Midea C Series Technical & Service Manual page 9

Midea 50Hz AC Fan Coil Unit Two-pipe Wall-mounted Series
Specifications
Model
Power supply
Air flow (H/M/L)
Capacity (H/M/L)
Cooling Water flow rate
Water pressure drop
Capacity (H/M/L)
Heating
Water pressure drop
Power input
Sound pressure level
Type
Fan motor
Quantity
Type
Fan
Quantity
Row
Diameter
Tube pitch(a) × row pitch(b)
Dimension (W×H×D)
Coil
Fin spacing
Fin type
Circuit
Max. working pressure
Net dimensions (W×H×D)
Packing size (W×H×D)
Body
Net weight
Gross weight
Pipe Water inlet/outlet pipe
connections Drain pipe
Notes:
1. H: high fan speed; M: medium fan speed; L: low fan speed
2. Cooling Conditions: Entering Water 7°C, Temperature Rise 5°C, Entering Air Temperature 27°C DB,19°C WB.
Heating Conditions: Entering Water 50°C, Enter air temperature 20°C, and water flow is same to the cooling conditions.
3. Noise is tested in semi-anechoic test room.
MKG-250-B
V/Ph/Hz
m 3 /h 425/390/350
CFM 250/230/205
kW 2.63/2.41/2.16
L/h 452
kPa 29.4
kW 3.36/3.1/2.79
kPa 27.3
W 24
dB(A) 30/24/20
mm
mm
mm
mm
MPa
mm
mm
kg 13
kg 16.3
inch
mm
- 7 -
MCAC-UTSM-201606
MKG-300-B
220-240/1/50
510/470/390
300/275/230
2.97/2.47/2.12
511
35.6
3.91/3.26/2.77
32.9
37
35/29/24
Low noise 4-speed fan motor
1
Tangential fan
1
2
Φ7
21×13.37
635×315×26.74
1.5
Hydrophilic aluminum
5
1.6
915×290×230
1020×390×315
13
16.3
G3/4
ODΦ20
MKG-400-B
680/550/460
400/325/270
3.28/2.83/2.41
564
43.5
4.37/3.73/3.17
40.8
40
37/31/26
13.3
16.7
