Viking VK3000 ICE Instruction Manual

M134
VK3000 ICE
Instructions:
Attach the powercon Mains cable ensuring it has been turned to
lock it in place. Switch the Red Power button to On and wait for the
unit to heat up (Warming). This takes about 8 Minutes after which
the LCD display will show 'READY'
1) Operation from Control Panel On Machine
Pressing the LOCK button will lock the machine to constant output or pressing MANUAL will produce fog
for as long as the button is held down.
Pressing the MENU button allows the user to alter the FAN speed and PUMP output to achieve a small
gentle output through to a thick blast.
Also the timer settings for repeated firing of the machine can be set in the MENU option. The DURATION
time controls how long the smoke is produced for while the INTERVAL time sets the time gap between the
auto firing of the machine. (Pictures 1 & 2)
NB. to save each setting on the machine it is important to press AND hold the MENU button until the LCD
display shows 'SAVE' - only then are the settings saved. (Picture 3)
Picture 1 Picture 3
Picture 2 Picture 4 Picture 5 Picture 5
2) Operation with Wireless REMOTE
Plug in the black remote receiver box into the Remote Control Din socket on the rear of the machine (Picture 4)
and switch on and allow the machine to heat up and say 'READY'
To begin output press the UNLOCK button on the handheld remote and to stop output press the LOCK button
- Please note that the antenna may need extending on the top of the remote and that this is a fragile item and
care must be taken to avoid damage. On pressing the buttons a confirmation Red Led will flash on the remote.
3) Operation with DMX
To Change the DMX address, use the MENU button on the control panel with the UP & DOWN buttons to
select required address (max address is 511), and press and hold the MENU button until 'SAVE' is displayed
in the LCD.
The unit requires 2 channels of DMX:
Channel 1 = Output Volume
Channel 2 = Fan Speed
