Page 1
OPERATING AND SERVICE MANUAL 110 JAH and 200 JAH 150 East Sharon Street Le Center, MN 56057 Office: 507-252-3033 Email: s ales@vsinnovation.com...
Page 2
VSI is under no liability or obligation of any kind with respect to an issue with a VSI product that is directly or indirectly attributable to normal wear, corrosion, neglect,...
Page 3
Valves As you are looking at your machine you will notice there are three valves. The valve located on the bottom of the tank/suction line is used to shut off the flow to the pump during transport or any time you need to isolate the tank from the pump. This valve needs to be opened during operation to provide flow to the pump.
Page 4
Filling The Machine The first step in mixing a batch of hydroseed is filling the machine with water. Your machine comes standard with a garden hose fill connection that is located at the top of the tank. Thread the yellow female camlock connection to your garden hose and connect it to the black male connection point.
Page 5
Mixing a Load of Hydroseed We recommend running a granular paper mulch in our hydroseeders for the best performance. Wood mulch is NOT recommended and could damage the pump and clog the system. Once your tank is ¾ full, start the engine. Make sure your agitation and tank valves are completely open (See picture LEFT) Mixing instructions are also labeled on each tank near the lid (See picture RIGHT) When the engine has warmed to operating temperature, increase the throttle until the...
Page 6
Applying the Hydroseed Connect as many hoses to your machine as you need, dragging them out as you connect each section. Finally, connect the gun to the hose. Make sure the gun valve is closed before opening the hose valve on the hydroseeder. Keep the engine running at maximum rpm to provide the best performance at the gun.
Page 7
Cleaning the Hydroseeder The final step in hydroseeding is cleaning the unit. Fill the tank with 25-50% of its capacity with water. You may find it beneficial to wash any remaining hydroseed off of the inside of the tank. Start the pump and let the system agitate. This will clean the mulch out of the agitation lines.
Page 8
Square Feet Minutes 200 JAH 2,000-2,400 80-100lbs 10-14lbs 2 Scoops Gallons Square Feet Minutes * 1-2 Punch is the VSI brand of fertilizer and tackifier mix. One scoop per 100 gallons. Machine Specifications Model Engine Pump Weight Weight Hose (Dry) (Loaded)
