- Page 1 USE AND MAINTENANCE INSTRUCTIONS SELF-PRIMING DIAPHRAGM PUMPS LIBELLULA 1/3" SERIES Read this user manual before installing, operating, using and maintaining this equipment. www.caffinipumps.it...
-
Page 2: Instruction For The Use And Maintenance - Libellula 1/3" Series - Vers
CAFFINI PUMPS DECLINES ALL AND EVERY LIABILITY FOR DAMAGE DUE TO NEGLIGENCE AND FAILURE TO COMPLY W ITH THE INSTRUCTIONS IN THIS MANUAL. CAFFINI PUMPS W ILL NOT BE LIABLE FOR DAMAGE CAUSED BY INCORRECT INTERPRETATION OF THE INSTRUCTIONS IN THIS MANUAL... -
Page 3: Table Of Contents
INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3" SERIES –vers. 01/16 INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3” SERIES - Vers. 1/16 TABLE OF CONTENTS page 1. PRESENTATION ..........................4 1. P RESENTATION … …………………………………………………………………………………………………………………………….... 4 ... -
Page 4: Presentation
3. MANUFACTURER The Libellula 1/3” series pumps are manufactured by CAFFINI CIPRIANO S.r.l. with offices in Lemignano di Collecchio (Parma) -‐ ITALY -‐ post code 43044 -‐ Via G. Di Vittorio n. 46 -‐ Tel. +39 0521 804325 Fax +39 0521 ... -
Page 5: Information On Plates
INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3” SERIES - Vers. 1/16 INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3" SERIES –vers. 01/16 4. INFORMATION ON PLATES Each pump has a nameplate that provides information about the pump. The nameplates are located on the gearbox ... -
Page 6: Use
INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3” SERIES - Vers. 1/16 INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3" SERIES –vers. 01/16 Electric motors: a)closed three-‐phase, self-‐ventilated externally insulated in class F, IP55 protection, unified Standards IEC or NEMA ... -
Page 7: Sound Level
INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3" SERIES –vers. 01/16 INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3” SERIES - Vers. 1/16 INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3" SERIES –vers. 01/16 7. SOUND LEVEL INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3"... - Page 8 INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3” SERIES - Vers. 1/16 INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3" SERIES –vers. 01/16 INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3" SERIES –vers. 01/16 Do n ot r efill f uel i n c losed a nd s carcely v entilated e nvironments. Do ...
-
Page 9: Handling And Transport
INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3” SERIES - Vers. 1/16 INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3" SERIES –vers. 01/16 10. HANDLING AND TRANSPORT The m achine c an o nly b e h andled w ith t he s uction a nd d elivery p iping d isconnected a nd w ith t he p ower s upply motor ... -
Page 10: Installation
INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3" SERIES –vers. 01/16 INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3” SERIES - Vers. 1/16 12. INSTALLATION With regard to the use of engines coupled with pump, reference is made and the Standards given by the manufacturers ... -
Page 11: B Efore S Tart
INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3" SERIES –vers. 01/16 INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3” SERIES - Vers. 1/16 Do n ot u se t he p ower s upply c able o f t he p ump t o l ift i t o r t ransport i t. It ... -
Page 12: Maintenance
INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3" SERIES –vers. 01/16 INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3” SERIES - Vers. 1/16 14. MAINTENANCE All maintenance operations must be carried out with machine still, disconnected from any feeders and disconnected ... -
Page 13: Spare Parts
INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3” SERIES - Vers. 1/16 INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3" SERIES –vers. 01/16 15. SPARE PARTS To o rder s pare p arts i ndicate: a) ... -
Page 14: Operating Problems: Causes And Solutions
INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3" SERIES –vers. 01/16 INSTRUCTION FOR THE USE AND MAINTENANCE - LIBELLULA 1/3” SERIES - Vers. 1/16 17. OPERATING PROBLEMS: CAUSES AND SOLUTIONS MALFUNCTIONING POSSIBLE C AUSE SOLUTION The ... -
Page 15: Features
65/min 37/min 47/min Reduction g ears ( RR) 1:43 1:38 1:30 A spare parts catalogue is attached to the use and maintenance manual. CAFFINI CIPRIANO SRL... - Page 16 CAFFINI CIPRIANO S.r.l. 43044 LEMIGNANO DI COLLECCHIO (Parma) - ITALY - Via G. Di Vittorio, 46 Tel. +39.0521.804325 - Fax +39.0521.804145 - info@caffinipumps.it w w w . c a f f i n i p u m p s .i t...
