PREMIER TECHNOLOGIES SMP 1304 Series Quick Start Manual

SMP SMP
1304 Series 1304 Series

General Description

General Description
The SMP 1304 is a digital message repeater designed
for triggered message play. MP3 audio is loaded to the
device using a removable USB flash drive.
The MP3 messages are then transferred into the unit
and stored in non-volatile flash memory.
The SMP 1304 can store and play up to four (4) unique
messages for triggered playback.
Loading new audio to the device is plug-and-play.
Simply drag/drop MP3 audio file(s) to a standard USB
flash drive, and insert the drive into the SMP 1304.
The device will automatically delete the old files and
load the new ones. Once the files have been loaded to
the unit, the USB flash drive can be removed.
Messages are triggered via dry contact closure using a
standard DIN connector located on the rear of the unit.
The SMP 1304 is designed for long-term, reliable audio
playback for use in a commercial application.
Made in the USA.
Digital MP3 System w/Trigger Digital MP3 System w/Trigger
800.466.8642

Features

● 100 % Fully Digital System
●MP3 audio loads to unit w/USB drive
● Stores up to four (4) messages for triggered play
● Audio is stored in non-volatile Flash memory
● Messages are triggered with standard DIN cable
● 600 ohm (line out) and 8ohm (amplified) RCA-type output

Applications

The SMP 1304 is suggested for commercial applications that
require a reliable, user-friendly audio device. Ideal for Trade
Show Displays, Transit applications, Drive Thru's, Interactive
Kiosks, Alarm Systems, Theme Parks, Museums, and Voice
Evacuation messages.
www.premtech.com
