beautyrest Simple Motion Owner's Manual And Reference Manual page 6

Installation Guide
Always use two people when setting up the adjustable base, moving or flipping the adjustable base.
STEP 1 Unpack Adjustable Base
Place the adjustable base box in a desired location
with the bottom of the box facing up. Remove the
binding straps and packing materials, making sure not to
puncture the box with any sharp objects.
Cut open box
STEP 2 Unfold The Adjustable Base
Important: Be careful of any pinch points while
unfolding the adjustable base.
STEP 3 Legs Installation
To install six legs, screw leg into the tapped holes on the
frame.
Do not over tighten.
STEP 4 Actuator Bracket Installation
A. Actuator bracket.
B.Remove the original two
pins and two R clips placed
inside the adjustable base.
C.Properly install actuator
bracket with adjustable
base by following correct
direction of sticker Green
to Green, Blue to Blue.
D.Install the actuator bracket
on the adjustable base.
E.Re-insert the two pins
and two R clips in same
holes. Make sure actuator
bracket is connected with
a djustable base.
STEP 5 Actuator Installation
A. Connect head and foot
actuator. Remove the original
pin and R clip placed inside
the adjustable base from the
bottom of actuator.
B.Re-insert the pin and R clip with actuator bracket.
Repeat for foot actuator.
6
