. The user must be physically in front for the box to press the reset button, and must be on their home Wi-Fi. After chang-...

  • Page 7: Start-Up

    Installation instructions A: Start-up 230V 50 Hz...

  • Page 8: 2: Initial Setup

    Installation instructions 2: Initial setup Download the "Smart Friends" app from the App Store Install the app on your smartphone or tablet. or the Google Play Store. https://appsto.re/ https://play.google. de/6lLdab.i com/store/apps/ details?id=de. smart_friends. smarthome&hl=de Follow the download Install the app according instructions.
  • Page 9 Installation instructions Give your smartphone or tablet a name here to be able to As soon as the Smart Friends Box has been found, save your use the “Push notifications” function. In the scenes, you can personal password. Make a note of your password here: choose which device you want to receive push notifications.
  • Page 10 Installation instructions Control mode enabled, by pressing Switch Stop button to control mode. Programming mode enabled, by pressing Switch Scroll down button to programming mode. On button Choose icon for devices, rooms and scenes. Change settings of devices, rooms and scenes. Off button Devices: A scene can be performed by triggering Delete devices, rooms and scenes.

  • Page 11: 3: Setting Up Rooms

    Installation instructions 3: Setting up rooms Rooms are already created Scroll down screen to make it easier to start configuring the app. The settings for the rooms can be changed at any time.
  • Page 12 Installation instructions Name room...

  • Page 13: 4: Pairing Devices

    Installation instructions 4: Pairing devices Please refer to the chapters from the four manufacturers, ABUS, Paulmann, Schellenberg and STEINEL.

  • Page 14: 5: Setting Up Scenes

    Installation instructions 5: Setting up scenes Paired devices in the rooms can be networked above the level of rooms and controlled at the same time within a scene. A status is defined for each device (e.g. roller shutter up, light on), which is then performed after triggering the scene.
  • Page 15 Installation instructions Name scenes Name scenes Create a manual scene: Begin at step E10 Select the desired type of automation. Create an automated scene: Begin at step E5 For a guide to the icons, see page 10. Example: Timer...
  • Page 16 Installation instructions Adjust personal settings Icons for the specified automation white: enabled grey: disabled, scene can only be triggered manually Scroll down screen Scroll down screen 5.10 Other types of automation can be specified. Other types of automation can be specified. And-link: All the conditions must be met.
  • Page 17 Installation instructions 5.11 5.12 Select and save the devices in the rooms Specify the device status that should be that are to be added. achieved after triggering the scene. 5.13 5.14 Save the scene created. A scene can be triggered manually at any time. Activated automation is displayed.

  • Page 18: 6: Setting Up The Home Status

    Installation instructions 6: Setting up the home status The home status provides an overview of all the devices that have a pre-defined critical sta- tus. A different critical status can be set for each individual device.

  • Page 19: 7: Menu

    Installation instructions 7: Menu...

  • Page 20: Icons In Menu

    Tips & tricks: Useful information about configuring and using the Smart Friends system. Log out: Close the app. Icons in System Information: Details of the Smart Friends app and the Smart Home Alarm Panel. Licences Reset system: Delete app data and restore factory settings.

  • Page 21: 8: Buying The Remote Home Function

    Follow the shop’s menu guidance. Once the purchase has been completed, the function is automatically enabled. For security reasons, each user must connect to the Smart Friends Box from with- in their home Wi-Fi at least once before they can use the Remote Home function.

  • Page 22: 9: Alexa Integration

    It will be free for 6 months. The Alexa voice assistant shall be activated now. Activate Devices for Voice Assistance. Please complete your configuration within the Smart Friends app. Finalize all item and scene settings. Each device or scene that...
  • Page 23 You can now synchronize Please change to scenes the configuration of the menu and choose the scene Smart Friends App with your likely to activate for your Alexa Echo. voice assistance. Hook-up Voice Assistance and save your settings.
  • Page 24 Alexa App instructions. 9.11 9.12 To active the Smart Friends skill change back to the Please change back to the Amazon Alexa App and Smart Friends App and pick under Settings > Exten- hit activate under the Smart Friends skill.
  • Page 25 9.14 Please insert the copied Token number of You shall now have successfully activated the Voice assistance module. your Smart Friends skill. 9.15 9.16 Synchonized devices and scenes with Amazon Alexa Else you can say: “Alexa, search my new devices”.
  • Page 26 Smart Home > Groups and create new the Amazon Alexa App, the devices will still stay within groups to assign the the Smart Friends App con- preferred devices to it. figuration. 9.19 9.20 Choose New Group Hook-up the preferred devices for each group.
  • Page 27 Installation instructions 9.21 9.22 The group you have set up acts like a single device, e.g. a Please find further instructions under Settings >Tips & Tricks > Alexa. whole group can be dimmed alternately to varying degrees or the colour can be changed across the group. Note: In comparison to groups, scenes support one individually set value per de-...

