TS-1 Series
Continuous Degaussing System
Operation and Installation Manual
www.GarnerProducts.com
(800) 624-1903
10620 Industrial Ave. Suite 100
Roseville, CA 95678
Manufactured in the U.S.A
PN 4075-364E
TS-1 Operation and Installation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TS-1 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Garner TS-1 Series

Summary of Contents for Garner TS-1 Series

  • Page 1 TS-1 Series Continuous Degaussing System Operation and Installation Manual www.GarnerProducts.com (800) 624-1903 10620 Industrial Ave. Suite 100 Roseville, CA 95678 Manufactured in the U.S.A PN 4075-364E TS-1 Operation and Installation Manual...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNINGS  GENERAL INFORMATION  INSPECTION  INTRODUCTION  MAGNETIC FIELDS  AGNETIC FIELDS MEASURED AROUND PERIMETER PACE MAKER USERS: WARNING SPECIFICATIONS  INSTALLATION  OWER EQUIREMENTS OLTAGE ELECTION EFERENCE WARNING NPUT OLTAGE ONFIGURATION OWER LOCK OCATION OOLING OPERATION  ONTROLS AND NDICATORS VERVIEW EGAUSSING NSTRUCTIONS DLT M EGAUSSING NSTRUCTIONS FOR EDIA...

  • Page 3: Warnings

    WARNINGS WARNING HIGH VOLTAGE! NEVER Power up this equipment with covers or safety features removed. Even when the equipment is powered down, high voltage (up to 1,000 Volts) can be present inside the chassis. WARNING! NEVER remove the ground pin from the power cord nor use a plug adaptor that doesn’t provide grounding continuity.

  • Page 4: General Information

    Inspect the degausser for shipping damage as soon as it is unpacked. If the degausser or any accessories are damaged or fail to operate correctly, notify carrier and Garner Products, Inc. immediately. For assistance from Garner Products, Inc. call (916) 784- 0200 or fax (916) 784-1425.

  • Page 5: Specifications

    SPECIFICATIONS Power Supply (TS-1): Selectable: 95~105, 105~115, 115~125, 215~225, 225~235 or 235~240. See “Input Voltage Configuration” section of this manual. Power Consumption 100V: Under Standby 0.3A While charging 5.0A (TS-1): At the time of ERASE 0.6A 110V: Under Standby 0.25A While charging 4.5A At the time of ERASE 0.55A 120V: Under Standby 0.2A...

  • Page 6: Installation

    TS-1 input voltage is configured to match the voltage from the power mains the TS-1 will plug into. Call Garner Products, Inc. if the voltage listed is not compatible with your voltage or if you have any questions. International customers call 011 916 784-0200.

  • Page 7: Input Voltage Configuration Warning

    WARNING Input Voltage Configuration The TS-1 model is equipped with a voltage selection block allowing the TS-1 to be configured for use in any country. To check or change the voltage configuration of the TS-1, follow the steps listed below: All trouble shooting and wiring checks must be performed by a qualified electrician or authorized plant personnel.

  • Page 8: Power Plug

    Power Plug Plug the EIA connector attached to the power cord supplied into the receptacle on the back of the TS-1. Fuse Block Located behind the removable panel on the front side of the TS-1, there are six separate fuses, one each for 100, 110, 120, 220, 230 & 240 VAC power. Only one fuse is used at a time.

  • Page 9: Degaussing Instructions

    The second pass at 90 degrees will correct this condition. If you have any questions, please call Garner Products, Inc. at 1-800-624-1903 or 916- 784-0200. First Pass...

  • Page 10: Display Messages

    Action LCD Display Description Total Erase Cycles: The left counter indicates the total number of times the GARNER PRODUCTS Step 1: right counter reached 50,000. The right −− Press POWER counter indicates the total number of button ON erase cycles on the TS-1 up to 49,999.

  • Page 11: Error Codes

    TS-1 will clear the error. Turn the TS-1 back on and press the ERASE button. The media in the degaussing chamber will be erased if the field is sufficient otherwise the “Gauss Error” will persist on the LCD screen. If error persists, call Garner Products technical support.

  • Page 12: Change Batteries

    Change Batteries LCD displays “WARNING: REPLACE AA BATTERIES” or “WARNING: REPLACE ‘D’ BATTERIES”. This message indicates that the AA OR D cell batteries used in the TS-1 are becoming weak and should be replaced at the earliest opportunity. Action: Replace AA or D batteries. Step 1 Unplug the TS-1 from the power mains.

  • Page 13: Parts List Model

    PARTS LIST MODEL TS-1 Part Number Description 1500-040 Capacitor, 15,000uF 400VDC 225-0033 Filter assy 225-0034 Fan guard, internal 250-0015 Handle, recessed pull 356-0001 Relay, 25A 3500-056 Fan, 115V 3700-002 Sensor, reflective 3700-006 Display, 2x16 serial LCD 398-0073 Power cord set, 10A 120V 2800-027 High point grounding contact 3900-002...

  • Page 14: Declaration Of Conformity

    Declaration of Conformity Page 13 TS-1 Operation and Installation Manual...

  • Page 15: Warranty

    Garner or a Garner authorized service provider; (g) to a product or part that has been modified to alter functionality or capability without the written permission of Garner; or (h) if any Garner serial number has been removed or defaced.
