Dytran 3122C Operating Instructions

OG3122C.docx
REV F ECN 13551 07/10/17
D y n a m i c T r a n s d u c e r s a n d S y s t e m s
2 1 5 9 2 M a r i l l a S t . • C h a t s w o r t h , C A 9 1 3 1 1 • P h o n e 8 1 8 - 7 0 0 - 7 8 1 8
w w w . d y t r a n . c o m • e - m a i l : i n f o @ d y t r a n . c o m
OPERATING INSTRUCTIONS
MODEL 3122C & 3122C2
HERMETICALLY SEALED
CHARGE MODE ACCELEROMETERS
NOTE
Models 3122C and 3122C2 are essentially
similar instruments with the following exceptions:
The upper temperature limit for Model 3122C is
+375 degrees F while the upper temperature .
for Model 3122C2 is +500 degrees F. The
sensitivity of Model 3122C is 50 pC/g while
the 3122C2 is 15 pC/g. Most other
specifications are similar. (Check specification
sheet for other differences).
This manual includes:
(1) Outline/installation drawing 127-3122C
(2) General Guide to Charge Mode Accelerometers