  • Page 28: To The Smart Friends Box

    Installation instructions 10: Connecting ABUS products to the Smart Friends Box 10.1 10.2 Smartvest Alarm Panel: Open the “Rooms” view. Select the Smartvest icon. The three fields for the name, Select the pencil icon to switch to the programming mode.
  • Page 29 For each component, select a room where it is installed. The display in the Smart Friends app is based on the allocations made here. Tip: If the desired room has not yet been created, select the room “Service”.
  • Page 30 Tip: In principle, cameras that are already connected to the because it is not connected to a Smartvest, please follow the Smartvest can be imported into the Smart Friends Box in the instructions in this chapter. The learning process is identical to same way as all the other components.
  • Page 31 Installation instructions 10.8 The Smart Friends Box automatically looks for a compatible camera in the local network. If a compatible camera is found, this is displayed to Important note: If the device security code you with the DID (CGAG- XXX-XXX). The standard...

  • Page 32: A1: Abus Products In The "Rooms" View

    ABUS product and the Smart Friends Box is complete. From now on, the Smart Friends Box receives information from Alarm: inactive, active the Smartvest and/or camera and displays this in your Smart Friends app.
  • Page 33 Installation instructions A1. 3 Smartvest Opening Detector/Motion Detector Tip (opening detector): All “Low battery” messages must be acknowledged in the Smartvest app. Status: Open/closed Tip (motion detector): The Smartvest Motion Detector has Failure: No, Low battery, an energy-saving mode. Once movement has been detected, the status remains on “Movement”...
  • Page 34 Installation instructions A1.5 Smartvest component settings: Select the pencil icon to switch to the programming mode. Then select the gear icon to switch to the specif- ic component’s settings. Changes can be made to the icon, name and room Links: All scenes with this product A1.6 Camera in the Rooms view...
  • Page 35 The way the camera functions Last image: Date and time in combination with the Smart of the last image taken Friends Box is different from how it functions in combination with App2Cam or the Smartvest app. A1.8 A1.9...
  • Page 36 Forward: Switch to next image Back: Switch to previous Important note: If the Smart image Friends Box’s memory is full, old Changes to the images are automatically overwrit- “Image archive” view ten (circular buffer). A1.12 In the programming mode, you can select images and then delete them using the relevant button or export them to your smartphone/tablet.
  • Page 37 Installation instructions A1.13 A1.14 Select the pencil icon to switch to the programming mode. Links: Then select the gear icon to switch to the camera’s settings. Changes can be made to the icon, name and room Links: All scenes with this product.

  • Page 38: A2: Abus Products In The "Scenes" View

    Installation instructions A2: ABUS products in the “Scenes” view A2.1 Smartvest Alarm Panel: The following conditions can be used Smartvest Alarm Panel: The following conditions can be used as a trigger in the IF section of the scene: as an actuator in the THEN section of the scene: Operating mode: part set, disarm or arm Operating mode:...
  • Page 39 Installation instructions A2.3 A2.4 Smartvest Motion Detector: The following conditions can be Smartvest Smoke Detector: The following conditions can be used as a trigger in the IF section of the scene: used as a trigger in the IF section of the scene: Motion detector: Smoke detector: Movement, No movement...
  • Page 40 Installation instructions A2.6 Smartvest Camera: The following conditions can be used as a Smartvest Camera: The following conditions can be used as an trigger in the IF section of the scene: actuator in the THEN section of the scene: Archive: No new image, new image Failure: No connection, incorrect password...

  • Page 41: A3: Abus Products In The "Home Status" View

    Installation instructions A3: ABUS products in the “Home status” view A3.1 In the Home status view, you are given an overview of all the components whose current status is classed as “critical”. If their status changes to “non-critical”, the components will no longer be included in this overview.

  • Page 42: Sc1: Pairing Schellenberg Products

    Installation instructions SC1: Pairing Schellenberg products SC1.1 SC1.2 Select the Schellenberg device that you would like to pair. SC1.3 SC1.4...

