- Page 1 Installation, Operation and Maintenance Manual RB Weir Gate...
-
Page 2: Table Of Contents
Seal replacement …………………...………..…………………………..…………. Sizes 8”x8” to 48”x48”…………..…………………………………………. Sizes 49”x49” to 80”x80”…………..……………………………………… Trouble shooting …………………………………………………………………………………. ORBINOX reserves the right to change specifications without notice. ORBINOX CANADA, ORBINOX USA, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA WWW.ORBINOX.COM OBXC 05-2010... -
Page 3: Introduction
“General Arrangement Drawing” (GAD). The GAD is the drawing that is sent to and approved by the customer prior to the production of the weir gate. Orbinox as- sumes no responsibility or liability if the slide gate is not installed, operated and maintained in strict accordance to the procedures described in this manual. -
Page 4: Installation
INSTALLATION: CONCRETE WALL MOUNTED Required Materials: Orbinox RB Weir Gates are installed by means of Anchor Bolts. Depending on the size and working conditions they shall be either of the mechanical or chemical type. Note that as standard, anchor bolts and construction sealant are not supplied with the weir gate. - Page 5 Figure 2 Figure 1 ORBINOX reserves the right to change specifications without notice. ORBINOX CANADA, ORBINOX USA, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA WWW.ORBINOX.COM OBXC 05-2010...
- Page 6 Re-install the weir gate on the wall and tighten both anchor bolts. Figure 4 Figure 3 ORBINOX reserves the right to change specifications without notice. ORBINOX CANADA, ORBINOX USA, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA WWW.ORBINOX.COM OBXC 05-2010...
- Page 7 (this step is only for esthetics). Wipe away the excess sealant to leave a smooth finish. Figure 5 Figure 6 ORBINOX reserves the right to change specifications without notice. ORBINOX CANADA, ORBINOX USA, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA WWW.ORBINOX.COM OBXC 05-2010...
-
Page 8: Concrete Round Manhole Wall Mounted
INSTALLATION: WALL THIMBLE MOUNTED Required Materials: Orbinox Wall Thimble Mounted RB Weir Gates are installed by means of Hex Bolts. In order to avoid leakage between the wall thimble and the frame, construction sealant shall be used. (Sikabond Con- struction Sealant or equivalent, 200ml per meter of opening perimeter). For detailed information about the size and quantity of the required bolts, or any other specific installation notes or materials, please refer to the notes on the „General Arrangement Drawing‟. -
Page 9: Installation Of Stem Extension, Stem Guides And Floor Stand
(drill and tighten anchor bolts). ORBINOX reserves the right to change specifications without notice. ORBINOX CANADA, ORBINOX USA, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA WWW.ORBINOX.COM OBXC 05-2010... - Page 10 STEM EXTENSION, STEM GUIDES AND FLOOR STAND continued Figure 7 Figure 8 ORBINOX reserves the right to change specifications without notice. ORBINOX CANADA, ORBINOX USA, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA WWW.ORBINOX.COM OBXC 05-2010...
-
Page 11: Operation
For self-contained frame configurations, the slide is stopped by the yoke when it is fully closed. The RB weir gate is designed to be self-locking, so that the slide maintains its position in open, close or intermediate positions. -
Page 12: Maintenance
Orbinox does not recommend stocking any spare parts by the owner of the equipment as the weir gates are designed for a very long life cycle. If a repair part is required, please contact an Orbinox representative and provide the following information: Orbinox S/O number. -
Page 13: Seal Replacement
UHWMPE guide onto it. Finally, mate the whole unit to the previously positioned UHWMPE guide. ORBINOX reserves the right to change specifications without notice. ORBINOX CANADA, ORBINOX USA, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA WWW.ORBINOX.COM OBXC 05-2010... - Page 14 Revision - MODEL WEIR GATES MAINTENANCE: SEAL REPLACEMENT (MU 8”X8” TO 48”X48”) continued ORBINOX reserves the right to change specifications without notice. ORBINOX CANADA, ORBINOX USA, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA WWW.ORBINOX.COM OBXC 05-2010...
-
Page 15: Sizes 49"X49" To 80"X80
Note 1: After installing the new seal, apply grease on it to ease operation. Reassembly: Follow Steps 6 to 1. ORBINOX reserves the right to change specifications without notice. ORBINOX CANADA, ORBINOX USA, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA WWW.ORBINOX.COM OBXC 05-2010... - Page 16 Revision - MODEL WEIR GATES MAINTENANCE: SEAL REPLACEMENT (49”X49” TO 48”X48”) continued ORBINOX reserves the right to change specifications without notice. ORBINOX CANADA, ORBINOX USA, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA WWW.ORBINOX.COM OBXC 05-2010...
-
Page 17: Trouble Shooting
Dirty stem and/or stem Clean and lubricate stem and/or nut. stem nut. ORBINOX reserves the right to change specifications without notice. ORBINOX CANADA, ORBINOX USA, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA WWW.ORBINOX.COM OBXC 05-2010...
