- Page 1 PD79X Ex DIGITAL TRUNKING PORTABLE RADIO OWNER’S MANUAL...
- Page 2 Preface Thanks for your favor in our product. This manual is helpful for you to quickly know how to use the product. For detailed features and operations, please refer to the Feature Description and Opera- tion Manual along with the product. To avoid body injury or property loss caused by misoperation, please read the Safety Information Booklet carefully before use.
- Page 3 Please note that the above information is applicable to Hytera Communications Corporation Limited (the U n i t e d S t a t e s F e d e r a l C o m m u n i c a t i o n s ●...
-
Page 4: Table Of Contents
Contents Intrinsically Safe Radio Information ---------------------------------------------- 2 Troubleshooting ------------------------------------------------------------------------- 10 Equipment marking ----------------------------------------------------------------- 2 Care and Cleaning ---------------------------------------------------------------------- 11 No Misoperations-------------------------------------------------------------------- 2 Optional Accessories ------------------------------------------------------------------ 11 Safety Instructions ------------------------------------------------------------------ 2 Specifications ---------------------------------------------------------------------------- 12 Compliance Standards ------------------------------------------------------------ 2 Items in the Package ------------------------------------------------------------------- 3 Product Overview ----------------------------------------------------------------------- 3 Product Controls--------------------------------------------------------------------- 3 Programmable Keys ---------------------------------------------------------------- 4... -
Page 5: Intrinsically Safe Radio Information
Intrinsically Safe Radio Information Equipment marking Safety Instructions modification of the radio may result in termination of Ex-protection (intrinsic safety) of the radio. FM/CAN C a u t i o n : To p ro te c t y o u a g a i n s t a n y Improper usage of the product other than it is ●... -
Page 6: Items In The Package
Items in the Package Product Overview Please unpack carefully and check that all items listed Product Controls below are received. If any item is missing or damaged, please contact your dealer. Belt Clip Radio Battery Power Adapter Antenna Charger Strap Documentation Kit Part Name Part Name... -
Page 7: Programmable Keys
Programmable Keys LED Indicator Icon Name Icon Radio Status The radio is in For enhanced convenience, you may request your emergency state LED Indication Radio Status Emergency (except for silent dealer to program the SK1, SK2, and TK ( ) as The LED indicator Powering on Icon... -
Page 8: Attaching The Antenna
Charging the Battery Push the battery until it is fully fitted into the slot, and then release the battery latch as ④ shows. Caution: Note: To remove the battery, please power U s e t h e c h a r g e r s p e c i f i e d b y t h e ●... -
Page 9: Basic Operation
Selecting a Zone special characters. But in the numeric mode, LED Indication/Tone Icon The LED Indicator glows pressing will input the numeric digit 1 A zone is a group of channels with the same property, green. In the alphabetic mode, press to input the which can facilitate convenient management over ●... -
Page 10: Call Services
group call contact, and all call contact information Note： Go to “Menu -> Contact -> Contact List”. The number and alias of a new contact such as call alias, call type and call ID. Use the Up/Down key to select an appropriate ●... -
Page 11: Group Call
You can hold down the PTT key to call back within the description on how to make and receive calls on the InBox preset time. If you do not respond to it, the radio will analog channel with signaling. The Inbox saves the received messages and marks display appropriate indications. -
Page 12: Available Features
Available Features Voice Services: Group Call, ● Private Call, All Call, Phone Call Message Services: New Msg, Available features of this radio are listed below. Please ● Q u i c k Te x t , I n B o x , O u t B o x , refer to the Feature Description and Operation Manual Drafts for detailed feature descriptions. -
Page 13: Troubleshooting
Troubleshooting Phenomena Analysis Solution The battery may be improperly installed. Remove the battery and then reattach it. The battery power may run out. Recharge or replace the battery. The radio fails to power on. The battery may suffer from poor contact caused by Clean the battery contacts. -
Page 14: Care And Cleaning
Care and Cleaning Optional Accessories Intrinsically Safe Noise- ECN22-Ex cancelling Headset (IP57) To guarantee optimal performance as well as a long The following items are the main optional accessories Ex earset with On-Mic EHN12-Ex service life of the product, please follow the tips below. for the product, and please consult your local dealer Intrinsically Safe Throat- for more other accessories. -
Page 15: Specifications
Specifications Item Specifications Rated Operating Voltage DC 7.4V Max. Operating Voltage DC 8.4V Max. Operating Current 1.5A We i g h t (w i t h s t a n d a r d About 495g antenna & battery) Sensitivity 0.3μV RF Power Output Rated Audio Power... - Page 16 Preface Thanks for your favor in our product. This manual is helpful for you to quickly know how to use the product. For detailed features and operations, please refer to the Feature Description and Operation Manual along with the product. To avoid body injury or property loss caused by misoperation, please read the Safety Information Booklet carefully before use.