  • Page 43: Sc2: Pairing Schellenberg Wireless Roller Shutter Belt Drive Premium

    Installation instructions SC2: Pairing Schellenberg wireless roller shutter belt drive PREMIUM SC2.1 SC2.2 SC2.3 SC2.4 Name device Save device name Pair device SC2.5 SC2.6 Pair the device directly or select the already-paired wireless transmitter that you want to copy. Example: direct pairing. Carry out the steps shown and confirm.
  • Page 44 Installation instructions SC2.7 SC2.8 SC2.9 SC2.10 Exit the programming mode. Control the product via the Rooms view. SC2.11 SC2.12 SC2.13 SC2.14 Open the menu for further Select the detail view for You can use the roller shutter control options. further control options. (A), the arrow buttons (B) or the percentage figure (C) to control the device.

  • Page 45: Sc3: Pairing Schellenberg Wireless Tubular Motor

    Installation instructions SC3: Pairing Schellenberg wireless tubular motor SC3.1 SC3.2 SC3.3 Name device Save device name Pair device SC3.4 SC3.5...
  • Page 46 Installation instructions SC3.6 SC3.7 SC3.8 Exit the programming mode. SC3.9 SC3.10 SC3.11 Control the product via the Select the detail view for You can use the roller shut- Rooms view. further control options. ter (A) or the arrow buttons (B) to control the device.

  • Page 47: Sc4: Pairing Schellenberg Wireless Reception Switch

    Installation instructions SC4: Pairing Schellenberg wireless reception switch SC4.1 SC4.2 SC4.3 SC4.4 Name device Save device name Pair device SC4.5 SC4.6 Pair the device directly or select the already-paired wireless transmitter that you want to copy. Example: direct pairing. Carry out the steps shown and confirm.
  • Page 48 Installation instructions SC4.7 SC4.8 SC4.9 SC4.10 SC4.11 SC4.12 SC4.13 SC4.14...
  • Page 49 Installation instructions SC4.15 SC4.16 SC4.17 Exit the programming mode. The roller shutter’s travel times can be readjusted in the settings at any time. SC4.18 SC4.19 SC4.20 Control the product via the Open the menu for further Rooms view. control options.
  • Page 50 Installation instructions SC4.21 SC4.22 Select the detail view for You can use the roller shutter (A), the further control options. arrow buttons (B) or the percentage figure (C) to control the device.

  • Page 51: Sc5: Pairing Schellenberg Wireless Reception Module

    SC5.2 SC5.3 Name device Save device name Pair device Note: If direct pairing with the Smart Friends Box is carried out, any paired handheld transmitters are deleted. If paired handheld transmitters need to be retained, please select the “roller shutter” icon (cf.
  • Page 52 Installation instructions SC5.8 SC5.9 SC5.10 SC5.11 Exit the programming mode. SC5.12 SC5.13 SC5.14 Control the product via the Select the detail view for You can use the roller shutter Rooms view. further control options. (A) or the arrow buttons (B) to control the device.

  • Page 53: Sc6: Pairing Schellenberg Wireless Roller Shutter Drives

    Installation instructions SC6: Pairing Schellenberg wireless roller shutter drives SC6.1 SC6.2 SC6.3 Name device Save device name Pair device SC6.4 SC6.5...
  • Page 54 Installation instructions SC6.6 SC6.7 SC6.8 Exit the programming mode. SC6.9 SC6.10 SC6.11 Control the product via the Select the detail view for You can use the roller shutter (A) Rooms view. further control options. or the arrow buttons (B) to control the device.

  • Page 55: Sc7: Pairing Schellenberg Wireless Awning Drive Plus

    SC7.3 Name device Save device name Pair device Note: If direct pairing with the Smart Friends Box is car- ried out, any paired handheld transmitters are deleted. If paired handheld transmitters need to be retained, please select the “awning” icon (cf.
  • Page 56 Installation instructions SC7.7 SC7.8 SC7.9 Exit the programming mode. SC7.10 SC7.11 SC7.12 Control the product via the Select the detail view for You can use the slider (A) Rooms view. further control options. or the arrow buttons (B) to control the device.

  • Page 57: Sc8: Pairing Schellenberg Wireless Awning Drives/ Wireless Awning Motors

    Installation instructions SC8: Pairing Schellenberg wireless awning drives/ wireless awning motors SC8.1 SC8.2 SC8.3 Name device Save device name Pair device SC8.4 SC8.5...
  • Page 58 Installation instructions SC8.6 SC8.7 SC8.8 Exit the programming mode. SC8.9 SC8.10 SC8.11 Control the product via the Select the detail view for You can use the slider (A) Rooms view. further control options. or the arrow buttons (B) to control the device.

