OPERATORS' GUIDE
REL-2000SA
PDC-2000
SINGLE ACTING HYDRAULIC CUTTING TOOLS
WARNING
All information found in this guide
must be read and understood before
use or testing of this tool.
Failure to read and understand these warnings
and safe handling instructions could result in
severe personal injury and or death.
DISTRIBUTED BY
2000 Series Manual 02-15
1
Advertisement
Related Manuals for Reliable Equipment 2000 Series
Summary of Contents for Reliable Equipment 2000 Series
- Page 1 All information found in this guide must be read and understood before use or testing of this tool. Failure to read and understand these warnings and safe handling instructions could result in severe personal injury and or death. DISTRIBUTED BY 2000 Series Manual 02-15...
- Page 2 DISTRIBUTED BY The information in this manual is intended to guide the user in the use and application of this tool. It is not intended as a substitute for proper training and experience in safe work practices for this type of equipment. CAUTION Consult your supervisor or safety personnel if you have any questions regarding the safe operation of this tool.
- Page 3 TABLE OF CONTENTS DISTRIBUTOR INFORMATION ..........2 TABLE OF CONTENTS & TOOL REGISTRATION ..... 3 REL-2000SA - DESCRIPTION & TOOL SPECIFICATIONS ..4 PDC-2000 - DESCRIPTION & TOOL SPECIFICATIONS ..5 SAFETY INFORMATION AND WARNINGS ......6-10 OPERATING INSTRUCTIONS ..........10 DAILY MAINTENANCE &...
- Page 4 Length: 17.5 in. along the line. Width: 6.5 in. REL-2000SA SINGLE ACTING HYDRAULIC 2000 SERIES CUTTING TOOL MAXIMUM CAPACITY Soft Copper Jacket 2” This guillotine style cutter features up to a 2 inch cutting capacity, 360 rotating head, and a built- Aluminum Jacket 2”...
- Page 5 Head opens Weight: 16.5 lb. for cable insertion Length: 17.5 in. along the line Width: 6.5 in. PDC-2000 SHOWN PCU-2000 INCLUDES COUPLERS PDC-2000 DOUBLE ACTING HYDRAULIC CUTTING TOOL MAXIMUM CAPACITY This guillotine style cutter features up to a 2 inch Soft Copper Jacket 2”...
- Page 6 BEFORE USING THIS TOOL, READ THE WARNINGS and the recommended practices described in this manual. Failure by the operator to read and fully understand these warnings will leave this person unqualified to use and operate this tool. Property damage, severe personal injury, and/or death could result by not following these warnings.
- Page 7 SAFE OPERATION & CARE USE THIS TOOL FOR ITS INTENDED PURPOSE ONLY Any other use can result in injury or property damage. INSPECT TOOL BEFORE USE. Replace any worn, damaged or WARNING missing parts. A damaged or improperly assembled tool may malfunction, injuring operator and/or nearby personnel.
-
Page 8: Hoses And Fittings
fl uid is hot. Failure to observe this warning could result in serious injury. IF YOU HAVE ANY QUESTIONS REGARDING THE SAFE USE AND/OR OPERATION OF THIS TOOL, CONSULT YOUR AREA SUPERVISOR, OR CONTACT RELIABLE EQUIPMENT AT 800-966-3530... -
Page 9: General Safety
Operation/Safety methods may vary in accordance with the working guidelines established by each utility or utility contractor. For your own safety, ensure that you fully comply with WARNING all safe operation guidelines required by your employer. ELECTRICAL SHOCK HAZARD Always wear and use the necessary clothing, equipment and safety practices to protect against electrical shock. - Page 10 Failure to observe this warning could result in serious injury REL - 2000 SERIES OPERATION Do not cut live conductors. Hardened metals may fl y when severed.
-
Page 11: Daily Maintenance
Inspect for wear and damage. Worn or damaged parts may malfunction during operation. All parts must be replaced with new parts if signs of wear or damage are evident. BEFORE USING THIS PRODUCT RELIABLE EQUIPMENT & SERVICE CO., INC. READ THE SAFETY WARNINGS 92 Steamwhistle Drive • Ivyland, PA 18974 • USA and recommended practices described Phone: 215-357-3500 •... - Page 12 REL-2000SA -CUTTING TOOL PARTS DRAWING NOTE: # 21 & 28 have been tightened to 30-40 Foot Pound of totque, and secured using Blue LOCTITE on the nuts.
- Page 13 SPACER, BLADE (Incl. w/ #4 Cutter Assy.) R23037 GUIDE, BLADE (Incl. w/ #4 Cutter Assy.) R23550 SEAL KIT * ITEMS IN SEAL KIT Contact RELIABLE EQUIPMENT at 800-966-3530 if you have any questions related to the instructional information found in this manual.
- Page 14 PDC-2000 -CUTTING TOOL PARTS DRAWING NOTE: # 21 & 28 have been tightened to 30-40 Foot Pounds of torque, and secured using Blue LOCTITE on the nuts.
- Page 15 PDC- 2000 PARTS LIST PART PART # MOVING BLADE ................1 R23001 RETAINING PLATE ................2 R23002 PIVOT PIN ..................1 R23003 HINGED CUTTER ASSY. (Incl. 21, 28, 29, 30, 31) ......1 R23004A SMALL STUD ..................3 R23005 LARGE STUD ...................2 R23006 GUIDE ROLL ..................1 R23007 CONNECTING PIN ................1 R23008...
- Page 16 Date Parts or Service Required If you have any questions regarding the information found in this manual please contact RELIABLE EQUIPMENT at the address, phone or fax numbers shown below. 301 Ivyland Road • Warminster, PA 18974 Phone: 800-966-3530 • Fax: 215-357-9193...
