Summary of Contents for Westinghouse Beyond WBYCM2
- Page 1 WBYCM2...
- Page 2 Coffee Maker Owner’ s Manual...
-
Page 3: Definition Of Terms
Definition of Terms Read and Save These Instructions 1. Important Safeguards When using electrical appliances, basic safety precautions should always be followed, including the following: Hazards or unsafe practices which could result in serious WARNING! personal injury or death. Hazards or unsafe practices which could result in minor CAUTION! personal injury or product damage. -
Page 4: Additional Important Safeguards
Coffee Maker Owner’ s Manual Save These Instructions FOR HOUSEHOLD USE ONLY. Additional Important Safeguards: To disconnect, turn the appliance off, then remove plug from wall outlet. Do not use appliance for other than intended use. Be certain Lids are securely in place before operating appliance. Scalding may occur if the lid is removed during the brewing cycles. -
Page 5: Polarized Plug
If this appliance falls or accidentally becomes immersed in water or any other liquid, unplug it immediately. Do not reach into the water! Do not use this appliance after it has fallen into or has become immersed in water. Contact Consumer Service for examination and repair. - Page 6 Thank you for purchasing the Beyond Mill & Brew Coffee Maker. The Beyond Mill & Brew Coffee Maker integrates two products into one space-saving unit. The built-in coffee mill grinds your whole coffee beans to the desired level of coarseness (you...
- Page 7 3. Unpack Your Beyond Mill & Brew Coffee Maker Carefully remove the Beyond Mill & Brew Coffee Maker and all other contents from the carton. If there is any damage to the Coffee Maker, contact your Beyond retailer or contact Beyond Customer Relations at 1-800-233-9054 (in the US) between 8 - 5:30 CST, Monday through Friday, or by e-mail at consumer_relations@toastmaster.com...
- Page 8 Scratch resistant with a non-stick coating to prevent carafe from sticking. 8. SANI Card Slot (Model Number WBYSM2) When a SANI card is installed (optional, sold separately) the Beyond Coffee Maker can exchange information with an iCEBOX™. 9. Control Panel Allows you to manually set the clock, automatic brewing times, view/enter your Home Code and to manually start and stop brewing.
- Page 9 11. Overflow slot If too much water is poured into the reservoir the excess drains through this opening 12. Coffee Mill Includes a permanent stainless steel filter basket with integrated stainless steel blades 13. Coffee Mill Lid Latch Press in latch to release lid 14.
-
Page 10: Control Panel
Coffee Maker Owner’ s Manual Control Panel Use the control panel to program all of the Coffee Maker’s functions. On/Off: Press to toggle Coffee Maker on or off. Select: Press to select grind setting (see instructions on page 12). Hour: Press to set hours when setting the time manually. -
Page 11: Setting The Clock
5. Before Using Your Mill & Brew Coffee Maker for the First Time Clean the Carafe and Coffee Mill Assembly NOTE: Unplug the Coffee Maker during cleaning! NOTE: The Coffee Mill lid must be closed securely in order for the brew cycle to begin. NOTE: A time will also appear in the display. -
Page 12: Making Coffee
A 5-ounce cup is the American industry standard and is used by most coffee maker manufac- turers. The Beyond Coffee Maker makes a maximum of 10 five-ounce cups as indicated by the 10 coffee cup markings on the Water Window. Your favorite mug will accommodate approxi- mately two standard “cups”... - Page 13 Pause-and-Pour Your Coffee Maker is equipped with Pause & Pour. This feature allows you to pour a cup of coffee before your coffee is finished brewing. At any time while your coffee is brewing, you may remove the carafe from the warming plate and pour a cup of hot coffee. No coffee will drip from the brew chamber.
- Page 14 8. Adding Your Beyond Coffee Maker to Your iCEBOX Appliance Network Your iCEBOX can act as a network gateway and command center for the Beyond Connected Appliances, including the Beyond Microwave, Bread Maker and Coffee Maker. In order to net- work your Beyond Appliances, you must connect the SANI antenna to your iCEBOX, and also install SANI cards in the appliances you want to network.
- Page 15 NOTE: If your appliance fails to connect, press and hold the Network button on the appliance for 10 seconds, then attempt to connect again. You are now able to set the Coffee Maker’s brew schedule, start or stop brewing and check the Coffee Maker’s status from your iCEBOX screen.
- Page 16 Proportion The cups on the Beyond Coffee Maker are 5 ounces. Add approximately 1 spoon of coffee beans per every two cups of coffee to be brewed. NOTE: Do not place more than 8 spoons of beans in the mill.
-
Page 17: Cleaning And Maintenance
12. Cleaning and Maintenance Coffee is naturally oily. A build up of coffee oils on the Coffee Maker will adversely affect the taste of new pots of coffee. For best results, completely clean and dry all removable parts after every use. When cleaning your Coffee Maker, please observe the following precautions: §... -
Page 18: Troubleshooting Guide
Coffee Maker Owner’ s Manual 13. Troubleshooting Guide If the Coffee Maker lid is not closed securely brewing will not begin. If the lid is opened during the brew cycle, brewing will stop. To restart the brewing process, make sure the Coffee Mill lid is positioned correctly then close the Coffee Maker lid pressing down until the latch clicks into place. - Page 19 Warranty Service: To obtain warranty service, you must call our warranty service number at 1-800-233-9054 for return instructions on how to deliver the product, in either the original packaging or packaging affording an equal degree of protection to the Repair Center specified below.