- Page 17 EU countries only. Hytera Communications Corporation Limited (the ● U n i t e d S t a t e s F e d e r a l C o m m u n i c a t i o n s Company) endeavors to achieve the accuracy and Commission, Code of Federal Regulations;...
- Page 18 Contents Intrinsically Safe Radio Information -----------------------------------------------2 Equipment marking -----------------------------------------------------------------2 No Misoperations -------------------------------------------------------------------2 Safety Instructions ------------------------------------------------------------------2 Compliance Standards ------------------------------------------------------------2 Items in the Package --------------------------------------------------------------------3 Product Overview ------------------------------------------------------------------------3 Product Controls --------------------------------------------------------------------3 Programmable Keys ---------------------------------------------------------------4 LCD Icon ------------------------------------------------------------------------------4 LED Indicator ------------------------------------------------------------------------4 Before Use ----------------------------------------------------------------------------------4 Attaching the Battery ---------------------------------------------------------------4 Attaching the Antenna -------------------------------------------------------------5 Attaching the Belt Clip ------------------------------------------------------------5...
-
Page 19: Intrinsically Safe Radio Information
Intrinsically Safe Radio ● The radio logo or model is hard to be recognized; dealer for repair and servicing. Information ● Do not dissemble or redo the radio. Unauthorized Safety Instructions modification of the radio may result in termination Equipment marking of Ex-protection (intrinsic safety) of the radio. -
Page 20: Items In The Package
Items in the Package Product Overview Standard Issue Date CAN/CSA-C22.2 No.61010-1 (Ed. Please unpack carefully and check that all items listed 2009 Product Controls 2.0) below are received. If any item is missing or damaged, ATEX please contact your dealer. EN 60079-0 (Ed. -
Page 21: Programmable Keys
Programmable Keys Icon Name Radio Status Call hung period. No voice is being transmitted Unread message(s). For enhanced convenience, you may request your or received on the traffic Message Icon The LED indicator channel during a call. Within Inbox is full. dealer to program the SK1, SK2, and TK ( ) as glows orange. -
Page 22: Attaching The Antenna
Charging the Battery Attaching the Antenna Align the accessory (such as an audio accessory, or a programming cable) plug with the accessory Caution: connector. ing cable) plug with the accessory U s e t h e c h a r g e r s p e c i f i e d b y t h e ●... -
Page 23: Basic Operation
Inputting via Keypad There are two hunt plans: Fixed Control Channel and LED Indication/Tone Icon Flexible Control Channel. You may request your dealer The LED Indicator glows You can input alias, call numbers and messages via the green. to set the appropriate plan for your radio. Please refer The LED Indicator glows keypad of the radio. -
Page 24: Selecting A Subgroup
Selecting a Subgroup Contact List key. Private Call In the “Contact List” menu, you can check the contact You can include the group contacts into a subgroup for information, edit or delete the private contacts. Private call is a call made to a private contact. There efficient management. -
Page 25: Group Call
ReDial Call Logs established successfully, the radio will emit a tone As a broadcast call is made in the same manner as a group call, we will only detail their differences in the In the home screen, press to enter the and display the icon on the LCD as well. -
Page 26: Emergency Call
Message Services missed the start of a group call can join this active group In the home screen, press to enter the call later without any operation. ReDial Call Logs. The Late Entry feature is applicable to the following Use the Up/Down key to select an appropriate Message Services allow you to edit and send a new situations: contact. -
Page 27: Available Features
Available Features InBox Message Services: New Msg, ● The Inbox saves the received messages and marks InBox, OutBox, Drafts, Status Available features of this radio are listed below. Please each message with a corresponding icon to indicate its Message, Quick Text Data Services refer to the Feature Description and Operation Manual status. -
Page 28: Troubleshooting
Troubleshooting Phenomena Analysis Solution The battery may be improperly installed. Remove the battery and then reattach it. The battery power may run out. Recharge or replace the battery. The radio fails to power on. The battery may be poorly connected due to dirtied or Clean the battery contacts. -
Page 29: Care And Cleaning
Care and Cleaning Optional Accessories Intrinsically Safe Noise- ECN22-Ex cancelling Headset (IP57) To guarantee optimal performance as well as a long The following items are the main optional accessories EHN12-Ex Ex earset with On-Mic PTT service life of the product, please follow the tips below. for the radio. -
Page 30: Specifications
Specifications Item Specifications Rated Operating Voltage DC 7.4V Max. Operating Voltage DC 8.4V Max. Operating Current 1.5A Weight (with standard About 495g antenna & battery) Sensitivity 0.3μV RF Power Output Rated Audio Power Output 0.5W Audio Distortion Ambient Temperature C to +50 Storage Temperature C to +85 Charging Temperature... - Page 31 是海能达通信股份有限公司的注册商标或商标 Hytera Communications Corporation Limited. 2015 Hytera Communications Corporation Limited. 2015 海能达通信 股份有限公司 。版权所有 深圳市南山区北环大道9108号 Z04313 H05658 8 1 1 PD7 9 0 0 0 8 0 0...
