Ameriwood HOME 5969500COM Assembly Manual
  1. Manuals
  2. Brands
  3. Ameriwood HOME Manuals
  4. Indoor Furnishing
  5. 5969500COM
  6. Assembly manual
Ameriwood HOME 5969500COM Assembly Manual

Ameriwood HOME 5969500COM Assembly Manual

Colebrook 6 drawer dresser
Hide thumbs

Advertisement

Quick Links

Download this manual
5555555COM
CoCeCrooC 5 Crawer CreCCer
Keep thiC ACCemCCy ManuaC for future reference
WARNING
Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall
- Do Not allow children to climb on unit
- Put heavy items on lower shelves or drawers
- Two people required for assembly
B345555555COM55
ameriwoodhome.com
Follow Ameriwood Home

Advertisement

loading
Need help?

Need help?

Do you have a question about the 5969500COM and is the answer not in the manual?

Questions and answers

Related Manuals for Ameriwood HOME 5969500COM

Summary of Contents for Ameriwood HOME 5969500COM

  • Page 1 B345555555COM55 Keep thiC ACCemCCy ManuaC for future reference ameriwoodhome.com WARNING Follow Ameriwood Home Unit can tip over causing severe injury or death. - Anchor unit to stud in wall - Do Not allow children to climb on unit - Put heavy items on lower shelves or drawers...
  • Page 2 Warning Do NOT return this product! Contact our friendly customer service team first for help Call us! Assembly Tips 1-800-489-3351 Monday-Friday 9am - 5pm CST Visit ameriwoodhome.com HeCpfuC HintC - Open your item in the area you plan to keep it for less heavy lifting - Identify, sort and count the parts before attempting assembly - Compression dowels are tapped in with a hammer - Slides are labeled with a R (right) and L (left) for proper placement...
  • Page 3 5555555COM CoCeCrooC 5 Crawer CreCCer Board Ident f cat on Not actual size T5969500010 T5969500020 T5969500030 TOP PANEL SIDE PANEL LEFT SIDE PANEL RIGHT T5969500050 T5969500040 T5969500060 DRAWER FRONT PARTITION PANEL DRAWER BACK T5969500070 T5969500080 T5969500090 DRAWER SIDE LEFT DRAWER SIDE RIGHT SIDE RAIL LEFT T5969500100 T5969500110...
  • Page 4 5555555COM CoCeCrooC 5 Crawer CreCCer Board Ident f cat on Not actual size T5969500130 T5969500140 KICK PANEL BOTTOM PANEL T5969500150 T5969500160 BACK PANEL DRAWER BOTTOM ameriwoodhome.com...

  • Page 5: Actual Size

    5555555COM CoCeCrooC 5 Crawer CreCCer Part LiCt Actual Size TTA0001 TTA0003 TTA0005 Cam Bolt Cam Lock CBS 3.5 x 12 15-11.5 TTA0010 TTA0013 TTA0014 CSK 4 x 32 PHCB 4 X 12 PH M4 X 20 TTA0016 TTA0018 DOWEL 6 X 30 NAIL ameriwoodhome.com...
  • Page 6 5555555COM CoCeCrooC 5 Crawer CreCCer Part LiCt Not Actual Size x1 set TTA0026 TTA0030 TTA0032 ANTI TIPPING KIT DRAWER BRACKET PULL HANDLE 96MM x6 Set TTA0033 TTA0036 DRAWER SLIDE DOUBLE END 300 MML BOLT 64MM ameriwoodhome.com...

