BOB Weather Shield Instructions

Congratulations on your
purchase of the BOB
Weather Shield. It is
designed to provide
your child with
protection from
Rear
inclement weather.
Vents
Proper installation and
care will provide years
of reliable service.
Before attempting to
use or attach your new
Weather Shield, read
Fig. 1 Keep all Vents unobstructed.
and understand these
instructions
completely to insure
proper assembly and
operation. If you are
unclear on any point,
contact your dealer or
BOB before use.
Warnings
. This product is
designed exclusively
for use with BOB
Revolution Duallie
Aft Canopy
strollers. It is not
Supports fully
intended for use with
rotated back
other strollers or
products.
. The Weather Shield
is made of a non-
breathable material.
To avoid danger of
suffocation and
excessive
temperatures,
follow all assembly
instructions.
. Always make sure all
vents are
Rear
unobstructed, as
Canopy
indicated in Fig.1.
Flap
. The Weather Shield
Fig. 2 Canopy Supports in position.
is not designed to
work with optional
Infant Car Seat
Adapter and car seat.
. Do not use Weather
Shield when
temperatures exceed
o o
65 F/18 C. Use in
higher temperatures
can cause unsafe
conditions inside the
Weather Shield.
. Never leave child
unattended.
. When not in use,
keep out of reach of
children.
Fig. 3 Canopy Drawstring Adjustment
Revolution duallie Weather Shield instructions
(800) 893-2447 www.bobgear.com email- info@bobgear.com Ph: (208) 375-5171
Fax: (208) 375-5172, BOB Trailers, Inc. 5475 Gage St. Boise, ID 83706
Side
Vents
Front
Vent
Forward Canopy
Supports
Cinch each
Cord Lock
tight against
each Canopy
INSTALLATION
INSTRUCTIONS:
Velcro
Fastened
1.
Set stroller Parking
Brake (refer to Parking
Brake section of stroller
Owner’s Manual). Place
each sun canopy into
position to receive the
Weather Shield as
shown in Fig.2.
2.
Pull each canopy
drawstring in order to
gather extra material
under canopy. Cinch
Velcro
cord lock against
Fastened
canopy to retract and
hold material, as shown
in Fig. 3.
Fig. 4 Rear Canopy Flap in position.
Very important: when
the Weather Shield is
used, the rear canopy
flap must be in correct
position as described
below. This will insure
proper airflow and
avoid danger of
suffocation.
3.
Locate rear canopy
flap and fold forward.
Fig. 5 Rear Vents unobstructed.
Attach canopy flap
velcro on flap to
respective velcro mate
on top outboard side of
Align Weather Shield Seam with
each canopy as shown
Forward Canopy Supports
in Fig. 4). Warning tag
on rear canopy flap also
describes and illustrates
Elastic
this critical step.
Cord
End
4.
Inspect opening at
Loop
back of stroller to make
sure the air passages
between top of seat
back and canopy are
unobstructed (see Fig.
Fig. 6 Shield placed on Canopy
5). We recommend
reclining each seat back
slightly to optimize
airflow (refer to
Reclining Seat section
of stroller Owner’s
Manual).
5.
Place Weather
Shield on the stroller so
the rear flap drapes over
back (between the
handlebars) and the
seam above the window
is aligned with the
forward Sun Canopy
Elastic Loop
supports (see Fig. 6).
Around Black
Shock Knob
6.
Stretch the elastic
cord on each side under
each respective black
shock knob as shown in
Fig. 7. There is an
opening mid way up
Fig. 7 Elastic cord attachment
each side (with silver
MA0653
Rear Canopy
Flap folded
over top
Air Passages
Silver
Reflective
Fabric
Elastic Cord
Under Black
Shock Knob
