- Page 1 Design-in guide POWERdrive 6060/R © 2015 eldoLED. All rights reserved. V1.2 All content contained herein is subject to change without prior notice. More product documentation and eldoLED´s terms and conditions are available at www.eldoLED.com...
-
Page 2: Table Of Contents
2.2.1 DMX network options 2.2.2 LED outputs 2.2.3 LEDcode/NTC 2.2.4 0-10V 2.2.5 DALI 2.2.6 120-230V AC 3. Installing the POWERdrive 6060/R 3.1 Cable connections 3.2 Common practice for grounding LED wires 3.3 Cable trunk 4. Configuring POWERdrive 6060/R 4.1 Menu button combinations 4.2 Order of LED driver configuration... - Page 3 Safety guidelines Disclaimer Warranty...
-
Page 4: Technical Characteristics
To avoid temperature rise affecting lifetime, it is recommended not to use configurations in the derating area of the diagram above. The green area indicates the highest efficiency area of POWERdrive 6060/R. Calculation examples in the high efficiency area, using the formula (number of LED outputs) * ( Iout ) * ( VLED ) Using all 32 LED outputs: ... -
Page 5: Output Characteristics
1.2 Output characteristics LED outputs LED output power 600W max LED output voltage range 2-48V LED output current range 200-1,050mA LED output current resolution Programmable in 50mA steps LED output current accuracy +/- 10% 1.3 Control characteristics Control channels 1-32 over DMX/RDM, 1-4 over DALI, 1 over 0-10V Dimming protocol USITT DMX512A // RDM, DALI or 0-10V Dimming range... -
Page 6: Thermal Protection
482.6 x 325 x 44.5mm / 19 x 12.8 x 1.75in Weight 6.3kg / 13 lb, 14.23 oz Packaging 1 pc Figure 1.2 POWERdrive 6060/R dimensions 1.8 Standards compliance EN 55022, EN 62386-101/102/207, EN 60929 Annex E RoHS RoHS2 1.9 Certifications... -
Page 7: Wiring
2. Wiring 2.1 Wiring specifications 2.1.1 General wiring specifications AWG20 – AWG16, 0.5-1.5mm Wire type Wire core type Solid or stranded copper Wire strip length 9mm, 0.35in The maximum length of LED wiring is 100m / 328ft from LED output to LED load when using 16 AWG type wires. Refer to the table below for the maximum LED wiring length for other wire types: AWG value Distance (m) -
Page 8: Sample Voltage Drop Calculation
EMI susceptibility will increase with longer wire lengths. 2.2 Connections Figure 2.1 POWERdrive 6060/R connections WARNING: risk of electrical shock. May result in serious injury or death. Disconnect power before servicing or installing. CAUTION: the device may only be connected and installed by a qualified electrician. All applicable regulations, legislation and building codes must be observed. -
Page 9: Dmx Network Options
Set the correct DMX start address for each POWERdrive Make sure you terminate the last POWERdrive 6060/R with a resistor that matches the impedance of the cable used as close to its ‘DMX in’ connector as possible. DMX+, DMX- and DMX Shield (the orange-white, orange and brown wire in a CAT5 cable) are pin 1, 2 and 7 of the RJ45 connector. - Page 10 Daisy-chained DMX To set up a daisy-chained DMX network: Use the ‘DMX in’ and ‘DMX out’ connectors as shown in the diagram below Set the correct DMX start address for the first POWERdrive in a group Make sure you terminate the POWERdrives at their ‘DMX in’ connector when the wire length between drivers is over 20m. Use a resistor that matches the impedance of the cable that has been used.
-
Page 11: Led Outputs
2.2.2 LED outputs POWERdrive 6060/R features 32 LED outputs. Note that if you want to connect an LED load to every LED output, the maximum current per output is 800mA. Refer to Chapter 1, Technical Characteristics, for more information on derating and LED wiring. -
Page 12: Ledcode/Ntc
2.2.5 DALI Use the DALI connectors to connect the POWERdrive 6060/R to a DALI network. Always combine a DA+ and DA- connector for either data input or data output. You can address the LED outputs over a total of 4 DALI ballasts. -
Page 13: Installing The Powerdrive 6060/R
3. Installing the POWERdrive 6060/R This chapter gives guidelines for the installation of POWERdrive 6060/R with regard to cable connections, grounding the LED output wires and use of cable trunks. 3.1 Cable connections It is recommended that you use shielded cabling for the LED output wires that connect the 19” rack unit to the LED loads in order to reduce EMI (Electromagnetic Interference). -
Page 14: Common Practice For Grounding Led Wires
3.2 Common practice for grounding LED wires POWERdrive 6060/R has been designed for installation in a 19” rack. It is recommended to ground the shielded LED output cables both at the 19”rack unit and close to the LED load. Inside the 19” rack unit, ground the LED wires as depicted in Figure 3.3 by leading them though an earthing clamp (2) that is attached to a C-rail (1). -
Page 15: Cable Trunk
3.3 Cable trunk Cable trunks as depicted in Figure 3.3 will facilitate leading the wires over longer distances inside the building. Figure 3.3 Using cable trunks... -
Page 16: Configuring Powerdrive 6060/R
“SET MODE”. Set the mode of operation before you move on to the other menu items. If the power is interrupted to a POWERdrive 6060/R that has already been configured, the display will only show the driver type when the power comes back on, but will not go to the Set Mode menu, as the driver’s configuration has been saved to memory. -
Page 17: Setting The Operation Mode
4.3 Setting the operation mode To enter the SET MODE menu: The very first time the driver is powered on, the display will show the driver type/name for a couple of seconds and then automatically enter the SET MODE menu. To manually enter the SET MODE menu, press the M button for 5 seconds The display shows “SET”- “MODE”, followed by the name of the currently active operation mode Using the minus or plus button, go to the operation mode of your choice (COLR, SHOW, DMX, DALI or 10V). - Page 18 To set LED output currents and LED group configurations: Press M and the plus button simultaneously. In the first menu (CUR1), select the LED output current for the current source 1. Figure 4.3 shows which current sources the LED outputs are connected to.
- Page 20 Safety guidelines Before installing or performing routine maintenance upon this equipment, follow the general precautions listed in this Appendix. Installation should be performed by a qualified licensed electrician. Maintenance should be performed by qualified person(s) familiar with the products’ construction and operation and any hazards involved.
- Page 21 AND PROVIDED BY ELDOLED IN WRITING TO THE PURCHASER OF ITS PRODUCTS. The provided Information must not be relied upon in connection with any investment decision. eldoLED B.V. cannot be held liable for any direct or indirect loss or damage resulting from the use of the Information and/or resulting from the use of its products or material(s), except in the event of actions verging on eldoLED’s gross intent or...
- Page 22 AND PROVIDED BY ELDOLED IN WRITING TO THE PURCHASER OF ITS PRODUCTS. The provided Information must not be relied upon in connection with any investment decision. eldoLED B.V. cannot be held liable for any direct or indirect loss or damage resulting from the use of the Information and/or resulting from the use of its products or material(s), except in the event of actions verging on eldoLED’s gross intent or...
- Page 23 Europe, Rest of World North America eldoLED B.V. eldoLED America Science Park Eindhoven 5125 One Lithonia Way 5692 ED Son Conyers, GA 30012 The Netherlands E: info@eldoled.com E: info@eldoled.com W: www.eldoled.com W www.eldoled.com...
