  • Page 1 Hz 2 Radio Control Systems Programming Manual www.simu.com...
  • Page 2 Hz Motor Selection Guide For Rolling Shutters and Doors To select a motor in this guide you need to know the following: 1. Type of Slat: Height and Width 2. Total weight of shutter 3. Diameter of the tube Type of slat: It is important to consider the total size of the product you plan to produce before choosing an operator, since these variables affect the weight of what an operator can lift.
  • Page 3 Motor Selection Guide For Hz Type 5 Operators 50mm (2.0 inch) TUBE DIAMETER Model Type 37(lbs.) 62(lbs.) 92(lbs.) 154(lbs.) 185(lbs.) 216(lbs.) 308(lbs.) 60mm (2.5 inch) TUBE DIAMETER Model Type 30(lbs.) 49(lbs.) 74(lbs.) 123(lbs.) 148(lbs.) 172(lbs.) 246(lbs.) 70mm (2.75 inch) TUBE DIAMETER Model Type 27(lbs.)
  • Page 4 Motor Selection Guide For Hz Type 5 Operators 78mm (3.0 inch) TUBE DIAMETER Model Type 25(lbs.) 41(lbs.) 62(lbs.) 103(lbs.) 123(lbs.) 143(lbs.) 205(lbs.) 85mm (3.25 inch) TUBE DIAMETER Model Type 22(lbs.) 38(lbs.) 57(lbs.) 95(lbs.) 114(lbs.) 132(lbs.) 189(lbs.) -The listed charts reflects the recommended 30% security factor that is used for most applications.
  • Page 5 Hz Motor Selection Guide For Retractable Awning Systems 1 Pair 2 Pair 3 Pair 4 Pair 5 Pair 6 Pair (2 arms) (4 arms) (6 arms) (8 arms) (10 arms) (12 arms) B Number of Arms 20 ft. (6m) 33 ft. (10m) 50 ft.
  • Page 6 Limit Switch Adjustment Hz T5 Operators MATERIAL ROLLS DOWN ON SAME SIDE AS LIMITS MATERIAL ROLLS DOWN ON OPPOSITE SIDE FROM LIMITS UP LIMIT ADJUSTMENT SCREW DOWN LIMIT ADJUSTMENT SCREW DOWN LIMIT ADJUSTMENT SCREW UP LIMIT ADJUSTMENT SCREW 1) Identify which limit adjustment screw controls the up limit and which controls the down limit (see above diagrams). It is important to note that the arrows by the limit adjustment screw refer to the tube's rotation.
  • Page 7 Limit Switch Adjustment Hz Type 5 DMI Operators LIMIT ADJUSTMENT SCREWS ON OPPOSITE SIDE FROM MOTOR CABLE LIMIT ADJUSTMENT SCREWS ON OPPOSITE SIDE FROM MOTOR CABLE MATERIAL ROLLS DOWN ON SAME SIDE AS LIMITS MATERIAL ROLLS DOWN ON OPPOSITE SIDE FROM LIMITS UP LIMIT ADJUSTMENT SCREW DOWN LIMIT ADJUSTMENT SCREW UP LIMIT ADJUSTMENT SCREW...
  • Page 8 -Mount Hz motor heads at least 18 inches from each other to prevent RF interference. -Always install the power cable with a drip loop to prevent water penetration -SIMU motors conform to IP44 requirements and as such must be protected against direct weather elements such as rain, sleet, ...etc.
  • Page 9 Hz 2 Type 5 / DMI Operator Basic Rules and Scenarios One motor to one wireless switch. Multiple motors to one wireless switch. There is no limit to the amount of motors you can put to one switch. The only limitation is the range a transmitter can reach.
  • Page 10 Simply supply power to the electric operator and program the wireless transmitter to the motor or motors of choice and you are done. Individual Switches Sub Group Switches Master Switch For more information about other options available, please consult a SIMU representative for more details.

  • Page 11: Programming The Transmitter

    Hz 2 Type 5 / DMI Operator Scenarios One motor to one wireless switch. IMPORTANT -The motor is supplied in “Factory Mode”. Set direction of rotation (1) before pressing the program button. Press the up and down button simultaneously to 1) Setting Direction of Rotation awake the motor.
  • Page 12 Hz 2 Type 5 / DMI Operator Scenarios Multiple motors to one wireless switch. There is no limit to the number of motors you can program to one switch. The only limitation is the range a transmitter can reach. This is approximately 70 feet through walls and up to 100 feet in open air.

