OPERATORS' GUIDE
3000 SERIES
PDC-3000 SHOWN
PCU-3000 INCLUDES COUPLERS
REL-3000SA
PDC-3000 / PCU-3000
SINGLE ACTING
DOUBLE ACTING
HYDRAULIC CUTTER
HYDRAULIC CUTTER
The 3000 Series guillotine-type cutter will make a straight, clean cut every time.
These cutters can be used for cutting a wide range of electrical conductors up to 3.35 inch.
WARNING
All information found in this guide
must be read and understood before
use or testing of this tool.
Failure to read and understand these warnings
and safe handling instructions could result in
severe personal injury and or death.
DISTRIBUTED BY
1
3000 Series Cutter Manual 04-15
Advertisement
Related Manuals for Reliable Equipment 3000 Series
Summary of Contents for Reliable Equipment 3000 Series
- Page 1 DOUBLE ACTING HYDRAULIC CUTTER HYDRAULIC CUTTER The 3000 Series guillotine-type cutter will make a straight, clean cut every time. These cutters can be used for cutting a wide range of electrical conductors up to 3.35 inch. WARNING All information found in this guide must be read and understood before use or testing of this tool.
- Page 2 DISTRIBUTED BY REGISTRATION UPON RECEIPT OF THIS TOOL, COMPLETE THE REGISTRATION BELOW. COMPANY _____________________________________________________________ ADDRESS _____________________________________________________________ ________________________________________________________________________ PHONE _______________________ FAX____________________________________ SERIAL NUMBER _______________________________________________________ DATE OF PURCHASE ___________________________________________________ DEALER NAME _________________________________________________________...
- Page 3 THIS SYMBOL INDICATES ITEMS OF EXTREME IMPORTANCE. Safety of user and others may be in jeopardy if these instructions are not read and understood. RELIABLE EQUIPMENT & SERVICE CO., INC. NOTICE 301 Ivyland Road • Warminster, PA 18974 • USA Phone: 215-357-3500 •...
- Page 4 PDC-3000 DOUBLE ACTING HYDRAULIC CUTTING TOOL FEATURES The 3000 Series guillotine-type cutter will make a straight, clean cut every time. These cutters can be used • Lightweight, compact guillotine for cutting a wide range of electrical conductors. Head design provides a clean, positive cut.
- Page 5 • 360 head eliminates hose twisting. and comfort. • Built-in Auxiliary Handle System Single-Acting 3000 SERIES - MAXIMUM Capacity (Jaw Opening) 3.35 inch. CONDUCTOR CAPACITY Force @ 10,000 psi (690 bar) 28,048 lb. Return @ 5,000 psi (345 bar) 10,445 lb.
- Page 6 BEFORE USING THIS TOOL, READ THE WARNINGS and the recommended practices described in this manual. Failure by the operator to read and fully understand these warnings will leave this person unqualified to use and operate this tool. Property damage, severe personal injury, and/or death could result by not following these warnings.
- Page 7 SAFE OPERATION & CARE USE THIS TOOL FOR ITS INTENDED PURPOSE ONLY Any other use can result in injury or property damage. INSPECT TOOL BEFORE USE. Replace any worn, damaged or WARNING missing parts. A damaged or improperly assembled tool may malfunction, injuring operator and/or nearby personnel.
- Page 8 HOSES AND FITTINGS There exists the potential for shock in using anything other than certifi ed nonconductive hoses and hydraulic oil with dielectric properties, when using system components near energized electrical lines. Failure to recognize these conditions could cause WARNING electrocution.
- Page 9 Operation/Safety methods may vary in accordance with the working guidelines established by each utility or contractor. For your own safety, ensure that you fully comply with all safe operation guidelines required by your employer. WARNING ELECTRICAL SHOCK HAZARD Always wear and use the necessary clothing, equipment and safety practices to protect against electrical shock.
- Page 10 OPERATION Do not cut live conductors. Hardened metals may fl y when severed. Take necessary precautions. wear safety glasses. Keep all body parts away from cutting blades and moving parts. WARNING Failure to follow these rules can result in serious personal injury or death. Read entire manual prior to using this tool.
- Page 11 Failure to observe all warnings and instructions could result in property damage, severe personal injury, and/or death. RELIABLE EQUIPMENT & SERVICE CO., INC. 301 Ivyland Road • Warminster, PA 18974 • USA Phone: 215-357-3500 • Fax: 215-357-9193...
- Page 12 PDC-3000 PARTS DRAWING RELIEF VALVE DO NOT ADJUST!
- Page 13 PDC- 3000 PARTS LIST PART PART # CYLINDER ....................1 R30001 RAM ......................1 R30002 INNER PISTON ..................... 1 R30003 MOVING BLADE ................... 1 R30004 RAIL, HINGED SIDE ..................1 R30005 RAIL, HANDLE SIDE ..................1 R30006 HINGED CUTTER ..................1 R30007 PIVOT PIN .....................
- Page 14 REL - 3000SA PARTS DRAWING...
- Page 15 REL- 3000 PARTS LIST PART PART # R30001 CYLINDER R30052 R30004 MOVING BLADE R30005 RAIL, HINGED SIDE R30006 RAIL, HANDLE SIDE R30007 HINGED CUTTER R23003 PIVOT PIN R23014 RETAINING RING R30010 SIDE PLATE R23006 LARGE STUD R23005 SMALL STUD R23010 DETENT PIN R23008 BOLT, RETAINING...
- Page 16 Date Parts or Service Required If you have any questions regarding the information found in this manual please contact RELIABLE EQUIPMENT at the address, phone or fax numbers shown below. 301 Ivyland Road • Warminster, PA 18974 Phone: 800-966-3530 • Fax: 215-357-9193...
