SaltDogg SHPE0750 Series Installation Instructions Manual

Installation Instructions
SHPE0750 Series
SaltDogg Electric Drive
®
Poly Hopper Spreader
0.65 cubic yards
Serial Number 2300 and higher.
Table of Contents
General Information ...................................................................1
Warranty Information .................................................................1
Safety Precautions .....................................................................2
Installation Instructions .........................................................2-3
Spreader Operation .....................................................................4
Spreader Maintenance ...............................................................5
Repair Parts & Drawings ....................................................... 6-8
General Information
SHPE0750- spreader with standard length chute
SHPE0750X- spreader with extended length chute
Overall Length: 55-1/2 inches
Overall Width: 48 inches
Overall Height (installed): 28 inches
SHPE Empty Weight: 205 lbs
SHPEX Empty Weight: 214 lbs
Capacity Struck: .65 cu. yd.
Vehicle Requirements:
½ ton pick-up truck or utility vehicle with 500 lbs. capacity
minimum.
WARNING
Do not overload vehicle beyond the vehicle's GVWR or GAWR.
Check vehicle's load rating certification sticker for maximum
vehicle capacity.
Average Material Weights
Materials to use
Fine Salt-Dry
Coarse Salt-Dry
Sand/Salt 50/50 Mix-Dry
Note: To calculate the total spreader weight (including ice
control material), add the empty spreader weight plus the ice
control material and spreader accessories.
Weight (pounds per cubic yard)
2,250
1,431
2,700
Phone (440) 974-8888 • Fax (800) 841-8003
SPREADER WARRANTY INFORMATION
This warranty replaces all previous warranties and
no employee of this company is authorized to extend
additional warranties, or agreements, or implications
not explicitly covered herein.
Buyers Products Company warrants all parts of the
product to be free from defects in material and work-
manship for a period of one (1) year. Parts must be
properly installed and used under normal conditions.
Normal wear is excluded.
Any part, which has been altered, including modifica-
tions, misuse, accident, or lack of maintenance will not
be considered under this warranty.
The sole responsibility of Buyers Products Company
under this warranty is limited to repairing or replacing
any part(s), which are returned, prepaid, 30 days after
such defect is discovered, and returned part(s) are
found to be defective by Buyers Products Company.
Authorization from Buyers Products Company must
be obtained before returning any part. The following
information must accompany defective parts returned
to Buyers Products Company: RMA #, spreader model,
serial number, date installed, and distributor from
whom purchased.
Buyers Products Company shall not be liable for dam-
age arising out of failure of any unit to operate proper-
ly, or failure, or delay in work, or for any consequential
damages. No charges for transportation or labor
performed on any part will be allowed under
this warranty.
1
9049 Tyler Blvd. • Mentor, Ohio 44060
www.saltdogg.com
—continued inside
