VE VVG Series
Electronic Two-way Valves
Normally Closed
Description
Features
Application
Product Numbers
and Ordering
Information
The VE VVG electronic two-way valves control the flow of water or glycol solutions. The
electronic actuator requires a 24 Vac supply and receives a 0 to 10 Vdc control signal
to control the 7/32-inch (5.5 mm) nominal stroke valve.
·
Maintenance free actuator with reversible motor.
·
Selector plug on actuator permits selection of linear or equal percentage flow
characteristics.
·
Reduced seat diameter produces reduced C
·
0 to 10 Vdc or 0 to 1000 ohms signal input.
·
Position output signal 0 to 10 Vdc.
·
Available with union or sweat end connections (1/2-inch and 3/4-inch).
·
Double O-ring packing with Teflon® wiper.
·
Manual override knob with indication of stroke allows for repositioning of the valve
in power-off conditions (SQS65U only).
·
Spring return closes flow port in power-off condition (SQS65.5U only).
Use the VE VVG as a control and shutoff valve in small to medium HVAC installations
for hot water and chilled water applications. Use in closed circuits only.
NOTE:
This valve is not designed for steam applications. See valve body
Specifications for details.
Order the valve and actuator separately. See Table 1 for product information.
Technical Instructions
Document No. 155-112P25
Rev. 3 August, 2002
(K
) in 1/2-inch valve bodies.
v
vs
VE VVG-1
Siemens Industry, Inc.
Advertisement
Table of Contents
Related Manuals for Siemens VVG44.15-0.4S
Summary of Contents for Siemens VVG44.15-0.4S
- Page 1 Use in closed circuits only. NOTE: This valve is not designed for steam applications. See valve body specifications for details. Product Numbers Order the valve and actuator separately. See Table 1 for product information. and Ordering Information Siemens Industry, Inc.
- Page 2 Ambient Temperature Operating 5°F to 122°F (-15°C to 50°C) Transport and storage -13°F to 149°F (-25°C to 65°C) Physical Characteristics Weight SQS65U 1.1 lbs. (0.5 kg) SQS65.5U 1.3 lbs. (0.6 kg) Dimensions See Figure 6 Page 2 Siemens Industry, Inc.
- Page 3 (10) 16.55 23.40 28.66 33.09 37.0 45.31 52.32 58.5 64.08 — — 1-1/4 (32) 18.7 (16) 26.47 37.44 45.85 52.95 59.2 72.5 — — — — — 1-1/2 (40) (25) — — — — — Siemens Industry, Inc. Page 3...
- Page 4 · Match the direction of flow with the symbol cast on the valve body. See Figure 1. · Allow 8 inches (200 mm) of clearance for installation and service. Page 4 Siemens Industry, Inc.
- Page 5 G = System potential G0 = System neutral 0 to 10 Vdc control signal Input for 0 to 1000 ohms remote setting unit or low temperature detection unit Measuring neutral Output for 0 to 10 Vdc position indication Siemens Industry, Inc. Page 5...
- Page 6 Check valve operation. Thread plastic valve cap (Figure 1) onto top of valve. Turn it to adjust valve position. Stem Packing Figure 5. VVG Valve Construction. Service If either valve or actuator is inoperative, replace that unit. WARNING: To avoid personal injury, do not attempt to repair the valve. Page 6 Siemens Industry, Inc.
- Page 7 Information in this publication is based on current specifications. The company reserves the right to make changes in specifications and models as design improvements are introduced. APOGEE is a trademark of Siemens Industry, Inc. Other product or company names mentioned herein may be the trademarks of their respective owners.
