- Page 1 Instruction Manual Bedienungsanleitung Manuel d’utilisation Manuale di Istruzioni...
- Page 2 NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit horizonhobby.com and click on the support tab for this product. Meaning of Special Language The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product: WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage, and serious injury OR create a high probability of superfi...
-
Page 3: Table Of Contents
• Always disconnect the battery after charging, and let the batteries can cause fi re, collateral damage and injuries. charger cool between charges. • Always charge in a well-ventilated area. • Always terminate all processes and contact Horizon Hobby if the product malfunctions. Table of Contents Components ..............3 Air Mode Operation (Beginner Mode) ........9... -
Page 4: Box Contents
Box Contents • Blade ® Inductrix ® Switch Air • MLP4DSM Transmitter (RTF only) • 3.7V 25C 150mAh 1S Li-Po Battery • 4 AA Batteries (RTF only) • 1S USB Li-Po Charger First Flight Preparation Flying Checklist • Remove and inspect contents ❏... -
Page 5: Installing The Transmitter Batteries
Installing the Transmitter Batteries Replace the transmitter batteries when the power LED fl ashes and the transmitter beeps. CAUTION: NEVER remove the transmitter batteries while the model is powered on. Loss of model control, damage, or injury may occur. CAUTION: Risk of explosion if battery is replaced by an incorrect type. -
Page 6: Transmitter And Receiver Binding
Transmitter and Receiver Binding Your RTF transmitter comes prebound to the model. If you need to re-bind, follow the directions below. MLP4DSM Binding Procedure 1. Disconnect the fl ight battery from the quadcopter. 2. Center all trims on your transmitter. 3. -
Page 7: Led Codes
LED Codes Equipment LED Color LED Status Operation Solid Position 2; Quadcopter AS3X mode Purple Solid Position 1; Quadcopter Horizon mode Blue Solid Position 0; Quadcopter Stability mode Green Solid IDX Switch mode 1 Amber Solid IDX Switch mode 2 Flight control LED on White Solid... -
Page 8: Understanding The Primary Flight Controls
Understanding the Primary Flight Controls ® If you are not familiar with the controls of your Inductrix Switch Air wing and quadcopter, take a few minutes to familiarize yourself with them before attempting your fi rst fl ight. Quadcopter Operation To selct Quadcopter mode, with the aircraft and transmitter powered on and bound, press both sticks to the outside bottom corners for 3 seconds. -
Page 9: Flying The Switch™ Quadcopter
™ Flying the Switch Quadcopter Takeoff Increase the throttle until the model is approximately 2 ft. (600mm) off the ground and check the trim so the model fl ies as desired. Once the trim is adjusted, begin fl ying the model. Typical fl... - Page 10 Elevator Left Side View Elevator up Forward Left Side View Elevator down Backward Aileron and Rudder - Right Stick Top View Nose Yaws Left Right Stick to left Rear View Left...
- Page 11 Aileron and Rudder - Right Stick (continued) Top View Nose Yaws Right Right Stick to right Rear View Right...
-
Page 12: Air Mode Operation (Expert Mode)
Air Mode Operation (Expert mode) Throttle Left Side View Throttle up Climb Left Side View Descend Throttle down Elevator Left Side View Elevator up Forward Left Side View Elevator down Backward Aileron Rear View Aileron left Left Rear View Right Aileron right... -
Page 13: Hovercraft Operation
Rudder Top View Nose Yaws Left Rudder left Top View Nose Yaws Right Rudder right Hovercraft Operation The hovercraft base plate (BLH9805) and foam skirt (BLH9806) are not included with this product and are sold separately. Please refer to the manual for the Inductrix Switch (BLH9800) for operation in the two hovercraft modes;... -
Page 14: Post-Flight Inspection And Maintenance Checklist
Post-Flight Inspection and Maintenance Checklist √ Make sure the battery is not connected before cleaning. Remove dust and debris with a soft brush or Cleaning a dry, lint-free cloth. Motors Replace the motor when the model will not fl y steady or veers off when doing a climb out. Wiring Make sure the wiring does not block moving parts. -
Page 15: Exploded View
Exploded View Quadcopter Assembly Air Wing Assembly Replacement Parts Part # Description Part # Description 1 BLH8521 Pro Motor Set (4) 7 BLH9804 Main Frame 2 BLH8705 Propeller Set, White (4) 8 BLH9801 Propeller Set (4) 3 BLH9807 Canopy, Red 9 EFLB1501S25 3.7V 150mAh 1S 25C LiPo 4 BLH9803 Duct Set (2) -
Page 16: Limited Warranty
Product, (iv) attempted service by anyone other securely using a shipping carton. Please note that original boxes than a Horizon Hobby authorized service center, (v) Product not may be included, but are not designed to withstand the rigors purchased from an authorized Horizon dealer, or (vi) Product not of shipping without additional protection. -
Page 17: Warranty And Service Contact Information
Horizon Technischer Service service@horizonhobby.eu Hanskampring 9 European Union D 22885 Barsbüttel, Germany Sales: Horizon Hobby GmbH +49 (0) 4121 2655 100 FCC Information FCC ID (Transmitter): BRWDXMTX10 in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed... - Page 18 Compliance Information for the European Union EU Compliance Statement: BLH8380: Horizon Hobby, LLC hereby declares that this product is in compliance with the essential requirements and BLH8300: Horizon Hobby, LLC hereby declares other relevant provisions of the RED and EMC Directives.
- Page 19 Blade, the Blade logo, Inductrix, BNF and Bind-N-Fly logo, E-fl ite, SAFE, the SAFE logo, DSM, DSM2, DSMX, ModelMatch and the Horizon Hobby logo are trademarks or registered trademarks of Horizon Hobby, LLC. The Spektrum trademark is used with permission of Bachmann Industries, Inc. Futaba is a registered trademark of Futaba Denshi Kogyo Kabushiki Kaisha Corporation of Japan.