  • Page 7: Before You Start

    5555555COM CoCeCrooC 5 Crawer CreCCer Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight.
  • Page 8 5555555COM CoCeCrooC 5 Crawer CreCCer Step 1 TTA0001 TTA0033 TTA0003 TTA0016 TTA0005 SCREW HOLE POSITION Quick Assembly FRONT BACK Proper orientation of CAM LOCK ameriwoodhome.com...
  • Page 9 5555555COM CoCeCrooC 5 Crawer CreCCer Step 2 TTA0003 TTA0016 TTA0005 TTA0033 LEFT SURFACE SCREW HOLE POSITION BACK FRONT RIGHT SURFACE SCREW HOLE POSITION FRONT BACK ameriwoodhome.com...
  • Page 10 5555555COM CoCeCrooC 5 Crawer CreCCer Step 3 TTA0001 TTA0003 TTA0016 TTA0005 TTA0033 SCREW HOLE POSITION Quick Assembly BACK FRONT Proper orientation of CAM LOCK ameriwoodhome.com...
  • Page 11 5555555COM CoCeCrooC 5 Crawer CreCCer Step 4 TTA0003 TTA0016 x2 Set Quick Assembly Proper orientation of CAM LOCK ameriwoodhome.com...
  • Page 12 5555555COM CoCeCrooC 5 Crawer CreCCer Step 5 TTA0003 TTA0016 x2 Set Quick Assembly Proper orientation of CAM LOCK ameriwoodhome.com...
  • Page 13 5555555COM CoCeCrooC 5 Crawer CreCCer Step 6 ameriwoodhome.com...
  • Page 14 5555555COM CoCeCrooC 5 Crawer CreCCer Step 7 TTA0036 ameriwoodhome.com...
  • Page 15 5555555COM CoCeCrooC 5 Crawer CreCCer Step 8 ameriwoodhome.com...
  • Page 16 5555555COM CoCeCrooC 5 Crawer CreCCer Step 9 ameriwoodhome.com...
  • Page 17 5555555COM CoCeCrooC 5 Crawer CreCCer Step 10 TTA0016 ameriwoodhome.com...
  • Page 18 5555555COM CoCeCrooC 5 Crawer CreCCer Step 11 TTA0016 ameriwoodhome.com...
  • Page 19 5555555COM CoCeCrooC 5 Crawer CreCCer Step 12 TTA0016 ameriwoodhome.com...
  • Page 20 5555555COM CoCeCrooC 5 Crawer CreCCer Step 13 ameriwoodhome.com...
  • Page 21 5555555COM CoCeCrooC 5 Crawer CreCCer Step 14 ameriwoodhome.com...
  • Page 22 5555555COM CoCeCrooC 5 Crawer CreCCer Step 15 TTA0010 Laminated Face ameriwoodhome.com...
  • Page 23 5555555COM CoCeCrooC 5 Crawer CreCCer Step 16 x1 set TTA0001 TTA0026 ameriwoodhome.com...
  • Page 24 5555555COM CoCeCrooC 5 Crawer CreCCer Step 17 TTA0010 ameriwoodhome.com...
  • Page 25 5555555COM CoCeCrooC 5 Crawer CreCCer Step 18 ameriwoodhome.com...
  • Page 26 5555555COM CoCeCrooC 5 Crawer CreCCer Step 19 TTA0018 Carefully turn the unit over onto its front as shown. Assure that the unit is square. Distance from corner to corner must be equal as shown. IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT AND MUST BE INSTALLED PROPERLY.
  • Page 27 5555555COM CoCeCrooC 5 Crawer CreCCer Step 20 TTA0030 x6 Set ameriwoodhome.com...
  • Page 28 5555555COM CoCeCrooC 5 Crawer CreCCer Step 21 TTA0030 x6 Set ameriwoodhome.com...
  • Page 29 5555555COM CoCeCrooC 5 Crawer CreCCer Step 22 TTA0016 x6 Set ameriwoodhome.com...
  • Page 30 5555555COM CoCeCrooC 5 Crawer CreCCer Step 23 TTA0010 x6 Set ameriwoodhome.com...
  • Page 31 5555555COM CoCeCrooC 5 Crawer CreCCer Step 24 TTA0010 x6 Set ameriwoodhome.com...
  • Page 32 5555555COM CoCeCrooC 5 Crawer CreCCer Step 25 TTA0013 x6 Set ameriwoodhome.com...
  • Page 33 5555555COM CoCeCrooC 5 Crawer CreCCer Step 26 TTA0032 TTA0014 x6 Set ameriwoodhome.com...
  • Page 34 5555555COM CoCeCrooC 5 Crawer CreCCer Step 27 x6 Set TTA0033 TTA0005 x6 Set SCREW POSITION LEFT RIGHT ameriwoodhome.com...
  • Page 35 5555555COM CoCeCrooC 5 Crawer CreCCer Step 28 For Masonry, Concrete, or other wall materials: TTA0026 Consult your local hardware store for appropriate anchors to bracket. IMPORTANT: THIS UNIT MUST BE SECURE TO THE WALL TO HELP PREVENT TIPOVER. FOLLOW THESE INSTRUCTIONS TO INSTALL THE ANTI-TIPPING SAFETY BRACKET PROVIDED WITH THIS PRODUCT.
  • Page 36 5555555COM CoCeCrooC 5 Crawer CreCCer Step 28 Pour Ca maçonnerie, Céton ou d'autreC matériaux de mur: TTA0026 Consultez votre magasin local de matériel pour les ancrages sécurité. IMPORTANT: CET APPAREIL DOIT ÊTRE FIXÉ AU MUR POUR AIDER À PRÉVENIR LE BASCULEMENT. SUIVRE CES INSTRUCTIONS POUR INSTALLER LE SUPPORT DE SÉCURITÉ...
  • Page 37 5555555COM CoCeCrooC 5 Crawer CreCCer Step 28 Para mampoCtería, hormigón u otroC materiaCeC de Ca pared: TTA0026 Consulte a su ferretería local para los el soporte de seguridad. IMPORTANTE: ESTA UNIDAD DEBE SER ASEGURADA CON LA PARED PARA PREVENIR VOLQUEO. SIGA ESTAS INSTRUCCIONES PARA INSTALAR EL SOPORTE DE SEGURIDAD ANTIVOLQUEO SUMINISTRADO CON ESTE PRODUCTO.
  • Page 38 5555555COM CoCeCrooC 5 Crawer CreCCer Step 29 Notice, the drawer bracket holes are slotted. Drawer fronts can be adjusted by loosening screws, making needed adjustments and retightening screws. ameriwoodhome.com...

