- Page 1 How to Connect 3CX to NeoGate TA FXO Gateway Version: 1.0 Date: 2014.12.29 Yeastar Information Technology Co. Ltd...
-
Page 2: Table Of Contents
How to Connect 3CX to NeoGate TA FXO Gateway Contents 1. Introduction ........................3 2. Preparation ........................3 3. Connect 3CX to NeoGate TA810 ..................4 3.1 Create a SIP Trunk on 3CX ..................4 3.2 Configuration on TA810 ....................7 4. -
Page 3: Introduction
How to Connect 3CX to NeoGate TA FXO Gateway 1. Introduction This application note shows how to connect 3CX phone system to NeoGate TA FXO gateway via SIP trunking. This guide has been tested with NeoGate TA810 and 3CX phone system v12.0.35528.640. -
Page 4: Connect 3Cx To Neogate Ta810
How to Connect 3CX to NeoGate TA FXO Gateway Before connecting NeoGate TA810 to 3CX, you need to set a static IP address from the same LAN with the 3CX. Steps to set static IP for NeoGate TA810: 1. Download a DeviceFound tool from Yeastar website: FindTA.rar... - Page 5 Figure 4 VoIP Provider 3) Enter External Number and Authentication ID (You can enter any number that is not the same with extension numbers of 3CX, take 9999 as an example here). And click “Next”. Note: "Maximum simultaneous calls " is four in the free version of 3CX. You can also enter the number accordingly if you have bought license from 3CX.
- Page 6 How to Connect 3CX to NeoGate TA FXO Gateway Figure 5 Configure SIP Trunk 4) Configure the default destination of inbound route to IVR for the SIP trunk and click “Next”. Note: If you want to change the inbound route, you can double click the trunk you want on the "Ports/Trunk Status"...
-
Page 7: Configuration On Ta810
Path: Gateway→VoIP Settings→VoIP Server Settings Do not check "Enable Register", choose SIP protocol, and fill in the 3CX IP address, the VoIP server template will be configured as SPS mode. Figure 9 Configure the VoIP Server Template as SPS Mode... -
Page 8: Ip To Port
After saving and applying the changes, you will see the trunk is “OK” in “Line Status”. Path: StatusSystem StatusPort Status Figure 12 FXO Port Status 4. IP to Port In this section, we introduce how to achieve making outbound calls from 3CX through PSTN line on TA810. 8/12... - Page 9 How to Connect 3CX to NeoGate TA FXO Gateway Figure 13 IP to Port Step 1. Create one outbound route on 3CX. To make external calls from 3CX through TA810’s pstn trunk, you need to create one outbound route on 3CX. Click "Create Outbound Rule" on 3CX.
- Page 10 Now, you can use 3CX phone system’s extension to make external calls through the pstn 1 on TA810. Do not forget to add digit 9 before the called number cause prefix is set to 9 on 3CX outbound route. For example, if you want to call 15880270600, you need to dial 915880270600.
-
Page 11: Port To Ip
How to Connect 3CX to NeoGate TA FXO Gateway 5. Port to IP In this section, we configure incoming calls to 3CX through PSTN trunk on TA810. Figure 13 Port to IP Step 1. Create an inbound route on 3CX. - Page 12 Figure 15 Port to IP Route Page Step 3. Test a call. Dial the pstn trunk number 05955503301 on your mobile phone, the call will be routed to 3CX IVR. After hearing the IVR prompt, you can dial any extension number on 3CX. <The End>...
