CLEANING THE GRILLS AND SWITCH
Regularly check to see if any dust or foreign matter
has entered the grills positioned on the front and back
of the motor (fig. O and P) or under ON/OFF switch
(Fig. A).
If so use a soft brush to remove any accumulated dust.
to clean grills and switch.
TENSIONING OR REPLACING THE
BELT
Unplug the Mini Carver/Mini Grinder Trade.
Remove the 4 bearing cap screws (10) (fig. R).
To remove guard cover, remove the cover screws (15)
then lift the back side and slide the cover back away
from blade and lift off(Fig.Q).
Rotate tensioning cap (Fig 18) to remove slack from
the belt (Fig S). The blade can be seen moving slightly
when rotating the Bearing Cap (9).
Ensure the belt is correctly positioned over the pulleys
as shown in Fig. S
When tensioning is finished align the Bearing Cap with
the nearest screw holes and tighten the screws. Then
secure the belt cover onto the arm.
DO NOT OVER TENSION THE BELT
Note: clean surroundings with a soft cloth or small
brush.
Accessories & spare parts
visit www.arbortechtools.com
English
7
