- Page 1 Instruction manual IKI Pro 14 IKI Pro 21 IKI Pro 28 IKI Pro 35 4/2019...
- Page 2 This instruction manual is intended for the owner or the person responsible for the upkeep of the sauna as well as for the electrician in charge of installation. Once installation is completed, the instruction manual must be handed over to the owner or manager. The purpose of the heater is to heat a sauna room to a temperature appropriate for sauna-bathing;...
-
Page 3: Table Of Contents
Contents Instructions for installation and laying of the stones ..................3 Connecting the heater to electricity ........................5 Circuit diagram ..............................6 Physical installation instructions for Pro-B2 control unit .................. 7 Heater measurements ............................9 Heater safety distances ............................. 9 Troubleshooting .............................. -
Page 4: Instructions For Installation And Laying Of The Stones
Option 1. Professional use: public baths, health clubs, etc. where the heater is active 12-18 hours a day (Ref. p. 9 for warranty specifications) Maximum need: IKI Pro 14 and 21 IKI Pro 28 IKI Pro 35 Kerkes, tetra small... - Page 5 Installation and stone-laying instructions Image 1 Image 2 Image 3 1. Lift and remove the heating 2. Put the guide back when the 3. Place about 6 small Kerkes element guide and place small stones have filled the lower half tetra stones on the top and in Kerkes tetra stones in between of the heater.
-
Page 6: Connecting The Heater To Electricity
Connecting the heater to electricity The heater is connected to the electric supply with a H07RN-F, or similar, rubber cable. The use of PVC- insulated cables is forbidden due to poor heat resistance. The electrical installation must be performed by a licenced electrician and must adhere to current legislation. -
Page 7: Circuit Diagram
Circuit diagram Electrical one-way switch connection for Pro14 Electrical two-way switch connection for Pro 14, 21 and 28 Electrical three-way switch connection for Pro 35 If the control unit (e.g. Pro-B2 or Wave) requires an additional contactor, we recommend a two- or three- way switch connection to distribute the power evenly to the control unit and the additional contactor. -
Page 8: Physical Installation Instructions For Pro-B2 Control Unit
Physical installation instructions for Pro-B2 control unit Instruction manual | IKI Pro electric heater Page 7... - Page 9 Instruction manual | IKI Pro electric heater Page 8...
-
Page 10: Heater Measurements
Heater Maximum Heater Heater model room size height width / depth stone capacity power IKI Pro 14 15-25 m³ 79 cm 88 / 44 cm 240 kg 13,8 kW IKI Pro 21 20-35 m³ 79 cm 88 / 44 cm... -
Page 11: Troubleshooting
Troubleshooting If the heater fails to heat up, check that • Electricity has been wired properly • Fuses are intact Timer switch is set for heating • The thermostat is set to a higher temperature than current room temperature • •... -
Page 12: Warranty
Warranty IKI Kiuas Ltd (the manufacturer) assures a warranty to its products as stipulated here, guaranteeing the quality and functionality of the products during the warranty period. The warranty applies to heaters sold and used in Finland. The warranty requires that the buyer follow the instructions regarding the placement of the heater, its installation, use and maintenance as well as those regarding the qualities of the stones used in the heater. - Page 13 You may only use tap water for the heater, and the heater or its surroundings may be washed with pressure washer or hose. 1. In case of a defect or malfunction, the buyer must always contact the manufacturer or sales agent before searching for the cause or attempting to repair it.
-
Page 14: Ventilation
Ventilation The ventilation in the sauna room needs to be considered carefully. Proper air-flow allows bathers to enjoy fresh, oxygen-rich air. The air should fully change 6 times an hour. The supply air inlet should be installed on the wall or the ceiling at about 500 mm above the heater. The supply air inlet vent should be 50-100 mm in diameter. -
Page 15: Warnings
Warnings 1. Staying in the hot sauna for long periods of time increases body temperature, which may be dangerous. 2. Keep away from the heater when it's hot. The stones and outer surface of the heater may cause burns when in contact with skin. 3. - Page 16 Copyright IKI Kiuas Plc | We reserve the right to make changes Instruction manual | IKI Pro electric heater Page 15...
