Detailed PAD Port Statistics

Statistics
Command
To View...
Transparent Polled Async
The Statistics command lets you to monitor the status of different parts of the
network. Use the information appearing on the Detailed Port Statistics screens
shown in this section to monitor the operation of a node.
To view the Detailed Port Statistics:
Step
Select Status/Statistics from the Main menu.
1
2 Select Detailed Port Statistics from the Status/Statistics menu.
The three screens shown in Figures 4, 5, and 6, display useful information about the
selected port.
Node:
Detailed PAD Statistics: Port 3
Port Number: 3
Port Speed: 9600
Physical:
Parity Errors : 0
Data Summary:
IN
Characters: 403425
Packets: 80685
Number of Packets Queued: 0
EIA Summary:
State: Connected (SIMPLE
Press any key to continue ( ESC to exit ) ...
Figure 4. Detailed PAD Port Statistics - Page 1
Action
Address: Date:
Port Type: ASYNC PAD
Port State: X28
Overrun Errors : 0
OUT
484115 Characters/sec:
80696 Packets/sec:
INPUT
DTR RTS MB P14
L L
Administration
Time:
Page: 1 of 3
Port Status: Up
Port Utilization Out: 20%
Framing Errors : 0
IN OUT
5 6
1 1
OUTPUT
DSR DCD RI CTS
L L H H L H
