- Page 1 A22 Industrial Dust Collector (Bin Version) Operation and Maintenance Manual www.trelawnyspt.co.uk...
-
Page 4: Operation
Use of the machine without the others. these instructions could result in supplied filters is not recommended. damage to the A22 Vacuum and/or Trelawny cannot foresee all possible personal injury. If the machine is used to vacuum c i r c u m s t a n c e s... -
Page 5: Pre-Start Check
If the vacuum cleaner features this specific filter, its filtering capacity will have to be periodically checked. When contacting Trelawny SPT Ltd Complete HEPA Filter Kit. or their agents, always quote the 303.5377 The bracket of the floor attachment... - Page 6 OPERATION Starting Description of controls supplied pipe connector. Make sure power supply corresponds to the voltage and frequency indicated on the vacuum cleaner plate. IMPORTANT: Do not plug in the power socket with wet hands In the event of an extension being used, make sure this is in perfect condition, in compliance with EC 110v Motor...
-
Page 7: Operation And Maintenance
OPERATION & MAINTENANCE Using the filter cleaning Dust containment bin Do not place hands on sides of container near the guide pins system. This should be emptied when the while re-installing. vacuumed material has reached 3/4 If the vacuum cleaner becomes of its maximum capacity. -
Page 8: Maintenance
RECOMMENDED SPARES PART NUMBER DESCRIPTION 303.5275 “M” Cat Conical Cartridge Filter 303.5265 “M” Cat Anti-Static Cartridge Filter 303.5280 PTFE Conical Cartridge Filter TECHNICAL SPECIFICATIONS A22 110v and 230v Voltage Volts 110v & 230v 50Hz Power Watts 2300 Vacuum rate Mm/H2O 2500 Max. -
Page 9: Fault Finding
If problem has not been cured by any of the above actions, contact your local Trelawny SPT dealership for assistance. Machine storage Remove the filter and clean it, empty the container and store the vacuum cleaner in a place protected against condensation and at a temperature between 0°C and 40°C. - Page 10 EXPLODED VIEW - MACHINE BODY ITEM PART NUMBER DESCRIPTION NUMBER 303.5370 230V Motor Head Assembly 303.5372 115V Motor Head Assembly 303.5390 Chamber Kit 303.5590 50mm dia Flap 303.5375 Machine Body Kit 303.5395 Dust Container Kit 303.5440 Wheel (2 x required) 303.5430 Braked Castor Wheel 303.5460...
- Page 11 EXPLODED VIEW - FILTER ITEM No PART NUMBER DESCRIPTION 303.5490 Toggle Clamp (2 x required) 303.5275 “M” Cat Conical Cartridge Filter 303.5265 “M” Cat Anti-Static Cartridge Filter 303.5280 PTFE Conical Cartridge Filter 303.5620 Filter Chamber with Flap 303.5495 Handle 303.5345 Inlet Gasket 303.5505 Locking Pin...
- Page 12 EXPLODED VIEW - CONTAINER ITEM No PART NUMBER DESCRIPTION 303.5625 Container 303.5475 Handle (2 x required) 303.5450 Castor Wheel (3 x required) 303.5470 Adapter Washer for Castor Wheel (3 x required)
- Page 13 EXPLODED VIEW - FRAME ITEM No PART NUMBER DESCRIPTION 303.5610 Trolley 303.5420 Round head screw (4 x required) 303.5410 Galvanized toothed washer (4 x required) 303.5560 Lever Fulcrum (2 x required) 303.5555 Lever spacer (2 x required) 303.5545 Lever...
- Page 14 EXPLODED VIEW - ELECTRIC MOTOR...
- Page 15 All rights reserved. Any unauthorised use or copying of the contents or part thereof is prohibited. This applies to trademarks, model denominations, part numbers and drawings. Use only genuine Trelawny spares. The use of non-Trelawny spare parts invalidates the warranty.
- Page 16 Trelawny SPT Ltd 13 Highdown Road, Sydenham Industrial Estate, Leamington Spa, Warwickshire, CV31 1XT, United Kingdom Telephone: +44 (0)1926 883781 - Fax: +44 (0)1926 450352 Email: sales@trelawny.co.uk www.trelawnyspt.co.uk © TSPT UK 2017 Part No: 735.6015 issue 5.4.17...
