  • Page 1 Back Bar Bottle Cooler Service, Installation and Care Manual Please read this manual completely before attempting to install or operate this equipment. Notify carrier of damage! Inspect all components immediately. IMPORTANT INFORMATION READ BEFORE USE PLEASE SAVE THESE INSTRUCTIONS!
  • Page 2 Service and Installation Manual COMMECIAL REFRIGERATOR SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. Our product instructions will be uploaded on our company official website. This is the Safety Alert Symbol.
  • Page 3 Service and Installation Manual The appliance use flammable insulation blowing gas C5H10, disposal of the appliance shall in accordance with the regulations of local authorities. The key for appliance electric box should be safe kept by qualified persons in order to avoid a hazard WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.

  • Page 4: Table Of Contents

    Service and Installation Manual CONTENTS RECEIVING & INSPECTING EQUIPMENT..................4 SPECIFICATIONS ............................5 INSTALLATION ................................6 OPERATION ................................. 7 MAINTENANCE ............................. 9 WIRING DIAGRAM ............................. 12 All rights reserved. Reproduction without written permission is prohibited. SERIAL NUMBER INFORMATION The serial number of all self-contained refrigerators is located inside the unit on the left hand side near the top on the wall.

  • Page 5: Specifications

    Service and Installation Manual SPECIFICATION BACK BAR BOTTLE COOLER SHIP STORAGE CHARGE WEIGHT NEMA CAPACITY MODEL# V/Hz/Ph AMPS HP BTU PLUG KBB48-2G-24 115/60/1 10.45 3.88 5-15P KBB60-2G-24 115/60/1 14.16 3.88 356.4 5-15P KBB72-3G-24 115/60/1 17.26 4.59 415.8 5-15P KBB48-2G-24SD 115/60/1 10.45 8.05 5-15P...

  • Page 6: Installation

    Service and Installation Manual INSTALLATION Location Units represented in this manual are intended for indoor use only. Be sure the location chosen has a floor strong enough to support the total weight of the cabinet and contents. A fully loaded unit can weigh as much as 1500 pounds.

  • Page 7: Operation

    Service and Installation Manual OPERATION Do not throw items into the storage area. Failure to heed these recommendations could result in damage to the interior of the cabinet. CAUTION Refrigerators: The factory setting for temperature range is 34°F - 38 °F Light Switch: An light switch is located next to on/off switch on the front of the bottom shroud.
  • Page 8 Service and Installation Manual 2. MAIN FUNCTIONS 2.1 HOW TO SEE THE SETPOINT 1. Push and immediately release the SET key: the display will show the set point value; 2. Push and immediately release the SET key or wait for 5 seconds to display the sensor value again. 2.2 HOW TO CHANGE THE SETPOINT 1.

  • Page 9: Maintenance

    Service and Installation Manual MAINTENANCE The power switch must be turned to OFF and the unit disconnected from the power source whenever performing service, maintenance functions or cleaning the refrigerated area. DANGER The interior and exterior can be cleaned using soap and warm water. If this isn't sufficient, try ammonia and water or a nonabrasive liquid cleaner.
  • Page 10 Service and Installation Manual MAINTENANCE Cleaning solutions need to be alkaline based or non-chloride cleaners. Any cleaner containing chlorides will damage the protective film of the stainless steel. Chlorides are also commonly found in hard water, salts, and household and industrial cleaners. If cleaners containing chlorides are used be sure to rinse repeatedly and dry thoroughly upon completion.
  • Page 11 Service and Installation Manual MAINTENANCE Swing Door Replacement and Adjustment 1. Open the bottom shroud and hold the door, then loose bottom hinge’s screws and take off the old door; 2. Prepare new door, insert top pin into top hinge, get one bottom hinge to hold the door by the bottom pin , then fasten bottom hinge securely to the door frame with three screws;...

  • Page 12: Wiring Diagram

    Service and Installation Manual WIRING DIAGRAM Model: KBB48-2G-24/KBB60-2G-24 Model: KBB72-3G-24...
  • Page 13 Service and Installation Manual WIRING DIAGRAM Model: KBB48-2G-24SD/KBB60-2G-24SD...
  • Page 14 Service and Installation Manual WIRING DIAGRAM Model: KBB48-2G-24/KBB60-2G-24...
  • Page 15 Service and Installation Manual WIRING DIAGRAM Model: KBB72-3G-24...
  • Page 16 Service and Installation Manual WIRING DIAGRAM Model: KBB48-2G-24SD/KBB60-2G-24SD...
  • Page 17 Service and Installation Manual IKON WARRANTY Two Year Parts & Labor Warranty MVP Group (IKON) warrants, to the original purchaser, all of its new equipment to be free from defects in material and workmanship, under normal use and maintenance service, for a period of two (2) years from the date of original purchase or 15 months after shipment date from the manufacturer, whichever occurs first.
