Manuale utente - User manual
FresneLED e PCLED 100 DMX Compact
cod. FN LED C100 CW DMX • FN LED C100 WW DMX • FN LED C100 NW DMX
PC LED C100 CW DMX • PC LED C100 WW DMX • PC LED C100 NW DMX

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FN LED C100 CW DMX and is the answer not in the manual?

Questions and answers

Related Manuals for Spotlight FN LED C100 CW DMX

Summary of Contents for Spotlight FN LED C100 CW DMX

  • Page 1 FresneLED e PCLED 100 DMX Compact cod. FN LED C100 CW DMX • FN LED C100 WW DMX • FN LED C100 NW DMX PC LED C100 CW DMX • PC LED C100 WW DMX • PC LED C100 NW DMX...
  • Page 2 Prima di usare questi apparecchi, read the present instructions carefully. leggere attentamente le istruzioni che seguono. Spotlight srl will not be responsible for damage Spotlight srl non potrà essere ritenuta responsabile di resulting from instructions not being followed. danni derivanti dalla non osservanza di dette istruzioni.
  • Page 3 FresneLED e PCLED 100 DMX Connessioni elettriche e DMX - Electrical and DMX connections CONSOLE DMX IN DMX OUT DMX IN DMX OUT DMX OUT DMX IN 100-240V Fig. 2 Dimensioni (mm) e pesi - Dimensions (mm) and weights Kg. 3,5 Fig.
  • Page 4 FresneLED e PCLED 100 DMX DESCRIZIONE DEL PROIETTORE CONNESSIONI ELETTRICHE Riferendosi ai disegni di pag. 2: Il vostro faro è stato progettato per una tensione di alimentazione da 100 a 240V, 50/60 Hz. ① Staffa di sospensione ② Maniglia per regolazione inclinazione del faro Prima e durante l’installazione osservare le seguenti ③...
  • Page 5 FresneLED e PCLED 100 DMX IMPOSTAZIONE MODALITA' DI FUNZIONAMENTO 2) Modalità DMX (001-512) (vedi Fig. 1 e 2) Per il controllo in questa modalità è necessario il collegamento tramite cavo DMX da un dispositivo Il faro è predisposto per poter essere utilizzato in di controllo (es.
  • Page 6 FresneLED e PCLED 100 DMX DESCRIPTION OF THE LUMINAIRE to 240V supply, 50-60Hz. Before and during the installation, make sure you Referring to pictures on pages 2: follow the guidelines below: ① Suspension yoke • Always check the earth continuity connection for the ②...
  • Page 7 FresneLED e PCLED 100 DMX FUNCTIONING SET UP (see Fig. 2) 2) DMX Mode (001-512) For the control in this mode the connection through The luminaire is intended to be used in various a DMX cable from a control device (eg. consolle) to functioning modes: the DMX IN luminaire connector is necessary.
  • Page 8 FresneLED e PCLED 100 DMX Spotlight s.r.l. Via Sardegna 3 20098 S. Giuliano Milanese Milano - Italy Tel. +39.02.98830.1 Fax +39.02.98830.22 E-mail: info@spotlight.it www.spotlight.it...
