Summary of Contents for National Instruments TBX-96

  • Page 1 National Instruments TBX-96 Manual Get Pricing & Availability at ApexWaves.com Call Today: 1-800-915-6216 Email: sales@apexwaves.com https://www.apexwaves.com/test-measurement-misc/national-instruments/terminal-blocks/TBX-96...

  • Page 2: What You Need To Get Started

    TBX-96 T ERMINAL LOCK This guide describes how to install and use the TBX-96 terminal block with the SCXI-1100, SCXI-1102B/C, SCXI-1104/C, and SCXI-1581 modules. The TBX-96 is a shielded, DIN-rail mountable terminal block with 96 screw terminals for easy connection to the SCXI-1100, SCXI-1102B/C, SCXI-1104/C, and SCXI-1581 front connector.

  • Page 3: Safety Information

    Do not substitute parts or modify equipment. Because of the danger of introducing additional hazards, do not install unauthorized parts or modify the device. Return the device to National Instruments for service and repair to ensure that its safety features are not compromised.

  • Page 4: Connecting The Signals

    TBX terminal block. National Instruments is not liable for any injuries or damage resulting from incorrect signal connections. Clean the TBX-96 by brushing off light dust with a soft non-metallic brush. Remove other contaminants with a stiff non-metallic brush. The unit must be completely dry and free from contaminants before returning it to service.

  • Page 5: Installing The Cable And Terminal Block

    Installing the Cable and Terminal Block Perform the following steps to mount the SH96-96 or R96-96 cable assembly and to connect the TBX-96 to your SCXI module. Refer to Figures 2 through 4 as needed. Turn off your SCXI chassis.
  • Page 6 1 R96-96 Cable Assembly 4 TBX Cable Adapter 2 SH96-96 Cable Assembly 5 Thumb Screws 3 Backshell Mounting Screws and Ears 6 SCXI Chassis Figure 2. Connecting the SH96-96 or R96-96 Cable to the SCXI Module © National Instruments Corporation TBX-96 Terminal Block...
  • Page 7 Note: The SH96-96 and R96-96 cables are not shown in the exact position for proper connection to the terminal block connector. See Figure 4 for the completed connection. Figure 3. Connecting the SH96-96 or R96-96 Cable to the TBX-96 Terminal Block Connect one end of the cable assembly to your TBX cable adapter and secure the cable by tightening both backshell mounting screws.

  • Page 8: Mounting On And Removing From A Din-Rail

    Figure 4. The Completed Installation Mounting on and Removing from a DIN-Rail To mount the TBX-96 terminal block onto the DIN rail, snap it into the DIN rail with a firm push. To remove the TBX-96 terminal block from the DIN rail, place a flathead screwdriver into the slot above the terminal block base and pry it from the rail.

  • Page 9: Specifications

    For use at altitudes up to 2,000 meters. Installation category I Pollution degree 2 Category I is a signal level such as voltages on a printed wire board (PWB) on the secondary of an isolation transformer. TBX-96 Terminal Block ni.com...

  • Page 10: Electromagnetic Compatibility

    DoC (in Adobe Acrobat format) appears. Click the Acrobat icon to download or read the DoC. PWB Layout Dimensions In the event your application requires individualized mounting, see Figure 5 for the circuit board layout dimensions of the TBX-96. © National Instruments Corporation TBX-96 Terminal Block...
  • Page 11 (2.8 in.) 0.86 cm 3.61 cm (0.339 in.) (1.42 in.) 14.17 cm (5.58 in.) 17.78 cm 19.50 cm (7.0 in.) (7.678 in.) 8.46 cm (3.329 in.) 10.75 cm (4.232 in.) Figure 5. TBX-96 Circuit Board Layout Dimensions TBX-96 Terminal Block ni.com...

  • Page 12: Technical Support Resources

    Technical Support Resources NI Web Support National Instruments Web support is your first stop for help in solving installation, configuration, and application problems and questions. Online problem-solving and diagnostic resources include frequently asked questions, knowledge bases, product-specific troubleshooting wizards, manuals, drivers, software updates, and more. Web support is available through the Technical Support section of ni.com...
