Iron Bow CLINiC 2x User Manual

Clinical care device
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
™
CLINiC
2x
Clinical Care Device
User Guide
Document Version 2.6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLINiC 2x and is the answer not in the manual?

Questions and answers

Related Manuals for Iron Bow CLINiC 2x

Summary of Contents for Iron Bow CLINiC 2x

  • Page 1 ™ CLINiC Clinical Care Device User Guide Document Version 2.6...
  • Page 2 Copyright © 2018 Iron Bow Technologies All Rights Reserved. Specifications subject to change without notice. For general inquiries, contact: Iron Bow Healthcare Solutions 2303 Dulles Station Boulevard, Suite 400 Herndon, VA 20171 Toll: 800.338.8866 Tel: 703.279.3000 www.ironbowhealthcare.com For support, contact: Iron Bow Client Service Center Toll: 833.476.6269 (833.IRONBOW)

  • Page 3: Table Of Contents

    CLINiC Administration ..........................18 Accessing the Codec Web Interface ........................18 Change Sleep Settings ............................18 Change Call Settings ............................18 Manage Favorites ............................... 19 Adjusting Audio Gain ............................19 Appendix: Mounting Information ......................20 Specifications ............................21 Copyright 2018 Iron Bow Technologies...
  • Page 4 Figure 2. CLINiC 2x system components ....................... 6 Figure 3. CLINiC 2x Sound deflector ........................7 Figure 4. CLINiC 2x power, network, data, and audio/video ports (left and right view) ........7 Figure 5. CLINiC 2x audio ports on the integrated control panel ................. 8 Figure 6.

  • Page 5: Introduction

    Introduction The CLINiC from Iron Bow Healthcare Solutions is a purpose-built telehealth video and consultation device that enables the delivery of clinical healthcare at a distance. The CLINiC includes a video codec, a high definition video camera, built-in microphone, 27” display, audio speakers and an intuitive touch-control panel. The CLINiC enables high quality video and audio calls between two parties or more.

  • Page 6: System Description

    2 Camera Height/Tilt Adjust 3 Integrated 27” LED 16:9 display ® 4 Integrated Polycom RealPresence Group 310 codec (in custom enclosure) 5 Touch control panel with integrated downward-facing speakers Figure 2. CLINiC 2x system components Copyright 2018 Iron Bow Technologies...

  • Page 7: Connections

    Description 10/100/1G Ethernet USB ports (future use) IEC power inlet HDMI input DB9 expansion VGA (HD15) input control port (future use) Figure 4. CLINiC 2x power, network, data, and audio/video ports (left and right view) Copyright 2018 Iron Bow Technologies...

  • Page 8: Figure 5. Clinic 2X Audio Ports On The Integrated Control Panel

    Description 1 Headphones audio output 2 Stethoscope audio input Figure 5. CLINiC 2x audio ports on the integrated control panel Copyright 2018 Iron Bow Technologies...

  • Page 9: Getting Started

    Figure 6. CLINiC 2x rear view with codec power sensor Powering On the CLINiC Connect the peripherals to the HDMI and/or VGA ports of the CLINiC before connecting the CLINiC to AC power.
  • Page 10 Touch and hold the power sensor. Release the power sensor when the light indicator changes color and wait until the codec is off.  Touch and hold the power sensor again to restart the codec. Copyright 2018 Iron Bow Technologies...

  • Page 11: Control Panel Functions

    Pan and tilt the camera. Enable or disable self-view mode. Decrease speaker volume. Increase speaker volume. Mute or unmute microphone. Enable or disable headphone mode for private listening. Enable or disable stethoscope mode. Figure 7. Control panel functions Copyright 2018 Iron Bow Technologies...

  • Page 12: Managing Calls

    (see CLINiC Administration). To place a call to the auto dial address: Press on the integrated control panel. Copyright 2018 Iron Bow Technologies...

  • Page 13: Managing Video Settings

    Enabling and Disabling Self-View Mode You can display or hide the self-view window on the screen. To enable self-view:  Press on the integrated control panel. To disable self-view:  Press again on the integrated control panel. Copyright 2018 Iron Bow Technologies...

  • Page 14: Zooming Camera In And Out

    Panning and Tilting Camera (EagleEye Acoustic Camera) The camera on the CLINiC 2x, the Polycom EagleEye Acoustic camera, supports electronic pan and tilt functionality. With electronic panning and tilting you can control which area of the full scene will be zoomed-in and displayed on the screen. This is illustrated in the following diagram.

  • Page 15: Managing Audio Settings

    To decrease speaker and headphone volume:  Press and hold the icon on the integrated control panel, immediately below the speakerphone symbol until the desired sound level is achieved. Copyright 2018 Iron Bow Technologies...

  • Page 16: Enabling And Disabling Audio Privacy Listening Mode

    The associated LED will turn off. Adjusting Transmission Audio Gain You can adjust the gain of the audio signal transmitted from the codec to optimize the audio experience at the remote end (see CLINiC Administration). Copyright 2018 Iron Bow Technologies...

  • Page 17: Sharing Content From Connected Devices

    Upon restart, the button assignment is reversed, meaning that is associated with the VGA source and associated with the HDMI source.  If you desire to reverse the setup, repeat the steps above. Copyright 2018 Iron Bow Technologies...

  • Page 18: Clinic Administration

    You can change the way calls are answered and placed from the CLINiC. To edit call settings: 1. In the web interface, go to Admin Settings > General Settings > System Settings > Call Settings. 2. View and configure the settings as desired and save your changes. Copyright 2018 Iron Bow Technologies...

  • Page 19: Manage Favorites

    You can adjust the gain of the audio signal transmitted from the codec to optimize the audio experience at the remote end. To adjust Transmission Audio Gain: 1. In the web interface, go to Admin Settings > Audio/Video > Audio. 2. Configure the Transmission Audio Gain value in dB. Copyright 2018 Iron Bow Technologies...

  • Page 20: Appendix: Mounting Information

    Appendix: Mounting Information The following figure is not to scale and provided for dimensional information only. Figure 8. CLINiC 2x rear view and mounting holes location Copyright 2018 Iron Bow Technologies...

  • Page 21: Specifications

    1 x HDMI (dedicated to display) Audio Input/Output Input Microphone (integrated with the EagleEye Acoustic camera) 1 x 3.5mm (for stethoscope) 1 x HDMI Integrated stereo speakers; 2 x 5 Watts Output 1 x 3.5mm (for headphone) Copyright 2018 Iron Bow Technologies...
  • Page 22 Weight 21.8 lbs. Mounting Compatible with 100mm x 100mm VESA mounts (refer to the Appendix for mounting hole location and required hardware) Electrical 100-240V~50/60Hz, 1.9A Integrated auto sensing power supply 1 x IEC type inlet Copyright 2018 Iron Bow Technologies...
  • Page 23 2303 Dulles Station Boulevard, Suite 400 Herndon, VA 20171 Toll: 800.338.8866 Tel: 703.279.3000 www.ironbowhealthcare.com...
