- Page 1 ADJUSTMENT GUIDE UCP Expression Chair w w w . u c p w h e e l s . o r g...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Tools needed Adjustment : 1. Footrest Height 2. Seat Depth 3. Back Tilt Angle 4. Back Height 5. Seat height 6. Caster 7. Center of Gravity 8. Brake 9. Tension back 10. Anti-Tip 11. Arm Rest w w w . u c p w h e e l s . o r g... -
Page 3: Tools Needed
Tools needed Phillips Screw Driver 2 Wrenches no. 13 Rubber Hammer 2 Wrenches no. 10 w w w . u c p w h e e l s . o r g... -
Page 4: Adjustment
1. Footrest Height Adjustment STEP 1 Loosen the nut (left and right). Adjust according to user’s needs. Note marks on tube. w w w . u c p w h e e l s . o r g... -
Page 5: Seat Depth
2. Seat Depth Adjustment STEP 1 Loosen bolt #1 and remove bolt #2. Lift and slide the back rest. w w w . u c p w h e e l s . o r g... -
Page 6: Back Tilt Angle
3. Back Tilt Angle Adjustment STEP 1 STEP 2 Loosen & remove bolt and nut. Adjust backrest angle to fit the user’s need. Re-install bolts and tighten all four nuts. w w w . u c p w h e e l s . o r g... -
Page 7: Back Height
4. Back Height Adjustment STEP 1 To change back height, first remove tension adjustable back strap. Then remove the bolts. w w w . u c p w h e e l s . o r g... -
Page 8: Seat Height
5. Seat Height Adjustment STEP 1 Seat height adjustment helps put the user’s arm in the strongest pushing position, with elbow at 90 when hand is at top of hand rim. To start, loosen all four bolts on axle bracket. STEP 2 Tap the bracket with a rubber hammer to move the bracket. -
Page 9: Caster
5. Seat Height Adjustment STEP 3 The caster barrel must be at 90 degrees or the chair will be difficult to push and turn. Move the caster axle to the same position 1, 2, or 3. To start, use a 13mm wrench to remove the axle. -
Page 10: Center Of Gravity
7. Center of Gravity Adjustment STEP 1 Remove rear wheels, loosen top bolts & bottom bolts. STEP 2 Move as needed. Carefully tighten bolts. Nut holders must be completely inserted. STEP 3 Loosen nuts of fender holder. Adjust to the rear wheel position. - Page 11 8. Wheel Lock Adjustment STEP 1 Wheel locks should fully stop the wheel. There are two sets of adjustment bolts - major and minor. Make the major adjustment first. STEP 2 Set minor adjustment so that wheel is fully stopped when wheel lock is engaged.
-
Page 12: Tension Back
9. Tension Back Adjustment STEP 1 Take off back cover & open velcro strap to start adjustment. STEP 2 Adjust the tension of the straps to match the curve of the user’s back. STEP 3 Replace the back cover. w w w . u c p w h e e l s . o r g... -
Page 13: Anti-Tip
10. Anti-Tip Adjustment STEP 1 Push the button on the tube of Anti tip. w w w . u c p w h e e l s . o r g... -
Page 14: Arm Rest
9. Arm Rest Adjustment STEP 1 Remove bolt and replace to fit the user’s needs. w w w . u c p w h e e l s . o r g... - Page 15 Question Contact Us: info@ucpwfh.org or check: info@ucpwheels.org/product w w w . u c p w h e e l s . o r g...
