Viz-Art Automation ZIP Plasma Mount Installation Manual

ZIP - Wall mount
Wall mount for flat displays

LIST OF ITEMS:


Mount elements(3 pcs.)

Mounting Set (1 set.)

Instruction manual

Vertical frame elements (2 pcs.)

1. Installation:

2A. Install A1 and A2 elements to your flat display using
proper screws form mounting set.
2C. Mount flat display with elements A1 andA2 on
element B already installed on a wall
Level the element
2B. B
it to a wall, using proper dowels.
2D. Make installation in 1 and 2 steps as
described below. In that layout of wall
mount, it will block and secure your flat
display.
before,
then install
1/2
