Evolution ™ Series
6" Furniture Feed Poke-Thru Devices
I N S T L L T I O N I N S T R U C T I O N S
nstallation nstruction No.: 1 007 155 R2 – Updated May 2010
Products Covered: 6 TCFF, 6STC, 6CFFTC, 15FFH , 152CH , CE6 TCFF
C UTION DO NOT operate tile stripper, cleaning, or resurfacing equipment over top of covers. This may result in
damage to the surface finish of the product.
Suitable for use in air handling spaces in accordance with Sec. 300-22 (C) of the National Electrical Code.
FLOOR PREP R TIONS
Step 1 Layout and locate position of hole(s).
C UTION: Minimum spacing of 2ft on center and not more than
one device per each 65 square feet of floor area in
each span.
24" [610mm] Min
Center – Center
C UTION: Be certain to locate hole at least 6" [152mm] from any wall or
pillar to leave enough room for Poke-Thru cover assembly.
Step 3 Create core hole according to the
dimensions provided in the chart.
Wiremold electrical systems conform to and should be properly
grounded in compliance with requirements of the current National
Electrical Code or codes administered by local authorities.
ll electrical products may present a possible shock or fire
hazard if improperly installed or used. Wiremold electrical products may
bear the mark as UL Listed and/or Classified and should
be installed in conformance with current local and/or the National
Electrical Code.
IMPORT NT: Please read all instructions
before beginning.
Step 2 Remove 7 1/4" dia. [166mm] section from
carpet or tile. Use template provided.
FLOOR
TYPE
Covered Floors
(Carpet, Tile or
Wood)
Bare Concrete
or Terrazzo
1
7 1/4"
[166mm]
CORE CORE
SIZE (Min.) SIZE (Max.)
6" [152mm] 6 1/8"
6 1/16" [154mm] 6 1/8"
[156mm]
[156mm]