  • Page 59: Sc9: Pairing Schellenberg Garage Door Drive Smart Drive Premium

    Installation instructions SC9: Pairing Schellenberg garage door drive Smart Drive PREMIUM SC9.1 SC9.2 SC9.3 SC9.4 Name device Save device name Pair device SC9.6 SC9.5 Pair the device directly or select the already-paired wireless transmitter that you want to copy. Example: direct pairing. Carry out the steps shown and confirm.
  • Page 60 Installation instructions SC9.7 SC9.8 SC9.9 SC9.10 Exit the programming mode. Control the product via the Rooms view. SC9.11 SC9.12 SC9.13 SC9.14 Open the menu for further Select the detail view for You can use the door (A), the control options. further control options.

  • Page 61: Sc10: Pairing Schellenberg Wireless Socket

    Installation instructions SC10: Pairing Schellenberg wireless socket SC10.1 SC10.2 SC10.3 SC10.4 Name device Save device name Pair device SC10.5 SC10.6 SC10.7 Example: direct pairing. Pair the device directly or se- lect the already-paired wireless Carry out the steps shown and transmitter that you want to confirm.
  • Page 62 Installation instructions SC10.8 SC10.9 SC10.10 SC10.11 Exit the programming mode. SC10.12 Control the product via the Rooms view.

  • Page 63: Sc11: Pairing Schellenberg Wireless Light Switch

    Installation instructions SC11: Pairing Schellenberg wireless light switch SC11.1 SC11.2 SC11.3 SC11.4 Name device Save device name Pair device SC11.5 SC11.6 SC11.7 Example: direct pairing. Pair the device directly or select the already-paired Carry out the steps shown and wireless transmitter that you confirm.
  • Page 64 Installation instructions SC11.8 SC11.9 SC11.10 SC11.11 Exit the programming mode. SC11.12 Control the product via the Rooms view.

  • Page 65: Sc12: Pairing Schellenberg Wireless Light Module

    Installation instructions SC12: Pairing Schellenberg wireless light module SC12.1 SC12.2 SC12.3 SC12.4 Name device Save device name Pair device SC12.6 SC12.7 SC12.5 Example: direct pairing. Pair the device directly or Carry out the steps shown select the already-paired and confirm. wireless transmitter that you want to copy.
  • Page 66 Installation instructions SC12.8 SC12.9 SC12.10 SC12.11 Exit the programming mode. SC12.12 Control the product via the Rooms view.

  • Page 67: Sc13: Pairing Schellenberg Wireless Alarm Handle

    Installation instructions SC13: Pairing Schellenberg wireless alarm handle SC13.1 SC13.2 SC13.3 Name device Save device name Pair device SC13.4 SC13.5 SC13.6 Carry out the steps shown and confirm. Exit the programming mode.
  • Page 68 Installation instructions SC13.7 SC13.8 Select the detail view for further status information. Handle position display: Closed, open or at an angle Battery status: Warns you in good time that you need to replace the batteries. SC13.9 Alarm: In the event of an alarm, you receive a message in the app.

  • Page 69: Sc14: Pairing Schellenberg Wireless Thermostat

    Installation instructions SC14: Pairing Schellenberg wireless thermostat SC14.1 SC14.2 SC14.3 Name device Save device name Pair device Important note: The wireless thermostat must be in the “manual” operating mode for pairing to be carried out. SC14.4 SC14.5 SC14.6 Carry out the steps shown Exit the programming and confirm.
  • Page 70 Installation instructions SC14.7 SC14.8 You can use the thermometer (A) or the buttons (B) to regulate the temperature. Single-room control: Group control of all the wireless thermostats paired in the room. SC14.9 SC14.10 SC14.11 Set up the automatic control Set up desired heating of the room temperature.
  • Page 71 Installation instructions SC14.12 SC14.13 SC14.14 Exit the set-up of the heating Set the room temperature phases. manually. Set up additional heating phases. Note: Only heating phases are set up here. Energy-saving phases auto- matically take place between the heating phases. SC14.15 SC14.16 SC14.17...

  • Page 72: P1: Connection From Paulmann Product To Smart Friends Box

    P1.3 P1.4 Click on Add ZigBee device The Smart Friends Box will now search for Paulmann to or end the pairing process by pair with. clicking Cancel. If a lamp or luminaire is found, these will flash in order until the pairing process is complete.
  • Page 73 Installation instructions P1.5 P1.6 The pairing process will now proceed automatically. Once all devices have been found and pairing has been All devices connected to a power supply can now be found. confirmed, you can exit the pairing process by clicking Finish process.

  • Page 74: P2: Change The Device Settings Of Paulmann Products

    Installation instructions P2: Change the device settings of Paulmann products P2.1 P2.2 Open the Rooms view. Select the pencil symbol You are now in the device settings view. to switch to editing mode. Then click the gear symbol above the device in question. Tip: If you have paired multi- ple devices at once, you can identify the respective lamp or...
  • Page 75 This will open a list of room names from which you can select the new allocation. Tip: You can also select the icons of other Smart Friends partners. These icons are used during pairing for simpler user Note: Depending on the operation.

