- Page 1 SPHYNX II & RS-422 Connectivity Version 1.3 updated 28.04.2006 Merging Technologies Le Verney 1070 Puidoux Switzerland T : +41 21 946 04 44 • F : +41 21 946 04 45 www.merging.com...
- Page 2 Sphynx II is fitted with an industrial RS-422 port. This industrial RS-422 carries different wiring than a regular “broadcast” RS-422. Most often, Sphynx II is delivered with a USB to RS-422 adapter and accompanying cable fully compatible with RS-422 industrial port and we recommend you to favor this solution for computer connection.
- Page 3 Please refer to the following table for connecting a Sphynx II to a unit equipped with a RS-232 port: Sphynx II RS-232 (All other RS-232 pins are left unconnected.) 1 - Rx - 3 - Tx 2 - NC 3 - NC...