  • Page 13: Programming Additional Transmitters

    Hz Type 5 / DMI Operator Scenarios Single motor to multiple wireless switches. There is a limit of 12 transmitters of any type to one motor. Press the up and down button simultaneously to awake the motor. 1) Setting Direction of Rotation (example 1) The motor will be in “Factory Mode”...

  • Page 14: Installation

    Hz Wireless Receiver Instruction INSTALLATION DESCRIPTION The UL Listed Hz Receiver allows control of any standard (non-Hz) T5 or 1) Mount the Hz Receiver as close to the motor as possible. Avoid T6 motor from any of the Hz handheld or wall switch, wireless transmitters. mounting the receiver on metallic surfaces as this will reduce the range.
  • Page 15 The Hz Dry Contact Interface can be used to communicate between and no more than 70 feet. Avoid mounting the receiver on metallic SIMU’s Hz motors and momentary dry contact devices such as: third party surfaces as this will reduce the range. If mounted outside, make sure to...
  • Page 16 Programming Button & LED DOWN MTR COM NEUT 6301075 -This radio receiver can be used with the SIMU standard AC motor series 120v-60hz. This control is compatible with all the transmitter switches shown above. Hz Dry Contact Interface Transmitter Programming Button & LED...
  • Page 17 Operators Hz Type 5 Bracket Accessories Item Reference Description Shade Bracket 510000 - U- Support for square 10mm motor mount 500073 - Attaches to wall bracket 800095 - Zinc Plated Shade Bracket 520073 - Motor mount 10mm square pin - For Type 5 operators - Zinc Plated 520038 Shade Bracket...
  • Page 18 Operators Hz Type 5 Bracket Accessories Item Reference Description Standard Bracket 520076 - 30mm spacing / counter sunk holes - Attaches to wall plate 850066 or 850067 - Zinc Plated Shutter Bracket 520187 - Maxi side frame bracket 100x100mm - Requires side frame center pin to be removed - Gold Zinc Plated 252527 Shade Bracket...

  • Page 19: Troubleshooting

    Trouble Shooting -Motor goes up when down is pressed. Go to step (C) listed below Setting Direction of Rotation. -Can not change the Direction of Rotation. Make sure to hold the transmitter within 10 feet of the motor head. Confirm the motor is in” Factory Mode” -Can not get the motor to memorize the 1st transmitter.
  • Page 20 -Mount Hz motor heads at least 18 inches from each other to prevent RF interference. -Always install the power cable with a drip loop to prevent water penetration -SIMU motors conform to IP44 requirements and as such must be protected against direct weather elements such as rain, sleet, ...etc.
  • Page 21 Hz2 PROGRAMMING INSTRUCTIONS Hz2 PROGRAMMING INSTRUCTIONS 6) Programming the Transmitters Waking up the motor - Before programming, changing direction of rotation, setting the limits, etc... Before programming you must wake Before programming you must wake the motor up by pressing and holding the motor up by pressing and holding You must Wake the motor up.
  • Page 22 Standard Limits Standard Limits MATERIAL ROLLS DOWN ON SAME SIDE AS LIMITS MATERIAL ROLLS DOWN ON OPPOSITE SIDE FROM LIMITS UP LIMIT ADJUSTMENT SCREW DOWN LIMIT ADJUSTMENT SCREW DOWN LIMIT ADJUSTMENT SCREW UP LIMIT ADJUSTMENT SCREW 1) Identify which limit adjustment screw controls the up limit and which controls the down limit (see above diagrams). It is important to note that the arrows by the limit adjustment screw refer to the tube's rotation.

  • Page 23: Wiring Diagram

    SYNCHRONIZING CONTROL Installation and Operation Instructions DESCRIPTION SOMFY'S Synchronized Control is designed to control two motors simultaneously. When two Somfy motors are mounted in a single tube, moving a single window treatment, it is important that the motors coincide with each other. The Synchronized control actuates and stops both motors at the same time.
  • Page 24 DMI Limits DMI Limits LIMIT ADJUSTMENT SCREWS ON OPPOSITE SIDE FROM MOTOR CABLE LIMIT ADJUSTMENT SCREWS ON OPPOSITE SIDE FROM MOTOR CABLE MATERIAL ROLLS DOWN ON SAME SIDE AS LIMITS MATERIAL ROLLS DOWN ON OPPOSITE SIDE FROM LIMITS UP LIMIT ADJUSTMENT SCREW DOWN LIMIT ADJUSTMENT SCREW UP LIMIT ADJUSTMENT SCREW DOWN LIMIT ADJUSTMENT SCREW...