  • Page 76: P3: User Operation And Further Installation Information About Paulmann Products In The "Rooms" View

    P3.1 Click on the triangle symbol Once all components have been allocated to a room, the Paulmann device and the Smart Friends Box are to see further control options. fully synchronised. Depending on the device type, there are different user menus available to you.
  • Page 77 Installation instructions P3.4 P3.5 Light colour selection sub-menu. White tone adjustment on RGB devices. Tip: On RGB devices without a separate white LED chip, you can also select a near- white tonein the top area of the colour selection menu. P3.6 CCT Light - Tunable white/ daylight control...
  • Page 78 Installation instructions P3.7 P3.8 Dimmable devices Switchable devices On/Off as well as < - > toggle between one setting and another. Dimming from 0-100% On/Off as well as < - > toggle between one setting and another.

  • Page 79: P4: Further Installation Information About Paulmann Products

    A Paulmann ZigBee remote control can be paired with the Smart Friends Box when it is in the default setting. If this is not the case (e.g. if it has already been used to control devic- es directly), it must first be restored to factory settings (see P4.3).

  • Page 80: To Smart Friends Box

    Once the flashing stops, the remote control has been found and paired with the Smart Friends Box. Exit configuration mode in the APP by click- ing on the checkbox symbol.
  • Page 81 Once the remote control has been paired with the Smart If you want to use an additional remote control for the same Friends Box, it can be connected directly to the devices. This device, this can be “cloned”. Proceed as follows:...

  • Page 82: P5: Paulmann Products In The "Scenarios" View

    Installation instructions P5: Paulmann products in the “Scenarios” view P5.1 P5.2 Device selection for If component possible: Creating a scenario Under Device, you can also selection a Paulmann device. P5.3 Select the device for the If component based on the room allocation and chosen control position (saving necessary!) If component: The following statuses can be used as an actuator in the “If”...
  • Page 83 Installation instructions P5.4 Then component: Different functions can be selected, depending on the device type: - On/Off as well as < - > toggle between one setting and another. - Dimming from 0-100% - RGB colour selection (click on field to open sub-menu) - Light colour selection (click on field to open sub-menu) - Automatic colour change selection (On = “Colour change is active”);...
  • Page 84 Installation instructions P5.7 Example setting for switching and dimming with automatic colour change activated Automatic colour change selection (On = “Colour change is active”); once the colour change has been activated, the speed at which it changes can also be adjusted.

  • Page 85: P6: Paulmann Products In The "Home Status" View

    Installation instructions P6: Paulmann products in the “Home status” view P6.1 In the Home status view, you can obtain an overview of all Save your chosen settings! components whose current status has been set to critical. You can freely determine the status as required: Product Critical condition On, Off, <...

  • Page 86: St1: Connecting Steinel Products

    Installation instructions ST1: Connecting STEINEL products to the Smart Friends Box ST1.1 Z Wave: Open the “Rooms” view. Select the pen symbol to switch to editing mode. Important note: Complete the configuration of the STEINEL products before you connect your STEINEL products with the Smart Friends Box.
  • Page 87 Installation instructions ST1.4 ST1.5 XLED Home 2 Z Wave and IS 140-2 Z Wave are If required, you can change the name of your device. Then, select Synchronise Device. set up using a control dial (Poti). Note: If you have selected “Synchronise Device”...

  • Page 88: St2: Steinel Products In The "Rooms" View

    Motion detectors: Shows if Note: Synchronisation between the STEINEL product and any current movement has the Smart Friends Box is complete once all components have been detected. been matched to a room. The Smart Friends Box will now receive information via the Only for the L 810: You can sensors and/or sensor lights;...

  • Page 89: St3: Steinel Products In The "Scenes" View

    Installation instructions ST3: STEINEL products in the “Scenes” view ST3.1 In the “Scenes” view you can switch the configured scenes ON or OFF.

  • Page 90: St4: Steinel Products In The "Home Status" View

    Installation instructions ST4: STEINEL products in the “Home status” view ST4.1 ST4.2 Click on a tick symbol if you wish to display a component The “Home status” view provides an overview of all compo- under “Home status”. The tick then turns green. nents whose sensor status needs to be displayed.

  • Page 91: St5: Steinel Products In The "Removal Process" View

    Installation instructions ST5: STEINEL products in the “Removal process” view ST5.1 ST5.2 Select the minus symbol to switch to the Depending on the type of device you have, there are two different ways of removing devices. XLED Home 2 Z Wave “Removal”...
