- Page 1 Installation, Operation and Maintenance Manual RR & RC Flap Gates...
-
Page 2: Table Of Contents
Cleaning and lubrication …………………………………………………………… RC Seal replacement ……………..…..……..……………………..……………... RR Seal replacement ….…………..…..……..……………………….…………….. Trouble shooting …………………………………………………………………………………. ORBINOX reserves the right to change specifications without notice. ORBINOX CANADA, ORBINOX USA, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA WWW.ORBINOX.COM OBXC 06-2010... -
Page 3: Introduction
The manual makes reference to the “General Arrangement Drawing” (GAD). The GAD is the drawing that is sent to and approved by the customer prior to the production of the gate. Orbinox assumes no responsibility or liability if the RR or RC Flap Gate is not installed, operated and main- tained in strict accordance to the procedures described in this manual. -
Page 4: Installation
(see Figure 1). Figure 1 ORBINOX reserves the right to change specifications without notice. ORBINOX CANADA, ORBINOX USA, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA WWW.ORBINOX.COM OBXC 06-2010... - Page 5 Figure 2 and 3). Be sure not to get sealant on the gate‟s seals or guides as this may cause leak- age or damage. Figure 2 Figure 3 ORBINOX reserves the right to change specifications without notice. ORBINOX CANADA, ORBINOX USA, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA WWW.ORBINOX.COM OBXC 06-2010...
- Page 6 (this step is only for esthetics). Wipe away the excess sealant to leave a smooth finish. Figure 4 Figure 5 ORBINOX reserves the right to change specifications without notice. ORBINOX CANADA, ORBINOX USA, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA WWW.ORBINOX.COM OBXC 06-2010...
-
Page 7: Standard Flange Mounted
INSTALLATION: WALL THIMBLE MOUNTED Required Materials: Orbinox Wall Thimble Mounted RR and RC Flap Gates are installed by means of Hex Bolts. In order to avoid leakage between the wall thimble and the frame, construction sealant shall be used. (Sikabond Construction Sealant or equivalent, 206oz/ft or 200ml/m of opening perimeter). For de- tailed information about the size and quantity of the required bolts, or any other specific installation notes or materials, please refer to the notes on the „General Arrangement Drawing‟. -
Page 8: Operation
The RR and RC Flap Gate is operated (opened) automatically, when the seating water head is higher than the unseating water head. ORBINOX reserves the right to change specifications without notice. ORBINOX CANADA, ORBINOX USA, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA WWW.ORBINOX.COM OBXC 06-2010... -
Page 9: Maintenance
Orbinox does not recommend stocking any spare parts by the owner of the equipment as the flap gates are designed for a very long life cycle. If a repair part is required, please contact an Orbinox representative and provide the following information: Orbinox S/O number. -
Page 10: Rc Seal Replacement
Step 2: Remove seal (item 6) and replace it with the new seal. Reassembly: Follow Steps 2 to 1. ORBINOX reserves the right to change specifications without notice. ORBINOX CANADA, ORBINOX USA, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA WWW.ORBINOX.COM OBXC 06-2010... - Page 11 MAINTENANCE: SEAL REPLACEMENT MAINTENANCE: RR SEAL REPLACEMENT continued Figure 6 Figure 7 ORBINOX reserves the right to change specifications without notice. ORBINOX CANADA, ORBINOX USA, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA WWW.ORBINOX.COM OBXC 06-2010...
-
Page 12: Rr Seal Replacement
MAINTENANCE: RC SEAL REPLACEMENT The following procedure describes how to replace the RR Flap Gate‟s seal. The flap shall be secured by lifting it to the open position with a crane. In case it cannot be secured in the open position, the flap should be first removed prior to the seal replacement. - Page 13 FLAP GATES MAINTENANCE: SEAL REPLACEMENT MAINTENANCE: RC SEAL REPLACEMENT continued Figure 8 ORBINOX reserves the right to change specifications without notice. ORBINOX CANADA, ORBINOX USA, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA WWW.ORBINOX.COM OBXC 06-2010...
-
Page 14: Trouble Shooting
Leakage through the seal Damaged seal. Replace seal. ORBINOX reserves the right to change specifications without notice. ORBINOX CANADA, ORBINOX USA, ORBINOX SPAIN, ORBINOX UK, ORBINOX FRANCE, ORBINOX GERMANY, ORBINOX INDIA, ORBINOX CHINA WWW.ORBINOX.COM OBXC 06-2010...