  • Page 39: Maximum Loads

    5555555COM CoCeCrooC 5 Crawer CreCCer MAXIMUM LOADS This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. 75 lbs. 34.02 kg 35 lbs. 15.8 kg Warning: RiCC of injury to perConC ‐ do not pCace a teCeviCion on thiC furniture. ThiC furniture iC not approved for uCe with a teCeviCion.
  • Page 40 5555555COM CoCeCrooC 5 Crawer CreCCer CARGA MAXIMA Esta unidad ha sido diseñada para soportar la carga máxima anotada. El exceder estos límites puede causar inestabilidad, colapsarse y/o causar serias lesiones. 75 lbs. 34.02 kg 35 lbs. 15.8 kg ACVERTENCIA: RieCgo de CeCioneC a CaC perConaC ‐ no coCoque un teCeviCor CoCre mueCCeC. ECte mueCCe no eCtá...
  • Page 41 5555555COM CoCeCrooC 5 Crawer CreCCer CHARGES MAXIMALES Ce meuble a été conçu pour supporter les charges maximales indiquées. En excédant ces limites de charge, le meuble pourrait devenir instable, s’effondrer, et/ou causer des blessures graves. 75 lbs. 34.02 kg 35 lbs. 15.8 kg AVERTISSEMENT : RiCque de CCeCCure corporeCCe ‐...
  • Page 42 5555555COM CoCeCrooC 5 Crawer CreCCer of Conformity 1. This applies to the Dorel Home Furnishings, Inc. product by this manual. 2. This applies to compliance of this product with the CPSC Ban on Lead-Containing Paint (16 CFR 1303). 3. This product is distributed by: Dorel Home Furnishings, Inc. 410 East First Street South Wright City, MO 63390 636-745-3351...
  • Page 43 5555555COM CoCeCrooC 5 Crawer CreCCer RegiCter your product to receive the foCCowing: * New trend detaiCC ‐CneaC peeC on what'C new * SurveyC ‐have a voice within our community * ExcCuCive deaCC and diCcount codeC * QuicC and eaCy repCacement part Cervice To regiCter your product, viCit ViCit your CocaC retaiCer'C weCCite, rate your purchaCed product and Ceave uC Come feedCacC!
  • Page 44 5555555COM CoCeCrooC 5 Crawer CreCCer RegiCtre Cu producto para reciCir Co Ciguiente: * CetaCCeC de nuevaC tendenciaC ‐ViCtazo a Co nuevo * EncueCtaC ‐aCec Cu voz entre Cu comunidad RegiCtre * CódigoC de ofertaC y deCcuentoC excCuCivoC * FáciC y rápido Cervicio de parteC de rempCace Para regiCtrar Cu producto, viCite Clasificasión de 5 estrellas ViCite eC...
  • Page 45 5555555COM CoCeCrooC 5 Crawer CreCCer EnregiCtrez votre produit pour recevoir CeC éCémentC CuivanteC: * CétaiCC Cur CeC nouveCCeC tendanceC ‐un aperçu Cur CeC nouveautéC EnregiCtrez * SondageC ‐avoir une voix au Cein de notre communauté excCuCiveC et codeC promo * Service de pièceC de rechange rapide et faciCe Pour enregiCtrer votre produit, viCitez 5 Étoiles ViCitez Ce Cite WeC de votre détaiCCant CocaC, évaCuez votre produit...
