User Manual
Dell Venue 10 Pro 5056 / 8 Pro 5855 Imaging Recommendations
Dell
Business Client
Imaging Recommendations
Dell Venue 10 Pro 5056 / 8 Pro 5855
Version: X00
28 FEB 2016
Advertisement
Related Manuals for Dell Dell Venue 10 Pro 5056
Summary of Contents for Dell Dell Venue 10 Pro 5056
- Page 1 Dell Venue 10 Pro 5056 / 8 Pro 5855 Imaging Recommendations Dell Business Client Imaging Recommendations Dell Venue 10 Pro 5056 / 8 Pro 5855 Version: X00 28 FEB 2016...
- Page 2 Dell Venue 10 Pro 5056 / 8 Pro 5855 Imaging Recommendations Contents Overview ....................................3 Imaging ....................................4 Supported Operating Systems ............................4 Boot Capabilities ................................4 OS Install ..................................4...
- Page 3 Dell Venue 10 Pro 5056 / 8 Pro 5855 Imaging Recommendations 1 Overview The purpose of this document is to provide details for imaging Dell Venue 10 Pro 5056 and 8 Pro 5855 systems with the properly supported Microsoft Operating System and required drivers and applications.
- Page 4 Dell Venue 10 Pro 5056 / 8 Pro 5855 Imaging Recommendations 2 Imaging 2.1 Supported Operating Systems The following Microsoft operating systems have been validated for use with the Dell Venue 10 Pro 5056 and 8 Pro 5855 tablets: ...
- Page 5 Dell Venue 10 Pro 5056 / 8 Pro 5855 Imaging Recommendations 2. In order to boot to PXE from an Ethernet network device, the UEFI network stack must be enabled. System Configuration->Integrated NIC->Enable UEFI Network Stack - Enable 3. In order for the system to detect and enumerate all the connected USB device, FastBoot mode must be set to “Thorough”.
- Page 6 Dell Venue 10 Pro 5056 / 8 Pro 5855 Imaging Recommendations 2.3.1 Two basic methods to install an OS image on the Venue 10 Pro 5056 and 8 Pro 5855 tablets. 1. Hand install from UEFI bootable USB flash drive that contains the OS install files.
- Page 7 Dell Venue 10 Pro 5056 / 8 Pro 5855 Imaging Recommendations 2. Select “Create installation media for another PC”.
- Page 8 Dell Venue 10 Pro 5056 / 8 Pro 5855 Imaging Recommendations 3. Select “Language, Edition and Architecture”.
- Page 9 Dell Venue 10 Pro 5056 / 8 Pro 5855 Imaging Recommendations 4. The MCT can create an ISO image or prepare a USB flash drive to boot the installer. Select “USB flash drive” and click next.
- Page 10 Dell Venue 10 Pro 5056 / 8 Pro 5855 Imaging Recommendations 5. The MCT will show a list of USB flash drives that it has detected, select the drive to be used as the install device from the list and click next. It is recommended that the USB flash drive have storage space of 4GB or greater.
- Page 11 Dell Venue 10 Pro 5056 / 8 Pro 5855 Imaging Recommendations 6. When the MCT has completed, select Finish. The USB flash drive is now ready to boot the Windows 10 installer.
- Page 12 Dell Venue 10 Pro 5056 / 8 Pro 5855 Imaging Recommendations Windows 8.1 – USB install media creation 2.3.1.1.2 Download the Windows 8.1 MCT to any workstation running Windows 7 or higher. Run the tool as admin and follow the prompts.
- Page 13 To install the OS using a UEFI bootable USB flash drive with a USB-C dock: For this example, the Dell Dock WD15 was used in conjunction with a Venue 10 Pro 5056. The process for the Venue 8 Pro 5855 would be similar.
- Page 14 Dell Venue 10 Pro 5056 / 8 Pro 5855 Imaging Recommendations This method will work for both the Venue 10 Pro 5056 and is the best option for 8 Pro 5855 since it only has the single USB-C port. With the Venue Pro 5056, if a USB-C docking unit is not available, another method possible is to use a USB-C charging adapter with a USB3.0 or 2.0 hub on the system’s external USB port to provide...
- Page 15 Dell Venue 10 Pro 5056 / 8 Pro 5855 Imaging Recommendations After making the necessary connections and powering on the tablet, as soon as the Dell splash screen is displayed, press the F12 on the keyboard or hold the Volume-Up button to bring up the one-time boot selection menu.
- Page 16 Dell Venue 10 Pro 5056 / 8 Pro 5855 Imaging Recommendations 2.3.2 Installation through Microsoft’s SCCM PXE Boot Setup The Venue 10 Pro 5056 and 8 Pro 5855 both support PXE network booting for connection to automated install and deployment servers. It is recommended to use the network capabilities of the docking unit to provide PXE boot and network support for the system.
- Page 17 Dell Venue 10 Pro 5056 / 8 Pro 5855 Imaging Recommendations This technique will work for the Venue 10 Pro 5056 and is best the approach for the Venue 8 Pro 5855. The Venue 10 Pro 5056 and 8 Pro 5855 both have PXE code included in the UEFI BIOS that can boot the following USB-C network devices.
- Page 18 To PXE boot the tablet, make the necessary USB and network connections then power up the system. As soon as the Dell splash screen is displayed, press the F12 on the attached keyboard or hold the Volume-Up button on the system to bring up the one-time boot selection menu.
- Page 19 SCCM System Drive Partition Setup The Dell Venue 10 Pro 5055 / 8 Pro 8055 do not support legacy boot options. All disk setup configurations must be setup for UEFI function. A typical Windows 10 will use this partitioning/volume scheme on a GPT formatted SSD.
- Page 20 Deploying Windows 8.1 through SCCM: https://technet.microsoft.com/en-us/library/dn744284.aspx SCCM Driver Install Step Sequence Dell recommends installing the Venue 10 Pro 5056 / 8 Pro 5855 system device drivers and supporting applications in the install order outlined below. 2.3.3 Venue 10 Pro 5056 and 8 Pro 5855 Recommended Install Order for Drivers/Apps Required drivers/updates: 1.
