ASSEMBLY GUIDE
Expression
w w w . u c p w h e e l s . o r g

Advertisement

loading
Need help?

Need help?

Do you have a question about the Expression and is the answer not in the manual?

Questions and answers

Related Manuals for UCP Expression

Summary of Contents for UCP Expression

  • Page 1 ASSEMBLY GUIDE Expression w w w . u c p w h e e l s . o r g...

  • Page 2: Table Of Contents

    Table of Contents 1. Back Release 2. Footrest Assembly 3. Caster Wheel Assembly 4. Rear Wheel Assembly 5. Backrest Assembly 6. Fender Assembly (Optional) 7. Armrest Assembly (Optional) 8. Anti-Tip Assembly (Optional) w w w . u c p w h e e l s . o r g...
  • Page 3 Tools Needed Phillips Screw Driver Rachet 19mm 2 Wrenches no. 13 2 Wrenches 10mm Rubber Hammer Wrenches no. 19 w w w . u c p w h e e l s . o r g...

  • Page 4: Back Release

    1. Back Release STEP 1 Pull string STEP 2 Lift backrest. w w w . u c p w h e e l s . o r g...

  • Page 5: Footrest Assembly

    2. Footrest Assembly STEP 1 Insert the footrest. STEP 2 Tighten both bolts very tight. w w w . u c p w h e e l s . o r g...

  • Page 6: Caster Wheel Assembly

    3. Caster Wheel Assembly STEP 1 Install caster, washer, and nut. STEP 2 Tighten nut. Caster should rotate freely. w w w . u c p w h e e l s . o r g...
  • Page 7 3. Caster Wheel Assembly STEP 3 Install plastic cap. w w w . u c p w h e e l s . o r g...

  • Page 8: Rear Wheel Assembly

    4. Rear Wheel Assembly STEP 1 Insert axle. Check that retaining ball is in correct position. STEP 2 Adjust axle using a 19 mm and 13mm wrench if ball is in wrong position. w w w . u c p w h e e l s . o r g...

  • Page 9: Backrest Assembly

    5. Backrest Assembly STEP 1 Install backrest cover on velcro. STEP 2 Attach to seat surface. w w w . u c p w h e e l s . o r g...

  • Page 10: Fender Assembly (Optional)

    6. Fender Assembly (Optional) Install the fender. w w w . u c p w h e e l s . o r g...

  • Page 11: Armrest Assembly (Optional)

    7. Armrest Assembly (Optional) STEP 1 STEP 2 STEP 3 w w w . u c p w h e e l s . o r g...

  • Page 12: Anti-Tip Assembly (Optional)

    8. Anti-Tip Assembly (Optional) STEP 1 Install the anti-tip. STEP 2 Tighten bolts. w w w . u c p w h e e l s . o r g...
  • Page 13 Question Contact Us: info@ucpwfh.org or check: www.ucpwheels.org/product w w w . u c p w h e e l s . o r g...
