Galion
USB&HDMI

1. USE

Data transmission.
(Supplied with M3.5 screws for BS boxes. Flush mounting or Surface
mounting.)

2. RANGE

Designation
USB and HDMI
2 824 48/48m
Socket
Colours
- front: white/rose golden/champagne/dark silver
- rear: white/rose golden/champagne/dark silver
X XXX XX white
X XXX XX-C matt black
X XXX XX-C1 rose golden
X XXX XX-C2 champagne
X XXX XX-C3 dark silver
Technical data sheet:F02871EN/00
2 824 48/48m
Weight
Cat. No. Characteristics
(g)
79
87045 Limoges Cedex
Telephone: (+33) 05 55 06 87 87 - Fax:(+33) 05 55 06 88 88
Cat. No(s): 2 824 48/48m

3. PREPARATION

3.1 General preparation
- flushing
mounting
box:
- surface
mounting
box:

4. OVERALL DIMENSIONS

88
Profile Size: 86×88 mm
Distance of installation hole: 60.3 mm
Minimum depth of the box>35 mm
Updated: 30/08/2019
CONTENTS
1. Use.......................................1
2. Range...................................1
3. Preparation.........................1
4. Overall dimensions.................1
5. Connection...........................2
6. Technical Characteristics......2
7. Cleaning.................................2
8. Conformity - Approvals..................2
1
2
86
24.8
Created: 30/08/2018
9.2
