INSTRUCTION MANUAL
Air-powered Brad Nailer
F50M
IMPORTANT: Please read this manual carefully before using this product, and save it for reference.
This manual contains important safety and operating instructions. Read all instructions and follow them
with use of this product.
Residual Risks
Even when the tool is used as prescribed it is not possible to eliminate all residual risk factors. The following hazards may
arise in connection with the tool's construction and design:
1.
Damage to lungs if an effective dust mask is not worn.
2. Damage to hearing if effective hearing protection is not worn.
3. Wear eye protection.
4. Health defects resulting from vibration emission if the power
tool is being used over longer period of time or not adequately managed and properly maintained.
TABLE OF CONTENTS:
-TECHNICAL SPECIFICATIONS
-KEY PARTS DIAGRAM
-TYPES OF NAILS
-MAINTENANCE
-EXPLODED VIEW
NOTE: If any parts are missing or damaged, or if you have any questions, please contact with rongpeng@rongpeng.com
TECHNICAL SPECIFICATIONS
MAGAZINE CAPACITY
OPERATING PRESSURE
MAXIMUM PRESSURE
CF: Cubic Feet (the volumetric flow rate of air corrected to standardized conditions of temperature and pressure).
SAFETY GUIDELINES
This manual contains information that relates to PROTECTING PERSONAL SAFETY and PREVENTING EQUIPMENT PROBLEMS.
It is very important to read this manual carefully and understand it thoroughly before using the product. The symbols listed
below are used to indicate this information.
DANGER! Potential hazard that will result in serious injury or loss of life.
WARNING! Potential hazard that could result in serious injury or loss of life.
CAUTION! Potential hazard that may result in injury or damage to equipment.
PERSONAL SAFETY
These precautions are intended for the personal safety of the user and others working with the user. Please take time to read
and understand them. Make sure you read and understand this manual before using this tool. Make sure other users read
and understand this manual before they use the tool.
100 nails
70–110 PSI (4.8–7.5 bar)
120 PSI (8.3 bar)
-SAFETY GUIDELINES
-TECHNICAL INFORMATION
-OPERATING INSTRUCTIONS
-TROUBLESHOOTING
- PARTS LIST
NAILS
18-gauge brad nails (5/8–2")
AIR INLET
1/4"
WEIGHT
3 lb 6 oz (1.55 kg)
Advertisement
Related Manuals for Rongpeng F50M
Summary of Contents for Rongpeng F50M
- Page 1 -TYPES OF NAILS -OPERATING INSTRUCTIONS -MAINTENANCE -TROUBLESHOOTING -EXPLODED VIEW - PARTS LIST NOTE: If any parts are missing or damaged, or if you have any questions, please contact with rongpeng@rongpeng.com TECHNICAL SPECIFICATIONS MAGAZINE CAPACITY 100 nails NAILS 18-gauge brad nails (5/8–2") OPERATING PRESSURE 70–110 PSI (4.8–7.5 bar)
- Page 2 NOTE: The word “Note” is used to inform readers of something they need to know about the tool. • Do not use oxygen or any other combustible or bottled gas to power air-powered tools. Failure to observe this warning can cause explosion and serious personal injury or death. Use only compressed air to power air-powered tools.
- Page 3 Compatible compressors GUIDELINES FOR PROPER USE AND OPERATION Be sure to use a proper air compressor with RONGPENG Air-powered tools. The compressor that is being used must be able to supply appropriate amount of pressure (PSI) to the tool. ...
- Page 4 • Do not drive a nail on top of an existing nail. Failure to comply could lead to serious injury or loss of life. TYPES OF NAILS This RONGPENG Brad Nailer drives 18-gauge 5/8-2" (15-50 mm) long brad nails. This nailer can be used with a variety of shank types (e.g., ring, smooth, spiral) and a variety of coatings or nail compositions (e.g., Electro, mechanical, hot-dipped galvanized...
-
Page 5: Operating Instructions
OPERATING INSTRUCTIONS Loading Nails Disconnect the tool (1) from the air supply (2) (Fig. A). 2. Hold the Air-powered Brad Nailer firmly with one hand. Use the other hand to press the latch (1) on the magazine (2) and slide it back (Fig. - Page 6 CAUTION! Potential hazard that may result in injury or damage to equipment. • If the trigger is pressed a second time, the recoil of the nailer may lift the safety stand enough to allow a second nail to be fired, even if the operator has not lifted the tip of the safety stand. •...
- Page 7 functional. Verify that no parts are loose or missing and no parts are sticking or jammed. • Keep the magazine and the safety stand of the tool clean and free of any dirt or abrasive particles. Troubleshooting The following chart lists common issues and solutions. Please read it carefully and follow all instructions carefully. •...
- Page 8 O-ring 33.6 x 2 Valve bush Fixed seat Switch valve Screw spring Fixed magazine Sealing gasket O-ring 1.9 x 1.1 Pin 3 x 17.5 O-ring 24.2 x 3.1 Switch lever Safety plate Main piston O-ring 11.2 x 1.6 Trigger II O-ring 41.7 x 3 Trigger valve seat Self-lock nut M4...
