Midea C Series Technical & Service Manual page 10

MCAC-UTSM-201606
Specifications
Model
Power supply
Air flow (H/M/L)
Capacity (H/M/L)
Cooling Water flow rate
Water pressure drop
Capacity (H/M/L)
Heating
Water pressure drop
Power input
Sound pressure level
Type
Fan motor
Quantity
Type
Fan
Quantity
Row
Diameter
Tube pitch(a) × row pitch(b)
Dimension (W×H×D)
Coil
Fin spacing
Fin type
Circuit
Max. working pressure
Net dimensions (W×H×D)
Packing size (W×H×D)
Body
Net weight
Gross weight
Pipe Water inlet/outlet pipe
connections Drain pipe
Notes:
1. H: high fan speed; M: medium fan speed; L: low fan speed
2. Cooling Conditions: Entering Water 7°C, Temperature Rise 5°C, Entering Air Temperature 27°C DB,19°C WB.
Heating Conditions: Entering Water 50°C, Enter air temperature 20°C, and water flow is same to the cooling conditions.
3. Noise is tested in semi-anechoic test room.
Midea 50Hz AC Fan Coil Unit Two-pipe Wall-mounted Series
MKG-500-B
V/Ph/Hz
m 3 /h 850/745/620
CFM 500/440/365
kW 4.25/3.85/3.32
L/h 731
kPa 31.8
kW 5.81/5.17/4.43
kPa 30.2
W 50
dB(A) 39/33/28
mm
mm
mm
mm
MPa
mm
mm
kg 15.8
kg 19.4
inch
mm
- 8 -
MKG-600-B
220-240/1/50
1020/915/780
600/540/460
5/4.47/3.97
Low noise 4-speed fan motor
1
Tangential fan
1
2
Φ7
21×13.37
785×315×26.74
1.5
Hydrophilic aluminum
5
1.6
1072×315×230
1180×415×315
G3/4
ODΦ20
860
42.5
6.7/6/5.28
39.7
66
40/34/29
15.8
19.4
