K71130
Base top
2 pcs
Mounting
plate
3 pcs
Screw flh
Bumper
3,5x45 mm
7x1,5
3 pcs
10 pcs
27-08-2014 1
/
DH194,040,000
K12230
Shelf
1 pcs
HS20860,000
K10110
Side
2 pcs
L20849
Door Tinta
1 pcs
Hinge
107 degrees
3 pcs
BP00001
Euro screw
6,3x11 mm
4 pcs
H813L,040,228-229
K13330
Support
1 pcs
ID11500
ID11500
Hanger
1 pcs
Shelf support
14x12 mm 5
4 pcs
K13370
Suspension list
1 pcs
K13120
Back panel
1 pcs
Screw ph
3,5x16
4 pcs
ID11510
Shelves
1 pcs
ID11510
Screw ph
3,5x16
4 pcs
1 /
7
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Kvik H813L-040-228
Summary of Contents for Kvik H813L-040-228
- Page 1 H813L,040,228-229 DH194,040,000 K13370 Suspension list K13330 K71130 K12230 Support Base top Shelf 1 pcs 1 pcs 1 pcs 2 pcs HS20860,000 K13120 K10110 Back panel Side 1 pcs 2 pcs L20849 Door Tinta 1 pcs ID11500 ID11510 Screw ph Mounting Hinge 3,5x16 Screw ph...
- Page 2 H813L,040,228-229 FIG. K10110 Side Euro screw 6,3x11 mm 2 pcs Shelf support 14x12 mm 5 2 pcs FIG. K10110 Side Euro screw 6,3x11 mm 2 pcs Shelf support 14x12 mm 5 2 pcs 27-08-2014 1...
- Page 3 H813L,040,228-229 FIG. K13370 K71130 Suspension list Base top K13370 Suspension list K13330 Support OBS !!! K10110 Side K71130 Base top FIG. K13120 Back panel 27-08-2014 1...
- Page 4 H813L,040,228-229 FIG. Screw flh 3,5x45 mm 5 pcs K10110 Side FIG. Screw flh 3,5x45 mm 5 pcs 27-08-2014 1...
- Page 5 H813L,040,228-229 FIG. K12230 Shelf K12230 Shelf FIG. Right Left Screw ph 3.5x16 4 pcs ID 11510 Shelves ID 11510 ID 11510 Shelves Shelves 27-08-2014 1...
- Page 6 H813L,040,228-229 FIG. Bumper 7x1,5 Bumper 7x1,5 L20849 Door Tinta L20849 Door Tinta Bumper 7x1,5 Click Mounting Hinge plate 107 degrees 3 pcs 3 pcs FIG. Right Left L20849 L20849 Door Tinta Door Tinta 27-08-2014 1...
- Page 7 H813L,040,228-229 Adjustment FIG. ID11500 Screw ph 3,5x16 4 pcs ID11500 27-08-2014 1...
